Teletronics International WL-CPE-ROUTER User Manual

Wireless customer premises router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
W
L
-
C
P
E
-
R
O
U
T
E
R
W
L
-
C
P
E
-
R
O
U
T
E
R
Wireless Customer Premises Router

USER MANUAL

CPE Firmware v2.16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WL-CPE-ROUTER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Teletronics International WL-CPE-ROUTER

  • Page 1: User Manual

    Wireless Customer Premises Router USER MANUAL CPE Firmware v2.16...

  • Page 2: Table Of Contents

    Teletronics International Inc. CPE Complete User Manual INDEX Contents Page =============================================================== 1.0 Minimum Requirements………………………………………………..…….. 2 2.0 General Overview…………………………………………………….….…… 3 3.0 Network Implementation…………………………………………………..…. 4 4.0 User Interface……………………………………………………………….… 6 5.0 Changing the Admin Password……………………………………….…….… 8 5.1 Setting up the CPE as a CPE……………………………………….….

  • Page 3: Minimum Requirements

    Teletronics International Inc. CPE Complete User Manual 1.0 Minimum Requirements =============================================================== System Requirements • Computer system running Win9x, NT, 2000 • Internet Explorer 4.x with 128 bit high encryption (Cookies Enabled) Or Netscape 6.x (Cookies Enabled) • Network Interface card •...

  • Page 4: General Overview

    Teletronics International Inc. CPE Complete User Manual 2.0 General Overview =============================================================== This software controls a CPE (Customer Premises Equipment) unit and/or an AP (Access Point) unit, and acts as a router between a user and an Internet Service Provider. The software allows for 1 Ethernet card and 1 radio card on the device.

  • Page 5: Network Implementation

    Teletronics International Inc. CPE Complete User Manual 3.0 Network Implementation =============================================================== Diagram 3.0 • From this point onward an Access Point will be designated AP and a Customer Premises Equipment will be designated CPE. Page 4 of 27...
  • Page 6 Teletronics International Inc. CPE Complete User Manual Description of Diagram 3.0 A. At point A, a station router has access to the Internet though a public IP address. It has an internal IP of 192.168.1.1. It will route incoming information, destined for 192.168.2.x and 192.168.3.x to the AP's Ethernet IP address of 192.168.1.2 (subnet...

  • Page 7: User Interface

    Teletronics International Inc. CPE Complete User Manual 4.0 User Interface =============================================================== The user interface for the CPE is browser based. The factory default IP for the CPE is 192.168.1.1. You can interface with the device by connecting the CPE to your computer via the Ethernet port and typing the following IP address into your Internet browser and pressing enter, (Please note that you are accessing a secure site -- use https, not http).
  • Page 8 Teletronics International Inc. CPE Complete User Manual With the configuration utility, you will be able to setup the CPE as a CPE, setup the CPE as an AP, and setup IPs, gateways, subnets, and routes. Clicking on the side options will take you to a variety of menus which include,...

  • Page 9: Changing The Admin Password

    Teletronics International Inc. CPE Complete User Manual 5.0 Changing the Admin Password =============================================================== The password can be modified once you are logged in. To do this, click on the Change Admin Password option on the main CPE Configuration Utility menu.

  • Page 10: Setting Up The Cpe As A Cpe

    Teletronics International Inc. CPE Complete User Manual 5.1 Setting up the CPE as a CPE =============================================================== • The following explanation and screen shots will demonstrate how to set the CPE as a CPE. The IP addressing explained in this section will reflect the IP addressing as seen in Diagram 3.0.
  • Page 11 Teletronics International Inc. CPE Complete User Manual Step 4: Setting up the ether1 adapter. Click on the default IP (192.168.1.1) to modify it. The default values will appear in the IP, Net Mask, and Comment fields. Make your modifications, and then click on the Modify button.
  • Page 12 Teletronics International Inc. CPE Complete User Manual Step 6: Select Static and Default Routes option from the menu on the left. enter the values into the fields as in the below screen shot. Click on the Create button when you have finished, and then click the Save button at the top left of the screen.

  • Page 13: Setting Up The Cpe With Teletronics 2Mbps Wireless Nic

    Teletronics International Inc. CPE Complete User Manual 5.2 Setting up the CPE with Teletronics 2Mbit Wireless NIC • The following explanation and screen shots will demonstrate how to set the CPE with the Teletronics 2Mbit Wireless Network Card. If your wireless card is not manufactured by Teletronics, please move to the appropriate section for your card.

  • Page 14: Setting Up The Cpe With Raylink 2Mbps Wireless Nic

    Teletronics International Inc. CPE Complete User Manual 5.3 Setting up the CPE with RayLink 2Mbit Wireless NIC • The following explanation and screen shots will demonstrate how to set the CPE with the RayLink 2Mbit Wireless Network Card. If your wireless card is not manufactured by RayLink, please move to the appropriate section for your card.

