- Page 1 FUSION ™ 8-Drive Serial ATA Disk Array Storage System with Dual Port Multipliers Drive Enclosure User’s Guide Windows...
-
Page 2: Specifications
Fusion D800P2 Enclosure Specs and Features Specifications Compatibility Compatible with Mac ® Windows , and Linux ® ® computers with compatible Drive Tray host adapter installed (Bay 1) Interface Connectors 2 x locking eSATA Drive Tray (Bay 2) Drives Supported 3 & 1.5 Gb/s Serial ATA; Drive Tray 7,200 RPM (Bay 3) Power Supply 100–240V AC, 50/60Hz Drive Tray (Bay 4) Drive Presence (top) Operating Temperature 32 to 95˚ F... -
Page 3: Safety Precautions
DEGRADE SYSTEM RELIABILITY AND PERFORMANCE. Check the Sonnet Web site for the latest list of qualified hard drives. • Do not expose the device to rain, use it near water or containers... -
Page 4: Drive Installation And Enclosure Setup
6. Connect the supplied power cable between the Fusion D800P2 and a grounded wall outlet or power strip; verify the cable is Figure 5 plugged in securely. - Page 5 Fax: 1-949-457-6349 E-mail: support@sonnettech.com • If you remove a module from the Fusion D800P2 with a drive that was part of a RAID set, you should power off the enclosure For Customers Outside the USA before reinserting the module.
- Page 6 ©2010 Sonnet Technologies, Inc. All rights reserved. Sonnet, the Sonnet logotype, Simply Fast, the Simply Fast logotype, Creativity Stored Here, and Fusion are trademarks of Sonnet Technologies, Inc. Macintosh, Mac, the Mac logo, and Mac OS are trademarks of Apple Inc., registered in the United States and other countries. Other product names are trademarks of their respective owners. Product specifications subject to change without...
