  • Page 1 W E B E D I T I O N O W N E R ' S M A N U A L...
  • Page 3 Volvo is one of the safest cars in mation contained in this owner's manual. the world. Your Volvo has also been designed to satisfy all current safety and environmental requirements.

  • Page 4: Table Of Contents

    ISOFIX - types of child seat...... 49 Volvo ID............. 19 Safety - warning symbol......28 Child seats - upper mounting points..51 Volvo Cars' environmental philosophy..21 Airbag system........... 29 The owner's manual and the environ- Driver airbag..........30 ment............23 Passenger airbag........
  • Page 5 Trip computer - supplementary informa- Approach lighting........91 Symbols in the display......70 tion............118 Headlamps - adjusting headlamp pat- Volvo Sensus..........73 Trip computer - trip statistics*....119 tern............92 Key positions..........74 Wipers and washing........96 Key positions - functions at different lev- Power windows.........
  • Page 6 Table of contents 04 Climate control 05 Loading and storage General information on climate control... 121 Air distribution - table......134 Storage spaces........145 Actual temperature......... 122 Engine and passenger compartment Tunnel console........147 heater*............. 136 Sensors - climate control......122 Tunnel console - cigarette lighter and Engine block heater and passenger com- ashtray*...........
  • Page 7 Table of contents 06 Locks and alarm 07 Driver support Remote control key......... 155 Keyless drive* - interference to remote Active chassis - Four C*......181 control key function........ 168 Remote control key - losing ....155 Electronic stability control (ESC) - gen- Keyless drive* - locking......
  • Page 8 Table of contents Adaptive cruise control* - overtaking Collision warning system* - detection of Park assist syst* - backward....235 another vehicle........196 cyclists............ 217 Park assist syst* - forward...... 236 Adaptive cruise control* - deactivate..197 Collision warning system* - detection of Park assist syst* - fault indication...
  • Page 9 Table of contents 08 Starting and driving Alcolock*..........247 Start/Stop* - the engine does not stop... 271 Filling up with fuel........289 Alcolock* - functions and operation..247 Start/Stop* - the engine auto-starts..272 Fuel - handling........290 Alcolock* - storage........248 Start/Stop* - the engine does not auto- Fuel - petrol..........
  • Page 10 Table of contents 09 Wheels and tyres 10 Maintenance and service Tyres - direction of rotation....306 TPMS (Tyre Pressure Monitoring Volvo service programme....... 338 System)* - recommendations....321 Tyres - maintenance....... 306 Book service and repair*......338 TPMS (Tyre Pressure Monitoring Tyres - tread wear indicators....
  • Page 11 Table of contents 11 Specifications Lamp replacement - number plate light- Rustproofing........... 382 Type designations........387 ing............357 Cleaning the interior........ 382 Dimensions..........390 Lamp replacement - lighting in cargo Paint damage.......... 384 Weights........... 391 area............357 Towing capacity and towball load..392 Lamp replacement - vanity mirror light- Engine specifications......
  • Page 12 Table of contents 12 Alphabetical Index Alphabetical Index........408...
  • Page 13 Table of contents...
  • Page 14 I N T R O D U C T I O N...

  • Page 15: 01 Introduction

    Volvo's recommendations in the owner's information. In the event of uncertainty over what is stand- ard or an option/accessory, contact a Volvo If there should be a difference between the dealer. information on the screen and in the prin-...
  • Page 16 01 Introduction Warning for personal injury Risk of property damage IMPORTANT "Important" texts appear if there is a risk of damage. NOTE NOTE texts give advice or tips that facili- tate the use of e.g. features and functions. Footnote There is footnote information in the owner's manual that is located at the bottom of the page.
  • Page 17 01 Introduction Information Related information When there is a series of illustrations for step-by-step instructions each step is Related information refers to other sections numbered in the same way as the corres- containing related information. ponding illustration. Images There are numbered lists with letters The manual's images are sometimes sche- adjacent to the series of illustrations matic and may deviate from the car's appear-...

  • Page 18: Digital Owner's Manual In The Car

    01 Introduction • Digital owner's manual in the car Search - Search function for finding an Search article. The owner's manual can be read on the • Categories - All articles sorted into cate- screen in the car . The content is searchable gories.
  • Page 19 01 Introduction Categories Navigating in an article 3. To change the input mode to numbers or special characters, or to perform a The articles in the owner's manual are struc- search, turn TUNE to one of the options tured into main categories and subcategories. (see explanation in the following table) in The same article can be in several appropri- the list for changing the input mode (2),...

  • Page 20: Recording Data

    This informa- Certain information about the vehicle's opera- The incorrect connection and installation of tion may be stored by Volvo as long as it can tion and functionality, and any incidents, are accessories and extra equipment can nega- help to further develop and further enhance recorded in the car.

  • Page 21: Information On The Internet

    The positioning of electronic equipment, such With a personal Volvo ID it is possible to log in Examples of services: as a transponder, behind a glass surface with to My Volvo web, which is a personal web •...
  • Page 22 It is possi- ble to create a Volvo ID via one of the follow- ing services: • My Volvo web - Enter your e-mail address and follow the instructions.

  • Page 23: Volvo Cars' Environmental Philosophy

    Your Volvo complies with strict international environmental standards and is also manufac- Efficient emission control Environmental care is one of Volvo Car Cor- for our partners so that they work systemati- poration's core values which influence all cally with environmental issues.
  • Page 24 Interior • • The owner's manual and the environment The interior of a Volvo is designed to be plea- If the car is equipped with an engine (p. 23) sant and comfortable, even for people with block heater*, use it before starting from contact allergies and for asthma sufferers.

  • Page 25: The Owner's Manual And The Environment

    The windscreen and the side windows* shows that the paper pulp in a printed have laminated glass. ® owner's manual comes from FSC certified forests or other controlled sources. Related information • Volvo Cars' environmental philosophy (p. 21) Option/accessory, for more information, see Introduction.
  • Page 26 S A F E T Y...

  • Page 27: 02 Safety

    Never modify or repair the seatbelts your- The hip strap must be positioned low down (not self. Volvo recommends that you contact over the abdomen). an authorised Volvo workshop. It is important that the seatbelt lies against...

  • Page 28: Seatbelt - Putting On

    02 Safety Seatbelt - putting on Seatbelt - loosening Put on the seatbelt (p. 25) before driving Loosen the seatbelt (p. 25) when the car is starts. stationary. Pull the belt out slowly and secure it by Press the red button on the seatbelt buckle pressing its locking tab into the seatbelt and then let the belt retract.

  • Page 29: Seatbelt - Pregnancy

    02 Safety Seatbelt - pregnancy Seatbelt reminder The aim should be to position the seat with as large a distance as possible between abdo- Seatbelt (p. 25) must always be worn during Unbelted occupants will be reminded to fas- men and steering wheel. pregnancy.

  • Page 30: Seatbelt Tensioner

    02 Safety Seatbelt tensioner Safety - warning symbol matically after driving for approximately 30 seconds or after pressing the indicator All the seatbelts (p. 25) are equipped with belt The warning symbol is shown if a fault is stalk OK button (p. 105). tensioners.

