5 | NDN-921 FlexiDomeHD 720p Day/Night IP Camera
Current Consumption 550 mA | 700 mA IVA (12 VDC)
550 mA | 700 mA IVA (24 VAC)
200 mA (PoE 48 VDC)
Power Consumption 6.6 W | 8.4 W IVA (12 VDC)
8.2 W | 10.4 W IVA (24 VAC)
9.6 W (PoE 48 VDC)
Sensor
Type 1/3-inch CCD
Active Pixels 1280 x 960
Network Video Output
Video compression H.264 (ISO/IEC 14496-10); M-JPEG,
JPEG
Streaming Four individually configurable streams in
H.264 and M-JPEG, configurable frame
rate and bandwidth.
Two independently Stream 1:
configurable H.264 H.264 Main Profile (MP) 720p 25/30
streams Stream 2:
H.264 Baseline Profile plus (BP+)
or
H.264 MP Standard Definition (SD),
or
Copy of stream 1
Two additional streams M-JPEG stream
and
High Definition (HD) I‑frame only
stream.
Data rate 9.6 Kbps to 10 Mbps
HD Resolution (H x V) 720p: 1280 x 720
480p Resolution (H x V) Encoding: 704 x 480
Displayed: 854 x 480
240p Resolution (H x V) Encoding: 352 x 240
Displayed: 432 x 240
Overall IP Delay Min. 120 ms, Max. 240 ms
GOP structure IP, IBP, IBBP
Sensitivity (3200 K, scene reflectivity 89%)
Minimum illumination (30 IRE)
Color 1 lx
Color + SensUp 10x 0.1 lx
Monochrome 0.4 lx
Monochrome + 0.04 lx
SensUp 10x
Day/Night Color, Mono, Auto
Pre-configured modes 6 preset programmable modes
Dynamic range 70 dB
Dynamic engine XF-Dynamic, SmartBLC
SmartBLC On / Off
AGC AGC On or Off (0 - 35 dB) selectable
White Balance ATW (2500 to 10000K), ATWhold and
manual
Shutter Auto (1/50 [1/60] to 1/10000) selectable
Auto (1/50 [1/60] to 1/50000) automatic
Fixed selectable
Sensitivity up Adjustable from Off up to 10x
Auto Black Automatic continuous, Off
Dynamic Noise Auto, On/off selectable
Reduction
Sharpness Sharpness enhancement level selectable
Privacy Masking Four independent areas, fully
programmable
Video Motion Analysis Motion+ or IVA
Test Pattern Generator Color bars 100%, Grayscale 11-step,
Sawtooth 2H, Checker board, Cross hatch,
UV plane
Synchronization Internal, Line Lock, HV-lock and Genlock
(Burst lock) selectable
Audio
Standard G.711, 8kHz sampling rate
L16, 16kHz sampling rate
Signal-to-noise ratio > 50 dB
Audio Streaming Full duplex
Input/output
Audio 1 x mono line in, 1 x mono line out
• signal line in 9 kohm typical, 5.5 Vpp max
• signal line out 3.0 Vpp at 10 kOhm typical,
2.3 Vpp at 32 Ohm typical,
1.7 Vpp at 16 Ohm typical
Alarm 1 non-isolated closing contact
• activation +5 VDC to +40 VDC
voltage (+3.3 VDC with DC-coupled 22 kOhm pull-
up resistor)
Relay 1 output
• voltage 30 VAC or +40 VDC
Maximum 0.5 A continuous, 10VA