  • Page 15: Setting Up The Cpe With Prism Ii 11Mbps Wireless Nic

    Teletronics International Inc. CPE Complete User Manual 5.4 Setting up the CPE with PrismII 11Mbit Wireless NIC • The following explanation and screen shots will demonstrate how to set the CPE with the PrismII 11Mbit Wireless Network Card. If your wireless card is not based on the PrismII chipset, please move to the appropriate section for your card.
  • Page 16 Teletronics International Inc. CPE Complete User Manual Step 9.2: (Optional) The PrismII Wireless Network Card has the ability to send and receive encrypted transmissions. This function allows only CPEs and APs with appropriate keys to communicate and disallows unauthorized use. The following procedure will provide details on how to use this function.
  • Page 17 Teletronics International Inc. CPE Complete User Manual Step 10: Click on the Activate button at the top of the screen. This will save all of your settings and activate any changes you have made to the default settings. Clicking on Save and Reboot will have the same effect. You have completed the setup of the CPE as a CPE.

  • Page 18: Setting Up The Cpe As An Access Point

    Teletronics International Inc. CPE Complete User Manual 6.0 Setting up the CPE as an Access Point =============================================================== • The following explanation and screen shots will demonstrate how to set the CPE as an AP. The IP addressing explained in this section will reflect the IP addressing as seen in Diagram 3.0.
  • Page 19 Teletronics International Inc. CPE Complete User Manual Step 4: Setting up the ether1 adapter. Click on the default IP (192.168.1.1) to modify it. The default values will appear in the IP, Net Mask, and Comment fields. Make your modifications, and then click on the Modify button.
  • Page 20 Teletronics International Inc. CPE Complete User Manual Step 6: Select Static and Default Routes option from the menu on the left. Enter the values into the fields as in the below screen shot. Click on the Create button when you have finished, and then click the Save button at the top left of the screen.
  • Page 21 Teletronics International Inc. CPE Complete User Manual Step 9: Select Slot 1, under the Configure Wireless Adapter option, from the CPE Configuration Menu on the left. There are 2 different Wireless Network Cards supported by the CPE Configuration Utility Software that can be placed in Access Point Mode.

  • Page 22: Setting Up The Cpe As An Ap With Teletronics 2Mbps Wireless Nic

    Teletronics International Inc. CPE Complete User Manual 6.1 Setting up the CPE as an AP with Teletronics 2Mbit Wireless NIC • The following explanation and screen shots will demonstrate how to set the CPE with the Teletronics 2Mbit Wireless Network Card. If your wireless card is not manufactured by Teletronics, please move to the appropriate section for your card.

  • Page 23: Additional Functions With Teletronics 2Mbps Wireless Nic

    Teletronics International Inc. CPE Complete User Manual 6.11 Additional Functions with Teletronics 2Mbit Wireless NIC: • An additional feature of using the Teletronics 2Mbit Wireless NIC in the CPE in AP mode is that the AP can determine signal strength of stations connected to the AP.

  • Page 24: Setting Up The Cpe As An Ap With Prism Ii 11Mbps Wireless Nic

    Teletronics International Inc. CPE Complete User Manual 6.2 Setting up the CPE as an AP with PrismII 11Mbit Wireless NIC • The following explanation and screen shots will demonstrate how to set the CPE with the PrismII 11Mbit Wireless Network Card. If your wireless card is not based on the PrismII chipset, please move to the appropriate section for your card.
  • Page 25 Teletronics International Inc. CPE Complete User Manual Step 9.3: (Optional) The PrismII Wireless Network Card has the ability to send and receive encrypted transmissions. This function allows only CPEs and APs with appropriate keys to communicate and disallows unauthorized use. The following procedure will provide details on how to use this function.
  • Page 26 Teletronics International Inc. CPE Complete User Manual Step 10: Click on the Activate button at the top of the screen. This will save all of your settings and activate any changes you have made to the default settings. Clicking on Save and Reboot will have the same effect. You have completed the setup of the CPE as an AP.

  • Page 27: Updating The Cpe Firmware

    Teletronics International Inc. CPE Complete User Manual 7.0 Updating the CPE Firmware =============================================================== Updating the CPE firmware is an option on the main menu of the CPE Configuration Utility. The version of your CPE firmware can be determined by looking at the top of the CPE Configuration Utility.
  • Page 28 Teletronics International Inc. CPE Complete User Manual CPE Firmware upgrade utility version 1.02-win32 Windows port - Aug 21, 2001. BETA MD5 Checksum for this file: 6cefdf7df87bee06884b5af845e71438 Connected: CPE is currently running firmware version 2.13-pr2 Sending firmware, please wait..[##################################################] - 8028160 (7840K) Firmware has been sent.