  • Page 31: Airbag System

    The symbol indicates a fault in the seatbelt ten- sioner system, SIPS, the IC system or some other fault in the system. Volvo rec- ommends that you contact an authorised Volvo workshop immediately. Airbag system viewed from above, right-hand- If the warning symbol malfunctions, the warn- drive car.

  • Page 32: Driver Airbag

    WARNING belt is not used or is used incorrectly, this may diminish the protection provided by Volvo recommends that you contact an the airbag in the event of a collision. authorised Volvo workshop for repair. Defective work in the airbag system could...

  • Page 33: Passenger Airbag

    02 Safety Passenger airbag To supplement the protection afforded by the seatbelt (p. 25) on the passenger side, the car is equipped with an airbag (p. 29). The airbag is folded up into a compartment above the glovebox. Its cover panel is marked AIRBAG.

  • Page 34: Passenger Airbag - Activating/ Deactivating

    02 Safety Passenger airbag - activating/ never children in a child seat or on a WARNING deactivating* booster cushion. Do not put objects in front of or above the Front passenger airbag (p. 31) can be deacti- The airbag is deactivated. With the switch dashboard where the passenger airbag is vated if the car is equipped with a switch, in this position, children in a child seat or...
  • Page 35 This indicates that there has been a severe malfunction. Visit a workshop as soon as possible. Volvo recommends that you contact an authorised Volvo workshop.

  • Page 36: Side Airbag (Sips)

    • Volvo recommends that repairs are the collision force is transferred by the SIPS only carried out by an authorised Volvo (Side Impact Protection System) to beams, workshop. Defective work in the SIPS- pillars, the floor, the roof and other structural bag system could cause malfunction parts of the body.

  • Page 37: Side Airbag (Sips) - Child Seat/Booster Cushion

    This could compromise the intended that the car does not have an activated airbag protection. Volvo recommends that you (p. 32) on the front passenger side. only ever use Volvo genuine parts that are approved for placement in these areas. Related information •...

  • Page 38: General Information On Whips (Whiplash Protection)

    This reduces the risk of whiplash injury. WARNING Never modify or repair the seat or WHIPS system yourself. Volvo recommends that you contact an authorised Volvo work- shop. Related information • WHIPS - child seats (p. 37) •...

  • Page 39: Whips - Child Seats

    02 Safety WHIPS - child seats WHIPS - seating position WARNING The protection provided by the car to children For optimum protection from the WHIPS sys- Do not squeeze rigid objects between the seated in a child seat or on a booster cushion tem (p.

  • Page 40: When The Systems Deploy

    02 Safety When the systems deploy WARNING System Triggered In the event of a collision Volvo's different If a seat has been subjected to extreme Inflatable Curtain In the event of a personal safety systems work together in forces, such as due to a rear-end collision, IC (p.

  • Page 41: General Information On Safety Mode

    Recovering the car. Volvo recommends that you have it con- veyed to an authorised Volvo workshop. WARNING Never drive with deployed airbags. They Warning triangle in the digital combined instru- can make steering difficult.

  • Page 42: Safety Mode - Attempting To Start The Car

    If the car is in safety mode it must not be towed. It must be transported from its If everything seems normal and you have location. Volvo recommends that it is checked for indications of fuel leakage, you transported to an authorised Volvo work- may attempt to start the car.

  • Page 43: Safety Mode - Moving The Car

    Regulations regarding the placement of children in cars vary from country to coun- try. Check what does apply. Volvo has child safety equipment (child seats, booster cushions & attachment devices) which is designed for your particular car. Using Volvo's child safety equipment pro- vides you with optimum conditions for your child to travel safely in the car.

  • Page 44: Child Seats

    02 Safety Child seats NOTE Children should sit comfortably and safely. When using child safety products it is Make sure that the child seat is being used important to read the installation instruc- correctly. tions included. WARNING Do not secure the straps of the child seat to the seat's horizontal adjustment bar, springs or the rails and beams under the seat.
  • Page 45 Weight Front seat (with deactivated airbag) Outer rear seat Centre rear seat Group 0 Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, secured with the ISOFIX fixture sys- max 10 kg tem. Group 0+ Type approval: E1 04301146...
  • Page 46 Weight Front seat (with deactivated airbag) Outer rear seat Centre rear seat Group 1 Volvo rear-facing/turnable child seat (Volvo Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-facing child Convertible Child Seat) - rear-facing child seat, 9-18 kg seat, secured with the car's seatbelt and secured with the car's seatbelt and straps.
  • Page 47 Type approval: E5 04216 (UF) (UF) (UF) Group 2/3 Volvo booster seat with backrest (Volvo Volvo booster seat with backrest (Volvo Booster Volvo booster seat with backrest Booster Seat with backrest). Seat with backrest). (Volvo Booster Seat with 15-36 kg backrest).

  • Page 48: Child Seats - Location

    02 Safety Child seats - location WARNING Always fit child seats/booster cushions (p. 42) Never place a child in a child seat or on a in the rear seat if the passenger airbag is acti- booster cushion in the front seat if the air- vated (p.

  • Page 49: Child Seat - Isofix

    02 Safety • Child seat - ISOFIX ISOFIX - size classes General information on child safety (p. 41) ISOFIX is a fixture system for car child seats There is a size classification for child seats (p. 42) that is based on an international stand- using the ISOFIX (p.
  • Page 50 If an ISOFIX child seat has no size classifi- cation, the car model must be included on the vehicle list for the child seat. NOTE Volvo recommends that you contact an authorised Volvo dealer for recommenda- tions about which ISOFIX child seats Volvo recommends.

  • Page 51: Isofix - Types Of Child Seat

    02 Safety ISOFIX - types of child seat seats are suitable for all seats in all car mod- els. Child seats are in different sizes – cars are in different sizes. This means that not all child Type of child seat Weight Size class Passenger seats for ISOFIX installation of child seats...
  • Page 52 IUF: Suitable for front-facing ISOFIX child seats that are universally approved in this weight class. Volvo recommends rear-facing child seats for this group. Make sure you select the right size class (p. 47) of child seat with ISOFIX (p. 47) fixture...

  • Page 53: Child Seats - Upper Mounting Points

    The upper mounting points are primarily intended for use with front-facing child seats. Volvo recommends that small children should sit in rear-facing child seats for as long as possible. For detailed information on how the child seat...
  • Page 54 I N S T R U M E N T S A N D C O N T R O L S...

  • Page 55: 03 Instruments And Controls

    03 Instruments and controls Instruments and controls, left-hand drive car - overview The overview shows where the car's displays and controls are located.
  • Page 56 03 Instruments and controls Overview, left-hand drive cars...
  • Page 57 03 Instruments and controls Function Function Function Menus and mes- (p. 105), Hazard warning (p. 88). Seat adjustment* (p. 77). sages, direction (p. 107), flashers Headlamp control, (p. 81), indicators, main/ (p. 89), Door handle – opener for fuel filler (p.

