2.0 General Overview

===============================================================
This software controls a CPE (Customer Premises Equipment) unit and/or an AP
(Access Point) unit, and acts as a router between a user and an Internet Service Provider.
The software allows for 1 Ethernet card and 1 radio card on the device.
Before configuring the software settings, it is extremely important to properly design and
setup your network. Without proper network implementation, the software and hardware
will not operate at peak efficiency, or in some improper configurations, not at all.
Routing requires proper network subnetting with proper network segmentation. Diagram
1.0 outlines one such network implementation. The accompanying descriptions detail
this implementation.
