  • Page 1: Quick Start Guide

    SY-5EMA+ ™ Super 7 Mainboard Quick Start Guide Tested To Comply With FCC Standards FOR HOME OR OFFICE USE 100% POST CONSUMER RECYCLED PAPER...

  • Page 2: Atx Form Factor

    Our customers should ensure that their use of our products does not infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or assist others to infringe upon such rights.
  • Page 3 SY-5EMA+ Quick Start Guide Introduction Congratulations on your purchase of the SY-5EMA+ PCI/AGP Mainboard. This Quick Start Guide describes the steps for installing and setting up your new mainboard. This guide is designed for all users to provide the basic steps of mainboard setting and operation.

  • Page 4: Sy-5Ema+ Mainboard Layout

    SY-5EMA+ Quick Start Guide SY-5EMA+ Mainboard Layout PS/2 Mouse PS/2 KB Connector Connector P .B. SRAM USB1 USB2 64Kx64 JP30 P .B. SRAM 64Kx64 (Optional) TAG 32Kx8 JP44 IDE 2 IDE 1 ETEQ EQ82C6638 Header DIMM 1 DIMM3 DIMM 2 AGP Slot PCI Slot #1 Lithium...

  • Page 5: Installation

    Follow the directions in this section designed to guide you through a quick and correct installation of your new SY-5EMA+ Super 7 ™ Mainboard. For detailed information, please refer to SY-5EMA+ Mainboard User's guide and Technical Reference online manual included on the CD-ROM packed with your Mainboard.

  • Page 6: Install The Mainboard

    SY-5EMA+ Quick Start Guide Install the Mainboard Follow the steps below in order to perform the installation of your new SY-5EMA+ Super 7 ™ Mainboard. Step 1. Install the CPU To mount the Pentium ® class processor that you have purchased separately, follow these instructions.
  • Page 7 SY-5EMA+ Quick Start Guide Step 2. Set JP30 ,JP1 and JP2 for CPU Voltage JP30 is used to set the CPU core voltage, JP1 and JP2 are used to select the CPU voltage type single voltage or dual voltage. Please verify the correct voltage settings with your dealer before installation. Use the following table to set JP30, JP1 and JP2 to the proper voltage value according to the specifications marked on your CPU: Voltage Setting: JP30...
  • Page 8 SY-5EMA+ Quick Start Guide Step 3. Set SW1 for CPU Frequency The DIP switch SW1 enable you to assign the Multiplier and Bus Clock, as shown in the following table: Frequency Setting: SW1 Processor Multiplier JP10 JP8 Clock AMD K5 PR100 1.5x 66MHz AMD K5 PR133...

  • Page 9: Memory Configuration Table

    SY-5EMA+ Quick Start Guide JP8 is used to indicate the frequency of the CPU bus clock to the ETEQ chipset. JP9 and JP10 are used to determine that the SDRAM is running at the frequency of the CPU bus clock or the AGP clock. CPU BUS AGP BUS SDRAM...

  • Page 10: Cmos Clear

    SY-5EMA+ Quick Start Guide Step 5. Attach Connectors This section tells how to connect internal peripherals and power supply to the Mainboard. Internal peripherals include IDE devices (HDD, CD-ROM), Floppy Disk Drive, Chassis Fan, Front Panel Devices (Turbo LED, Internal Speaker, Reset Button, IDE LED, and KeyLock Switch.), Wake-On-LAN card, VGA card, Sound Card, and other devices.

  • Page 11: Quick Bios Setup

    SY-5EMA+ Quick Start Guide Quick BIOS Setup After the hardware installation is complete, turn the power switch on, then press the <DEL> key during the system diagnostic checks to enter the Award BIOS Setup program. The CMOS SETUP UTILITY will display on screen. Then, follow these steps to complete the quick BIOS setup.
  • Page 12 Mainboards and other products. Step 1. Insert the SOYO CD into the CD-ROM drive The SOYO CD will auto-run, and the SOYO CD Start Up Menu will display as shown below. (SOYO CD Start Up Program Menu) The SOYO CD Start Up Program automatically detects which SOYO Mainboard you own and displays the corresponding model name.
  • Page 13 SY-5EMA+ Quick Start Guide Please note that if the Start Up program was unable to determine which SOYO Mainboard you own, the manual selection menu will pop up, as shown below. Then select the user's manual file that corresponds to your Mainboard model name and click OK.
  • Page 14 (top to bottom). If you want to see all the drivers available on the SOYO –CD, click the Display all drivers on the SOYO CD button. Do NOT install drivers that are not suitable for you board, otherwise your system may crash.
  • Page 15 SY-5EMA+ Quick Start Guide Step 4. Enter the SOYO CD Click the Enter SOYO CD button to enter the SOYO HTML database. The Start Up program will activate the default HTML browser installed on your system (for example, Internet Explorer or Netscape) to visualize the contents of the SOYO CD.
  • Page 16 International Headquarters Edition: Sep. 1998 Soyo Computer Inc., (Taiwan) Version 1.1 Tel: 886-2-2290-3300 Fax: 886-2-2298-3322 5EMA+ SERIAL Web Site: http://www.soyo.com.tw E-mail: info@mail.soyo.com.tw USA Branch Office Soyo Tek Inc., (USA) Tel: (408) 452-7696 Fax: (408) 573-7696 Web Site: http://www.soyousa.com E-mail: sales@soyousa.com SOYO Europe Soyo Europe B.V., (Holland)