  • Page 58: Instruments And Controls, Right-Hand Drive Car - Overview

    03 Instruments and controls Instruments and controls, right-hand drive car - overview The overview shows where the car's displays and controls are located.
  • Page 59 03 Instruments and controls Overview, right-hand drive cars...
  • Page 60 03 Instruments and controls Function Function Function Hazard warning (p. 88). Headlamp control, (p. 81), Control panel for cli- (p. 127). flashers opener for fuel filler (p. 289) and mate control flap and boot lid (p. 173). Screen for infotain- (p.

  • Page 61: Combined Instrument Panel

    03 Instruments and controls Combined instrument panel Analogue combined instrument panel Gauges and indicators - overview The combined instrument panel's information display shows information on some of the The combined instrument panel's information car's functions, as well as messages. display shows information on some of the car's functions, e.g.

  • Page 62: Digital Combined Instrument Panel - Overview

    03 Instruments and controls Digital combined instrument panel - Functionality check Tachometer. The meter indicates engine overview speed in thousands of revolutions per All indicator and warning symbols, apart from minute (rpm). symbols in the centre of the information dis- The combined instrument panel's information play, illuminate in key position II or when the display shows information on some of the...
  • Page 63 03 Instruments and controls Gauges and indicators Geartronic* (p. 261) or Automatic gear- box -- Powershift* (p. 265). Alternative themes can be selected for the digital combined instrument panel. Possible themes are "Elegance", "Eco" and "Performance". A theme can only be selected when the engine is running.
  • Page 64 03 Instruments and controls Indicator and warning symbols Tachometer. The meter indicates engine Speedometer speed in thousands of revolutions per Tachometer. The meter indicates engine minute (rpm). speed in thousands of revolutions per Gear shift indicator /Gear position indica- minute (rpm). .

  • Page 65: Eco Guide & Power Guide

    03 Instruments and controls Eco guide & Power guide* Functionality check Instantaneous value All indicator and warning symbols, apart from The instantaneous value is shown here - the Eco guide and Power guide are two com- symbols in the centre of the information dis- higher the reading on the scale, the better.

  • Page 66: Combined Instrument Panel - Meaning Of Indicator Symbols

    Low level in fuel tank the car's emissions system. Drive to a work- shop for checking. Volvo recommends that you seek assistance from an authorised Volvo workshop. Power is dependent on engine speed. Option/accessory, for more information, see Introduction.
  • Page 67 Volvo recommends that you Related information tion display. The message text is cleared with seek assistance from an authorised Volvo • Combined instrument panel (p. 59) the OK button, see Menu navigation - com- workshop.

  • Page 68: Combined Instrument Cluster - Meaning Of Warning Symbols

    The warning symbols alert the driver that an engine immediately and check the engine oil Visit a workshop. Volvo recommends that you important function is activated, or that a seri- level, top up if necessary. If the symbol illumi- seek assistance from an authorised Volvo ous error or a serious failure has occurred.
  • Page 69 The loss of brake fluid must be investiga- (p. 350). If one of the doors is not closed properly then ted by a workshop. Volvo recommends the information or warning symbol illuminates If the brake and ABS symbols illuminate at...

  • Page 70: Outside Temperature Gauge

    03 Instruments and controls Outside temperature gauge Trip meter Related information • Combined instrument panel (p. 59) The display for the outside temperature gauge The trip meter display appears in the com- • appears in the combined instrument panel. bined instrument panel. Combined instrument panel - meaning of indicator symbols (p.

  • Page 71: Clock

    The Portions of this product uses software following text is Volvo's agreement with the copyrighted © 2007 The FreeType Project manufacturer/developer. (www.freetype.org). All rights reserved.

  • Page 72: Symbols In The Display

    03 Instruments and controls Symbols in the display MIT License: http: http://opensource.org/ Symbol Specification licenses/mit-license.html There are a variety of different symbols in the Parking brake (p. 66) • display in the car. The symbols are divided ・ Lua applied, alterna- into warning, indicator and information sym- tive symbol bols.
  • Page 73 03 Instruments and controls Symbol Specification Symbol Specification Symbol Specification Rear fog lamp on (p. 64), ECO function* on (p. 64), Windscreen sen- (p. 85), (p. 87) (p. 277) sor*, Camera sen- (p. 214), sor*, Laser sen- (p. 223), Stability system, (p.
  • Page 74 03 Instruments and controls Information symbols in the roof console Symbol Specification Symbol Specification display Start/Stop* (p. 275) Engine block (p. 140) Symbol Specification heater and pas- senger compart- Seatbelt reminder (p. 27) ment heater* Start/Stop* (p. 275) Service required Airbag, passenger (p.

  • Page 75: Volvo Sensus

    Volvo Sensus is the heart of your personal Navigation* - NAV, see separate supple- Volvo experience. It is Sensus that provides With a press on MY CAR all settings related ment (Sensus Navigation).

  • Page 76: Key Positions

    03 Instruments and controls Key positions Key positions - functions at different the remote control key in the ignition switch. levels The remote control key can be used to set the 2. Then press the remote control key in the vehicle's electrical system in different modes/ In order to enable the use of a limited number lock up to its end position.
  • Page 77 03 Instruments and controls Choosing key position/level Towing Level Functions • Key position 0 - Unlock the car - This For important information about the remote • Odometer, clock and tem- means that the car's electrical system is control key during towing, see Towing at level 0.

  • Page 78: Seats, Front

    03 Instruments and controls Seats, front Raising takes place in reverse order. WARNING The car's front seats have different setting Adjust the position of the driver's seat WARNING options for optimum seating comfort. before setting off, never while driving. Make sure that the seat is in locked posi- Grasp the backrest and make sure that it tion in order to avoid personal injury in the is properly locked after being folded up in...

  • Page 79: Seats, Front - Electrically Operated

    03 Instruments and controls Seats, front - electrically operated* Store setting object. If this should happen, set the car's electrical system in key position I or 0 and Memory button The car's front seats have different setting wait a short time before adjusting the seat options for optimum seating comfort.

  • Page 80: Seats, Rear

    03 Instruments and controls Seats, rear Emergency stop 2. Fold the backrest forward. Lower the centre head restraint fully if the backrest's If the seat accidentally begins to move, press The rear seat backrest and the outer seat wide section shall be lowered. one of the setting buttons for the seat or head restraints can be folded.

  • Page 81: Steering Wheel

    03 Instruments and controls Steering wheel Electrical lowering of the rear seat's Related information • outer head restraints* Seats, front (p. 76) The steering wheel can be adjusted in differ- • ent positions and has controls for horn and Seats, front - electrically operated* (p. 77) cruise control, as well as menu, audio and phone control.

  • Page 82: Heating* Of The Steering Wheel

    03 Instruments and controls Heating* of the steering wheel 3. Push back the lever to fix the steering Paddle for manual gear changing in an wheel in place. If the lever is stiff, press automatic gearbox, see Automatic gear- The steering wheel can be heated with elec- the steering wheel lightly at the same time box -- Geartronic* (p.

