Bosch NDN-921 Quick Manual page 6

6 | NDN-921 FlexiDomeHD 720p Day/Night IP Camera
Software Control
Unit Configuration Via web browser or Configuration Manager
Flicker Control 50/60 Hz, selectable
Software update Flash ROM, remote programmable
Network
Protocols RTP, RTSP, Telnet, UDP, TCP, IP, HTTP,
HTTPS, FTP, DHCP, IGMP V2/V3, ICMP,
ARP, SMTP, SNTP, SNMP, 802.1x, UPnP
Encryption TLS 1.0, SSL, AES (optional)
Ethernet STP, 10/100 Base-T, auto-sensing, half/
full duplex, RJ45
PoE SUPPLY IEEE 802.3af compliant
Optical
Varifocal lens IR corrected, manual zoom and focus
adjustment
Iris control Automatic iris control
Viewing angle 92.9º to 31.7º horizontal
67.9º to 23.7º vertical
Mechanical
Weight 0.67 kg (1.48 lb)
+SMB: 1.29 kg (2.84 lb)
Mounting Flush mount or surface mount
Color White (RAL9010) trim ring with black inner
liner
Adjustment range 360º pan, 90º tilt, ±90º azimuth
Dome bubble Polycarbonate, clear with UV blocking anti-
scratch coating
Trim ring Aluminum
Environmental
Motion+ versions
Operating temperature -20 ºC to +50 ºC
default (with heater off) (-4 ºF to +122 ºF)
cold start
Operating temperature -50 ºC to +50 ºC
(with heater on) (-58 ºF to
+122 ºF)
Storage temperature -50 ºC to +70 ºC (-58 ºF to +158 ºF)
Operating humidity 5% to 93% relative humidity
Storage humidity Up to 98% relative humidity
Impact protection IEC 60068-2-75 test Eh, 50 J
EN 50102, exceeding IK 10
IVA versions
-20 ºC to +45 ºC
(-4 ºF to +113 ºF)
cold start
-50 ºC to +45 ºC
(-58 ºF to
+113 ºF)
Water/dust protection IP 66 and NEMA‑4X
Environmental EN50130-5:1999 Alarm systems Part 5
Test Method (Class 4 Outdoor in general)
Ordering information
NDN-921-V03-P FlexiDomeHD 720p
1/3-inch Dome, HD 720p, H.264, Motion+, PoE
Order number
NDN-921-V03-P
NDN-921-V03-IP FlexiDomeHD 720p
1/3-inch Dome, HD 720p, H.264, IVA enabled, PoE
Order number
NDN-921-V03-IP
NDN-921-V03-PS FlexiDomeHD 720p
1/3-inch Dome, HD 720p, H.264, Motion+, PoE,
Surface mount
Order number
NDN-921-V03-PS
NDN-921-V03-IPS FlexiDomeHD 720p
1/3-inch Dome, HD 720p, H.264, IVA enabled, PoE,
Surface mount
Order number
NDN-921-V03-IPS
Accessories
VDA-WMT-DOME Wall Pendant Mount Bracket
Wall pendant mount bracket for FlexiDome cameras
Order number
VDA-WMT-DOME
VDA-CMT-DOME Corner Mount Bracket
Corner mount bracket for FlexiDome cameras
Order number
VDA-CMT-DOME
VDA-PMT-DOME Pendant Pipe Mount Bracket
Pendant pipe mount bracket for FlexiDome cameras
Order number
VDA-PMT-DOME
LTC 9213/01 Pole Mount Adapter
Pole mount adapter with stainless steel straps, light
gray finish
Order number
LTC 9213/01
UPA-2410-60 Power Supply
120 VAC, 60 Hz, 24 VAC, 10 VA Out
Order number
UPA-2410-60
UPA-2430-60 Power Supply
120 VAC, 60 Hz, 24 VAC, 30 VA Out
Order number
UPA-2430-60
UPA-2450-60 Power Supply, 120 V, 60 Hz
Indoor, 120 VAC, 60 Hz In; 24 VAC, 50 VA Out
Order number
UPA-2450-60
UPA-2420-50 Power Supply
220 VAC, 50 Hz, 24 VAC, 20 VA Out
Order number
UPA-2420-50
UPA-2450-50 Power Supply, 220 V, 50 Hz
Indoor, 220 VAC, 50 Hz In; 24 VAC, 50 VA Out
Order number
UPA-2450-50
