X8SIA/X8SIA-F User's Manual
Number LED
40 LE1
15
LE7
Jumper
Number
JPUSB1
47
JBT1
33
JI C1/JI
17
2 2
JPG1
16
JPL1/JPL2
6, 7
JPB
13
LED Indicators
Description
Onboard Standby PWR LED
IPMI Heartbeat LED
Jumpers
Description
USB0/1 Wake-up
CMOS Clear
C2 SMB to PCI Slots
Onboard VGA Enable
LAN1//LAN2 Enable
BMC Jumper
Color/State
Green: Solid on
Yellow: Blinking
1-6
Status
PWR On
IPMI: Normal
Default
Pins 1-2 (Enabled)
(See Chpt. 2)
(See Chpt. 2)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 2-3 (Disabled)