  • Page 83: Light Switches

    03 Instruments and controls Light switches Knob positions approx. 10 °C. Activate/deactivate the func- tion in the menu system MY CAR (p. 108). The headlamp control activates and adjusts Posi- Specification the external lighting. It is also used to adjust tion display and instrument lighting and mood lighting (p.
  • Page 84 Main beam can be activated. Main beam flash can be used. Fitted in or under the front bumper. Volvo recommends that mode is used when the car is being driven, as long as traffic situations or weather conditions are unfavour- able for the Active high beam* function.

  • Page 85: Position/Parking Lamps

    03 Instruments and controls Position/parking lamps Daytime running lights WARNING Position/parking lamps are switched on with With the knob for headlamp control in This system help to save energy - it cannot the headlamp control's knob. position, and the car's electrical system in key determine in all situations when daylight is position II or the engine running, the daytime too weak or sufficiently strong, e.g.

  • Page 86: Tunnel Detection

    03 Instruments and controls Tunnel detection* Main/dipped beam Dipped beam Tunnel detection changes the lighting from With the knob for headlamp control in posi- With the knob in position, dipped beam daytime running lights to dipped beam when is activated automatically at twilight or when tion and the car's electrical system in the car is driven into a tunnel.

  • Page 87: Active High Beam

    When main beam is switched on the symbol also illuminates in the combined instrument panel. Auxiliary lamps must be connected to the electrical system by a workshop. Volvo recommends that you contact an authorised Volvo workshop. Option/accessory, for more information, see Introduction.
  • Page 88 03 Instruments and controls Car with digital combined instrument panel AHB may be temporarily unavailable e.g. in IMPORTANT situations with dense fog or heavy rain. When When AHB is activated the symbol Examples of when manual switching AHB becomes available again, or the wind- between main and dipped beam may be turns white in the instrument's information screen sensors are no longer blocked, the...

  • Page 89: Active Xenon Headlamps

    Headlamp The system is system disengaged. Visit malfunc- a workshop if the message tion Serv- remains. Volvo recommends required that you contact an authorised Volvo workshop. Button for rear fog lamp. The function is only active in twilight or dark- ness and only when the car is moving.

  • Page 90: Brake Lights

    03 Instruments and controls Brake lights Hazard warning flashers the headlamp control's knob is turned to position The brake light automatically comes on during The hazard warning flashers warn other road braking. users by means of all of the car's direction NOTE indicator lamps flashing simultaneously when The brake light is switched on when the brake...

  • Page 91: Direction Indicators

    03 Instruments and controls Direction indicators again or the button is depressed. For more The stalk switch remains in its position and is information on emergency brake lights and moved back manually, or automatically by the The car's direction indicators are operated automatic hazard warning flashers, see Foot steering wheel movement.

  • Page 92: Interior Lighting

    03 Instruments and controls Interior lighting Front roof lighting Automatic lighting The front reading lamps are switched on or The switch for passenger compartment light- The passenger compartment lighting is acti- off by pressing the relevant button in the roof ing has three positions for the lighting in the vated/deactivated with the buttons in the con- console.

  • Page 93: Home Safe Light Duration

    03 Instruments and controls Home safe light duration Approach lighting The passenger compartment lighting comes on and remains on for two minutes if one of Home safe lighting consists of dipped beam, Approach lighting consists of parking lamps, the doors is open. parking lamps, lamps in the door mirrors, lamps in the door mirrors, number plate light- number plate lighting, interior roof lighting as...

  • Page 94: Headlamps - Adjusting Headlamp Pattern

    03 Instruments and controls Headlamps - adjusting headlamp Active Xenon headlamps* set to the adjusted position, see preceding pattern illustration. The headlamp pattern must be adjusted to Example 2 avoid dazzling oncoming motorists and can A car that is delivered in the UK is designed be set for right or left-hand traffic.
  • Page 95 03 Instruments and controls Masking the headlamps 1. Copy the A and B templates for left-hand drive cars or the C and D templates for right-hand drive cars, see the later sec- tion "Templates for halogen headlamps": • A = LHD Right (left-hand drive, right lens) •...
  • Page 96 03 Instruments and controls Upper row: left-hand drive cars, templates A and B. Lower row: right-hand drive cars, templates C and D.
  • Page 97 03 Instruments and controls Templates for halogen headlamps...

  • Page 98: Wipers And Washing

    03 Instruments and controls Wipers and washing Intermittent wiping detects on the windscreen. The sensitivity of the rain sensor can be adjusted using the Set the number of sweeps per time Wipers and washers clean the windscreen thumbwheel. unit with the thumbwheel when and rear window.

  • Page 99: Power Windows

    03 Instruments and controls Power windows The rain sensor is automatically deactivated The windscreen wipers will make several when the remote control key is removed from more sweeps and the headlamps are washed All power windows can be operated using the the ignition switch or five minutes after the once the stalk switch has been released.
  • Page 100 03 Instruments and controls Operating with auto All power windows can be operated using the WARNING control panel for the driver's door - the con- Move one of the controls up/down to the end Check that children or other passengers trol panels for the other doors can only each position and release it.

  • Page 101: Sun Blind

    03 Instruments and controls Sun blind* Door mirrors Sun blinds are built into the panel on each The door mirror positions are adjusted with rear door. the joystick in the driver's door controls. There is a sun blind built into the rear parcel shelf.
  • Page 102 03 Instruments and controls The function can be activated/deactivated in 2. Release them after WARNING the menu system MY CAR, see MY CAR approximately 1 second. The mirrors Both mirrors are the wide-angle type to (p. 108). automatically stop in the fully retracted provide optimal vision.

  • Page 103: Windows And Rearview And Door Mirrors - Heating

    03 Instruments and controls Windows and rearview and door Rearview mirror - interior cally after a certain time. Following which, mirrors - heating rear window heating is switched on and off The interior rearview mirror can be dimmed automatically as long as the outside tempera- The defroster is used to quickly remove mist- with a control in the mirror's lower edge.

  • Page 104: Compass

    03 Instruments and controls Compass* for manual dimming is not available on mir- side of the mirror using a paper clip for exam- rors with automatic dimming. ple. The rearview mirror contains an integrated display that shows the compass direction in The rearview mirror contains two sensors - Calibration which the front of the car is pointing.

  • Page 105: Sunroof

    03 Instruments and controls Sunroof* 7. Cars with heated windscreen*: If the character is shown in the display when The sunroof can be operated with a control in the heated windscreen is activated, per- the roof panel. form the calibration in accordance with The sunroof's inner sunscreen is closed man- point 6 above with the heated windscreen ually.
  • Page 106 03 Instruments and controls Opening Closing using the remote control key or WARNING For maximum sunroof opening, move the central locking button If there are children in the car: control back to the position for automatic Remember to always switch off the power opening and release.

