Page 1: Quick Start Guide
SY-7IZB+N Motherboard Quick Start Guide Tested To Comply With FCC Standards FOR HOME OR OFFICE USE 100% POST CONSUMER RECYCLED PAPER... - Page 2 Our customers should ensure that their use of our products does not infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or assist others to infringe upon such rights.
- Page 3 SY-7IZB+N Quick Start Guide Introduction Congratulations on your purchase of the SY-7IZB+N Motherboard. This Quick Start Guide describes the steps for installing and setting up your new Motherboard. This guide is designed for all users to provide the basic steps of Motherboard setting and operation.
-
Page 4: Sy-7Izb+N Motherboard Layout
SY-7IZB+N Quick Start Guide SY-7IZB+N Motherboard Layout USB1 PS/2 Mouse Connector JP10 Connector Flash BIOS Winbond 83977 ATX Power AT Power COM 1 COM 2 JP44 PRT 1 AGP Slot PCI Slot #4 PCI Slot #2 PCI Slot #3 PCI Slot #1... -
Page 5: Installation
Follow the directions in this section designed to guide you through a quick and correct installation of your new SY-7IZB+N Motherboard. For detailed information, please refer to SY-7IZB+N Motherboard User's Guide and Technical Reference online manual included on the CD-ROM packed with your Motherboard. -
Page 6: Install The Motherboard
SY-7IZB+N Quick Start Guide Install the Motherboard Follow the steps below in order to perform the installation of your new SY-7IZB+N Motherboard. Install the CPU Step 1. Mark your CPU Frequency: Record the working frequency of your CPU that should be clearly marked on the CPU cover. - Page 7 Front Panel Devices (ACPI LED, Internal Speaker, Reset Button, IDE LED, and KeyLock Switch.), Wake-On-LAN card, VGA card, Sound Card, and other devices. For more details on how to connect internal and external peripherals to your new SY-7IZB+N Motherboard, please refer to SY-7IZB+N Motherboard User's Guide and Technical Reference online manual on CD-ROM.
-
Page 8: Memory Configuration Table
You do not need to set any jumper for the CPU frequency. Instead, CPU settings are changed through the BIOS [SOYO COMBO SETUP]. Please refer to Chapter 3 - Quick BIOS Setup for details on how to set the Celeron processor frequency. - Page 9 SY-7IZB+N Quick Start Guide Enable/Disable the Keyboard Power-On (JP10) Step 6. You can choose to enable the Wake-Up by Keyboard or Mouse function by shorting pin 1-2 on jumper JP1, otherwise, short pin 2-3 to disable this function. Support Power-On...
- Page 10 Press the <Del> key during the system diagnostic checks to enter the Award BIOS Setup program. From the BIOS main menu, select [SOYO COMBO SETUP] and move the cursor to the [CPU Frequency] field to set the proper working frequency.
-
Page 11: Quick Bios Setup
This Motherboard does not use any hardware jumpers to set the CPU frequency. Instead, CPU settings are software configurable with the BIOS [SOYO COMBO SETUP]. The [SOYO COMBO SETUP] menu combines the main CPU parameters that you need to configure, all in one menu, for a quick setup in BIOS. - Page 12 The SOYO CD will auto-run, and the SOYO CD Start Up Menu will be as shown. If you use Windows NT, the SOYO-CD will not detect your motherboard type. In that case the following dialog will pop up, please choose your motherboard and press OK. Now the SOYO-CD Start Up Menu will be shown.
- Page 13 SY-7IZB+N Quick Start Guide The user's manual files included on the SOYO CD are in PDF (Postscript Document) format. In order to read a PDF file, the appropriate Acrobat Reader software must be installed in your system. Note: The Start Up program automatically detects if the Acrobat Reader utility is already present in your system, and otherwise prompts you on whether or not you want to install it.
- Page 14 Select which driver you want to install and click OK, or click Cancel to abort the driver installation and return to the main menu. Note: Once you have selected a driver, the system will automatically exit the SOYO CD to begin the driver installation program. When the installation is complete, most drivers require to restart your system before they can become active.
- Page 15 Quick Trouble shoot tips Video (no display) related issues I built a new computer system using a Soyo board and nothing happens when turning it on, no video and no beeps from the PC speaker. What is happening and how can it be fixed? No screen and no beeps mean that your CPU and motherboard do not work at all.
-
Page 16: Audio Issues
IV motherboard with 2AA2 bios. Where can I find the latest BIOS of my motherboard? Please go to the technical support page of one of the SOYO websites (Taiwan: www.soyo.com.tw ), and look up your motherboard to find the latest BIOS revision. - Page 17 If you are running a Cyrix CPU, make sure the 'linear burst function' is enabled in the bios. I can not get my board to run properly. Please make sure you have the latest bios and driver from the SOYO web site at: http://www.soyo.com...
- Page 18 SY-7IZB+N Quick Start Guide How to contact us: If you are interested in our products, please contact the SOYO sales department in the region you live. If you require Technical Assistance, please contact our Technical Support in the region you live.
- Page 19 SY-7IZB+N Quick Start Guide Hong Kong Soyo (H.K.) Ltd. 5C, Big Star Centre, 8 Wang Kwong Road, Kowloon Bay, Kowloon, HK TEL: 852-2710-9810 FAX: 852-2710-9078 http://www.soyo.com.hk/ Email: soyo@hkstar.com...
- Page 20 Edition: June 2001 Version 1.2 SY-7IZB+N SERIAL...