  • Page 107: Menu Navigation - Combined Instrument Panel

    03 Instruments and controls Menu navigation - combined Pinch protection instrument panel The sunroof's pinch protection function is triggered if it is blocked by an object during The left-hand stalk controls the menus automatic closing. If blocked, the sunroof will (p.

  • Page 108: Menu Overview - Combined Instrument Panel

    03 Instruments and controls Menu overview - combined Messages Parking heater * instrument panel When a warning, information or indicator Trip computer reset Which menus are shown in the combined symbol illuminates, a corresponding message appears on the information display. instrument panel's information display Related information depends on the key position (p.

  • Page 109: Messages - Handling

    An authorised Volvo workshop is recommended. possible. must be read (press OK) before the previ- For more information regarding the automatic gearbox, see ous activity can be resumed.

  • Page 110: My Car

    03 Instruments and controls MY CAR vary, depending on the equipment selected and the market. MY CAR is a menu source that handles many MY CAR - opens the menu system MY of the car's functions, e.g. City Safety™, locks CAR.

  • Page 111: Trip Computer

    03 Instruments and controls Trip computer Menu options and search paths Group menus For a description of the menu options and The trip computer has two different group The car's trip computer can record, calculate search paths in MY CAR, see the Sensus menus: and show information while driving.

  • Page 112: Trip Computer - Analogue Combined Instrument Panel

    03 Instruments and controls Trip computer - analogue combined Functions instrument panel Proceed as follows to open and check/adjust functions: The trip computer's menu is in a variable 1. To ensure that no control is in the middle loop. One of the alternatives is that the trip of a sequence - "Reset"...
  • Page 113 03 Instruments and controls Functions Information Digital speed Shows the car's speed digitally in the centre of the combined instrument panel: • • Open with OK, select with the thumbwheel, confirm with OK and back out with ENTER. km/h • •...
  • Page 114 03 Instruments and controls Functions Information For more information, see Engine oil - checking and filling (p. 346). Oil level Messages (##) For more information, see Messages - handling (p. 107). Certain engines. Headings 1. To ensure that no control is in the middle 3.
  • Page 115 03 Instruments and controls Average speed - shown in the combined instrument panel: • Give a long press on RESET - selected heading is zeroed. Each heading must be zeroed individually. Related information • Trip computer (p. 109) • Trip computer - supplementary informa- tion (p.

  • Page 116: Trip Computer - Digital Combined Instrument Panel

    03 Instruments and controls Trip computer - digital combined Functions instrument panel Proceed as follows to open and check/adjust functions: The trip computer's menu is in a variable 1. To ensure that no control is in the middle loop. One of the alternatives is that the trip of a sequence - "Reset"...
  • Page 117 03 Instruments and controls Functions Information Trip computer reset Note that this function does not reset both trip meters T1 and T2 - see table under next section "Headings" and section "Resetting - Average speed/consumption" for information on the proc- •...
  • Page 118 03 Instruments and controls Headings One of the heading combinations in the fol- lowing table can be selected for constant dis- play in the combined instrument panel. Pro- ceed as follows to determine which: 1. To ensure that no control is in the middle of a sequence - "Reset"...
  • Page 119 03 Instruments and controls Resetting - Average speed/ consumption Trip computer 1. Select function reset and activate with OK. 2. Select one of the following options with the thumbwheel and activate with OK: • l/100 km • km/h • Reset both 3.

  • Page 120: Trip Computer - Supplementary Information

    In addition to in the trip computer, these • In which case, refuel as soon as possible. the last resetting. units are also changed in Volvo's naviga- The calculation is based on the average fuel tion system*. NOTE consumption over the last 30 km and the There may be a slight error in the reading if remaining driveable fuel quantity.

  • Page 121: Trip Computer - Trip Statistics

    03 Instruments and controls Trip computer - trip statistics* Operation Different settings can be made in the menu Information is stored about completed trips system MY CAR, see MY CAR (p. 108) - containing average fuel consumption and Trip statistics there, find average speed, which can be viewed in the centre console's screen as a bar chart.
  • Page 122 C L I M A T E C O N T R O L...

  • Page 123: 04 Climate Control

    04 Climate control General information on climate temporary increase in temperature in the Related information control passenger compartment. • Actual temperature (p. 122) • Remove misting on the insides of the win- • The car is equipped with electronic climate Menu settings - climate control (p.

  • Page 124: Actual Temperature

    04 Climate control Actual temperature Sensors - climate control Air cleaning The temperature you select in the passenger The climate control system has a number of The interior in a passenger compartment is compartment corresponds to the physical sensors to help control the temperature designed to be pleasant and comfortable, experience with reference to factors such as (p.

  • Page 125: Air Cleaning - Passenger Compartment Filter

    The filter must be replaced at regular inter- stances. 75 000 km over 5 years. In cars without vals. Follow the Volvo Service Programme for CZIP and where the customer does not the recommended replacement intervals. If The following is included: want to keep the CZIP standard the IAQS filter must be changed at a regular service.

  • Page 126: Air Cleaning - Iaqs

    MY CAR (p. 101). agents and car care products recommended (p. 108). • Interior air quality system (p. 124)*. by Volvo to clean the interior (p. 382). • Automatic start of seat heating driver NOTE Related information (p. 128).

  • Page 127: Air Distribution In The Passenger Compartment

    04 Climate control Air distribution in the passenger Air vents in the dashboard Air vents in the door pillars compartment The incoming air is divided between a number of different vents in the passenger compart- ment. Closed Closed Open Open Lateral airflow Lateral airflow Air distribution is fully automatic in AUTO...
  • Page 128 04 Climate control Air distribution The selected air distribution is shown in the cen- tre console display screen. Air distribution - defroster windscreen Related information Air distribution - air vent instrument panel • General information on climate control (p. 121) Air distribution - ventilation floor •...

  • Page 129: Electronic Climate Control - Ecc

    04 Climate control Electronic climate control - ECC compartment and can be set separately for The auto function is used to automatically the driver's side and passenger side. control temperature, air conditioning, fan ECC (Electronic Climate Control) maintains speed, recirculation and air distribution. the temperature selected in the passenger Temperature control (p.

  • Page 130: Heated Front Seats

    04 Climate control • Heated front seats* Heated rear seat* Lowest heat level - one orange field illu- minates in the screen. The front seat heating has three positions for The heating for the rear seat's outer positions • Switch off the heat - no field illuminates. increasing the comfort for driver and passen- has three positions for increasing the comfort ger when it is cold.

  • Page 131: Ventilated Front Seats

    04 Climate control Ventilated front seats* For button location, see the WARNING illustration (p. 127). The ventilation can be used at the same time Heated seats must not be used by people as seat heating. For example, the function can Press the button repeatedly who find it difficult to perceive an increase be used to dry damp from clothing.

  • Page 132: Fan

    04 Climate control Auto-regulation Temperature control in the passenger compartment The fan should always be activated in order to The auto function automatically regulates avoid misting on the windows. temperature (p. 130), air conditioning When the car is started, the most recent tem- (p.

  • Page 133: Air Conditioning

    04 Climate control Air conditioning Demisting and defrosting the Related information • windscreen General information on climate control The air conditioning cools and dehumidifies (p. 121) incoming air as required. Heated windscreen* and max. defroster are • Actual temperature (p. 122) used to quickly remove misting and ice from When the lamp in the AC the windscreen and side windows.

  • Page 134: Air Distribution - Recirculation

    04 Climate control Air distribution - recirculation For cars without heated windscreen: NOTE Select recirculation to shut out bad air, • Air flows to the windows - symbol (2) illu- Electrically heated windscreen is not avail- exhaust gases etc. from the passenger com- minates in the screen.
  • Page 135 04 Climate control NOTE When max. defroster is selected, recircula- tion is always deactivated. Related information • General information on climate control (p. 121) • Air distribution in the passenger compart- ment (p. 125) • Air distribution - table (p. 134)

  • Page 136: Air Distribution - Table

    04 Climate control Air distribution - table Three buttons are used to select the distribu- tion (p. 125) of the air. Air distribution Air to windows. Some air flows from the air vents. The air is not to remove ice and misting quickly. recirculated.
  • Page 137 04 Climate control Air distribution Air to the floor and windows. Some air flows from the dashboard to ensure comfortable conditions and good demisting in air vents. cold or humid weather. Air to floor and from dashboard air vents. in sunny weather with cool outside temperatures. Air to floor.

  • Page 138: Engine And Passenger Compartment Heater

    04 Climate control Engine and passenger compartment Refuelling appears on the information display. Acknowl- heater* edge the message by pressing the indicator stalk (p. 105) OK button once. Preconditioning prepares the car's heater, engine and passenger compartment before IMPORTANT departure so that both wear and energy needs during the journey are reduced.

  • Page 139: Engine Block Heater And Passenger Compartment Heater* - Direct Start

    Indicator lamp on remote control key with PCC*. settings that can be managed from a mobile Heating of the passenger compartment will phone will be available via the Volvo On Call* begin as soon as the engine coolant has The engine block heater and passenger com- mobile app.

  • Page 140: Engine Block Heater And Passenger Compartment Heater* - Immediate Stop

    04 Climate control Engine block heater and passenger Engine block heater and passenger 6. Briefly press OK to move to the flashing compartment heater* - immediate compartment heater* - timer minutes setting. stop The timer of the engine block and passenger 7.
  • Page 141 04 Climate control Parking 2. Scroll with the thumbwheel to heater and select with OK. > If a timer is set but not activated then a clock icon is shown beside the set time. 3. Select one of the two timers using the thumbwheel and confirm with OK.

  • Page 142: Engine Block Heater And Passenger Compartment Heater* - Messages

    04 Climate control Engine block heater and passenger When one of the timers has been activated, Symbol for activated timer in digital compartment heater* - messages the symbol for activated timer illuminates in combined instrument panel. the display at the same time as the set time is Symbols and display messages regarding the shown next to the symbol.
  • Page 143 Low fuel level starting the engine as well as approx. 50 km driving. Fuel operated heater Service Heater not working. Contact a workshop for repair. Volvo recommends that you contact an required authorised Volvo workshop. A display text clears automatically after a time or after one press on the indicator stalk (p.

  • Page 144: Additional Heater

    1. Before starting the engine: Select key position I (p. 74). An authorised Volvo dealer has information regarding the geographical areas concerned. An authorised Volvo dealer has information regarding the engines concerned. Analogue combined instrument panel. Digital combined instrument panel.

  • Page 145: Electric Additional Heater

    04 Climate control Electric additional heater* The car is equipped with either a fuel-driven (p. 142) or an electric additional heater (p. 142). The heater cannot be controlled manually, but is instead activated automatically after the engine has been started in outside tempera- tures below 14 °C and is switched off after the set passenger compartment temperature has been reached.
  • Page 146 L O A D I N G A N D S T O R A G E...

  • Page 147: 05 Loading And Storage

    05 Loading and storage Storage spaces Overview of storage spaces in the passenger compartment.
  • Page 148 05 Loading and storage Storage compartment in door panel Storage pocket* on front edge of front seat cushions Ticket clip Glovebox (p. 147) Storage compartment Storage compartment, cup holder (p. 147) Cup holder* in armrest, rear seat Storage pocket WARNING Keep loose objects such as mobile phones, cameras, remote controls for accessories, etc.

  • Page 149: Tunnel Console

    05 Loading and storage Tunnel console Tunnel console - cigarette lighter and Glovebox ashtray* The tunnel console is located between the The glovebox is located on the passenger front seats. A detachable ashtray is fitted in the cup side. holder under the armrest. The cigarette lighter is fitted in the 12 V socket (p.

  • Page 150: Inlay Mats

    Inlay mats collect e.g. rubbish and slush. The vanity mirror is located on the rear of the The electrical sockets (12 V) are located next Volvo supplies specially manufactured inlay sun visor. to the cup holder and rear of the tunnel con- mats.

  • Page 151: Loading

    The compressor for emergency puncture boot lid (p. 173). repair (p. 325) has been tested and Optional equipment and accessories - e.g. approved by Volvo. display screens, music players and mobile WARNING phones - which are connected to one of the passenger compartment's 12V electri- The car’s driving properties change...

  • Page 152: Loading - Long Load

    05 Loading and storage • Loading - long load Cover sharp edges with something soft to Related information avoid damaging the upholstery. • Load retaining eyelets (p. 152) To simplify loading (p. 149) in the cargo area, • Secure all loads to the load retaining eye- •...

  • Page 153: Loading - Ski Hatch

    The load carriers recommended for roof loads Release the hatch in the rear seat back- transport long narrow items. are the ones developed by Volvo. This is in rest by sliding the bolt up while pressing order to avoid damage to the car and in order the hatch down/forward.

  • Page 154: Load Retaining Eyelets

    05 Loading and storage Load retaining eyelets Loading - bag holder* WARNING The bag holder keeps carrier bags in place The folding load retaining eyelets are used to Hard, sharp and/or heavy objects which and prevents them from overturning and fasten straps in order to anchor items in the protrude may cause injury under violent spreading their contents across the cargo...

  • Page 155: 12 V Electrical Socket, Cargo Area

    12 V, e.g. display puncture repair has been tested and screens, music players and mobile phones. approved by Volvo. For information on the use of Volvo's recommended temporary emergency puncture repair (TMK), Emer- gency puncture repair* (p. 325).
  • Page 156 L O C K S A N D A L A R M...

  • Page 157: 06 Locks And Alarm

    The remaining remote control keys must be More remote control keys can be ordered - Remote control key in basic version and taken to the Volvo workshop. The code of the but not variants other than the one supplied Remote control key with PCC (Personal Car missing remote control key must be erased with the car.

  • Page 158: Remote Control Key - Personalisation

    06 Locks and alarm Remote control key - personalisation* Proceed as follows in order to store the set- WARNING tings and use the key memory in the remote The key memory in the remote control key Risk of crushing! Make sure that children control key: (p.

  • Page 159: Locking/Unlocking - Indicator

    06 Locks and alarm Locking/unlocking - indicator Immobiliser Seats, front - electrically operated* (p. 77). When the car is locked or unlocked using the The electronic immobiliser is a theft protec- • Adjust seat and door mirrors manually, remote control key (p. 155) the direction indi- tion system that prevents an unauthorised see Seats, front - electrically operated* cators confirm that locking/unlocking was...

  • Page 160: Remote-Controlled Immobiliser With Tracking System

    Functions starting - Remove the key liser to switch off the engine. from the ignition switch, press Contact your nearest Volvo dealer for more it in again and make a new information and assistance with activating the start attempt. system.
  • Page 161 06 Locks and alarm Related information Press and hold to open all windows simulta- • neously. For more information, see Total air- Remote control key (p. 155) ing function (p. 172). • Remote control key with PCC* - unique functions (p. 160) The function can be changed from unlocking •...

  • Page 162: Remote Control Key - Range

    06 Locks and alarm Remote control key - range Remote control key with PCC* - Related information • unique functions Remote control key (p. 155) Remote control key functions (in its basic ver- • sion) have a range of approx. 20 metres from A remote control key with PCC has enhanced Remote control key - functions (p.

  • Page 163: Remote Control Key With Pcc* - Range

    PCC), contact a the car for the information to be read then the been triggered since the car was locked. workshop - an authorised Volvo workshop status the car was last left in is shown, with- is recommended.

  • Page 164: Detachable Key Blade

    (p. 162) is carried out as follows: out. Removing the key blade The key blade's unique code is provided by authorised Volvo workshops, which are rec- ommended when ordering new key blades. Key blade functions Using the remote control key's detachable key blade: •...

  • Page 165: Detachable Key Blade - Unlocking Doors

    06 Locks and alarm Detachable key blade - unlocking Privacy locking* Related information • doors Detachable key blade - unlocking doors Privacy locking is intended for when the car is (p. 163) The detachable key blade (p. 162) can be left for service, with a hotel parking valet or •...
  • Page 166 06 Locks and alarm Activate/deactivate NOTE Do not reinsert the key blade into the remote control key, but keep it in a safe place instead. • Deactivation takes place in reverse order. For information on locking the glovebox only, see Locking/unlocking - glovebox (p. 172). Active locks for remote control key, without key blade and privacy locking activated.

  • Page 167: Remote Control Key - Replacing The Battery

    06 Locks and alarm Remote control key - replacing the NOTE battery Turn the remote control key over with the The battery for the remote control key may buttons facing up, this is to avoid the bat- need to be replaced. teries falling out when it is opened.

  • Page 168: Keyless Drive

    With the keyless starting and locking system NOTE the car can be started, locked and unlocked Volvo recommends that the batteries to be without the remote control key (p. 155) used in the remote control key/PCC fulfil inserted in the ignition switch. It is enough to...

  • Page 169: Keyless Drive* - Secure Handling Of The Remote Control Key

    06 Locks and alarm Keyless drive* - secure handling of When the remote control key has been remote control key , a remote control key the remote control key returned to the car, the warning message must be within approx. 1.5 metres from the goes off and the audible reminder ceases car's door handle or boot lid.

  • Page 170: Keyless Drive* - Interference To Remote Control Key Function

    06 Locks and alarm Keyless drive* - interference to Keyless drive* - locking Related information remote control key function • Keyless drive* (p. 166) Cars equipped with Keyless drive have a but- • Electromagnetic fields and screening can ton on the outer door handles for locking/ Alarm indicator (p.

  • Page 171: Keyless Drive* - Unlocking

    06 Locks and alarm Keyless drive* - unlocking Keyless drive* - unlocking with the 2. Then insert the key blade in the lock cyl- key blade inder and unlock the door. Unlocking takes place when a hand grasps a door handle or the boot lid's rubberised pres- If central locking cannot be unlocked with the 3.

  • Page 172: Keyless Drive* - Lock Settings

    06 Locks and alarm Keyless Drive* - lock settings Keyless Drive* - antenna location WARNING Lock settings for cars equipped with Keyless Cars equipped with Keyless Drive have a People with pacemaker operations should Drive can be adapted by indicating in the number of built-in antennas positioned at dif- not come closer than 22 cm to the keyless menu system MY CAR which doors are to be...

  • Page 173: Locking/Unlocking - From The Outside

    06 Locks and alarm Locking/unlocking - from the outside Locking/unlocking - from the inside WARNING Locking/unlocking from the outside is carried All of the doors and the tailgate are locked or Be aware of the risk of being locked in the out using the remote control key (p.

  • Page 174: Total Airing Function

    06 Locks and alarm • Total airing function Locking/unlocking - glovebox Pull the door handle once and release - the door is unlocked. Pull the door handle The total airing function opens or closes all The glovebox (p. 147) can only be locked/ again to open the door.

  • Page 175: Locking/Unlocking - Boot Lid

    06 Locks and alarm Locking/unlocking - boot lid Locking with the remote control key If the boot lid is not opened within two • minutes then it is relocked and the alarm is Press the remote control key (p. 158) but- The boot lid can be opened, locked and re-armed.

  • Page 176: Deadlocks

    06 Locks and alarm Deadlocks* Temporary deactivation Related information • Keyless drive* - unlocking with the key Deadlocks means that all lock buttons and blade (p. 169) door handles are mechanically disengaged, • which prevents doors being opened from Remote control key (p. 155) both inside and outside.

  • Page 177: Child Safety Locks - Manual Activation

    06 Locks and alarm Child safety locks - manual activation Child safety locks - electrical NOTE activation* The child safety locks prevent children from • A door's knob control only blocks that being able to open a rear door from the Child safety locks with electrical activation particular door - not both rear doors inside.

  • Page 178: Alarm

    In which case, is started. NOTE contact a workshop - an authorised Volvo Related information Do not attempt to repair or alter compo- workshop is recommended. •...

  • Page 179: Alarm Indicator

    06 Locks and alarm Alarm indicator Alarm - automatic re-arming Deactivating a triggered alarm – Press the remote control key unlock but- The alarm indicator shows alarm system Automatic re-arming of the alarm (p. 176) pre- ton or insert the remote control key in the (p.

  • Page 180: Alarm - Remote Control Key Not Working

    06 Locks and alarm Alarm - remote control key not Alarm signals Reduced alarm level working When the alarm (p. 176) is triggered a siren Reduced guard means that the movement If the alarm (p. 176) cannot be deactivated sounds and all direction indicators flash. and tilt detectors can be temporarily deacti- vated.

  • Page 181: Type Approval - Remote Control Key System

    06 Locks and alarm Type approval - remote control key Country/Area system China Type approval for the remote control key sys- tem can be read in the table. Lock system, standard Country/Area EU, China Hong Kong Keyless lock system (Keyless drive) Related information Country/Area •...
  • Page 182 D R I V E R S U P P O R T...

  • Page 183: 07 Driver Support

    07 Driver support Active chassis - Four C* Electronic stability control (ESC) - Operation general Active chassis "Four-C" (Continously Controlled Chassis Concept), regulates the Stability system ESC (Electronic Stability characteristics of the shock absorbers so that Control) helps the driver to avoid skidding and the car's driving characteristics can be improves the car's traction.

  • Page 184: Electronic Stability Control (Esc) - Operation

    07 Driver support Electronic stability control (ESC) - Spin Control Sport mode is indicated in the com- operation bined instrument panel by means of The function prevents the driving wheels from this symbol illuminating with a con- spinning against the road surface during Selection of level - Sport mode stant glow until the driver deselects acceleration.

  • Page 185: Electronic Stability Control (Esc) - Symbols And Messages

    Stop the car in a safe place, switch off the engine and start it again. • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. "Message" There is a text message in the combined instrument panel (p. 59) - Read it! Constant glow for System check when the engine is started.
  • Page 186 07 Driver support Related information • Electronic stability control (ESC) - general (p. 181) • Electronic stability control (ESC) - opera- tion (p. 182)

  • Page 187: Road Sign Information (Rsi)

    07 Driver support Road Sign Information (RSI)* Road sign information (RSI)* - WARNING operation The road sign information function (RSI – RSI does not work in all situations but is Road Sign Information) helps the driver to The road sign information function (RSI – designed merely as a supplementary aid.
  • Page 188 07 Driver support End of restriction or motorway Additional signs A corresponding road sign is shown in the combined instrument panel for approx. 10 seconds in situations where RSI detects a sign that involves the end of a speed limit - or other speed-related informa- tion, e.g.

  • Page 189: Road Sign Information (Rsi)* - Limitations

    07 Driver support Road sign information (RSI)* - Road sign information On/Off exceeded. The function can be activated/ deactivated in the menu system MY CAR. For limitations a description of the menu system, see MY The road sign information function (RSI – CAR (p.

  • Page 190: Cruise Control

    07 Driver support Cruise control* Cruise control* - managing speed WARNING The cruise control (CC – Cruise Control) helps It is possible to activate, set and change the The driver must always be observant with the driver maintain an even speed, resulting in stored speed.

  • Page 191: Cruise Control* Temporary Deactivation And Standby Mode

    07 Driver support • Cruise control* temporary Use short presses - each press gives Automatic standby mode +/- 5 km/h. deactivation and standby mode Cruise control is temporarily disengaged and set in standby mode if: To adjust +/- 1 km/h: The function can be temporarily deactivated and set in standby mode.

  • Page 192: Cruise Control* - Resume Set Speed

    07 Driver support Cruise control* - resume set speed Cruise control* - deactivate Adaptive cruise control - ACC* The cruise control (CC – Cruise Control) helps The adaptive cruise control (ACC – Adaptive How it is deactivated is described here. the driver to maintain an even speed.

  • Page 193: Adaptive Cruise Control* - Function

    Maintenance of adaptive cruise control • Radar sensor (p. 199) components must only be performed at a Radar sensor (p. 199) workshop - an authorised Volvo workshop • Radar sensor - limitations (p. 200) is recommended. • Adaptive cruise control* - fault tracing and action (p.
  • Page 194 07 Driver support The adaptive cruise control aims to follow the WARNING vehicle ahead in the same lane according to Adaptive cruise control is not a collision what the driver set for time interval (p. 195). If avoidance system. The driver must inter- the radar sensor cannot see any vehicle in vene if the system does not detect a vehi- front then the car will instead maintain the...

  • Page 195: Adaptive Cruise Control* - Overview

    07 Driver support • Adaptive cruise control* - overview Adaptive cruise control* - symbols and WARNING messages (p. 203) The adaptive cruise control only warns of vehicles which the radar sensor has detected. Hence the warning may not be given, or it may be given with a certain delay.

  • Page 196: Adaptive Cruise Control* - Managing Speed

    07 Driver support Adaptive cruise control* - managing At the same time a speed stored speed when the accelerator pedal is speed range is marked: released. To enable ACC: NOTE • Press the steering wheel button If any of the adaptive cruise control but- similar WHITE symbol illuminates in the tons are held depressed for several combined instrument panel (8) which...

  • Page 197: Adaptive Cruise Control* - Set Time Interval

    07 Driver support Adaptive cruise control* - set time Adaptive cruise control* - temporary NOTE interval deactivation, and standby mode Only use the time intervals permitted by The adaptive cruise control can be temporar- local traffic regulations. Different time intervals to the ily deactivated and set in standby mode.

  • Page 198: Adaptive Cruise Control* - Overtaking Another Vehicle

    07 Driver support Adaptive cruise control* - overtaking stored speed when the accelerator pedal is wheel button - the speed is then set to the another vehicle released. last stored speed. Automatic standby mode When the car is following another vehicle and NOTE The adaptive cruise control is dependent on the driver indicates an impending overtaking...

  • Page 199: Adaptive Cruise Control* - Deactivate

    07 Driver support Adaptive cruise control* - deactivate Adaptive Cruise Control* - queue With an automatic gearbox, the adaptive assistance cruise control can follow another vehicle With a short press on the steering wheel but- within the range 0-200 km/h. Queue assistance also provides the adaptive the adaptive cruise control is set in cruise control with enhanced functionality at...
  • Page 200 07 Driver support Queue assistance releases the foot brake and NOTE WARNING sets the adaptive cruise control in standby Queue Assist can hold the car stationary When the adaptive cruise control is follow- mode in the following situations: for a maximum of 4 minutes - then the ing another vehicle at speeds in excess of •...

  • Page 201: Adaptive Cruise Control* - Switch Cruise Control Functionality

    (spacing system) in the cruise control is • Contact a workshop - an authorised deactivated, at which point the car just fol- Volvo workshop is recommended. lows the set/stored speed. The function may completely or partially • Give a long press on the steering wheel...

  • Page 202: Radar Sensor - Limitations

    07 Driver support Radar sensor - limitations WARNING A radar sensor (p. 199) has certain limitations The driver must always be observant with - due to its limited field of vision for example. regard to the traffic conditions and inter- vene when the adaptive cruise control is The capacity of the adaptive cruise control to not maintaining a suitable speed or suita-...
  • Page 203 07 Driver support WARNING Adaptive cruise control is not a collision avoidance system. The driver must inter- vene if the system does not detect a vehi- cle in front. The adaptive cruise control does not brake for humans or animals, and not for small vehicles such as bicycles and motorcy- cles.

  • Page 204: Adaptive Cruise Control* - Fault Tracing And Action

    07 Driver support Adaptive cruise control* - fault tracing sensor (p. 199) cannot detect other vehicles sion Warning with Auto Brake (p. 215) are and action in front of the car. working. This message indicates that neither of the The following table presents examples of If the combined instrument panel shows the functions for Distance Alert (p.

  • Page 205: Adaptive Cruise Control* - Symbols And Messages

    07 Driver support Adaptive cruise control* - symbols are some examples - follow the recommenda- and messages tion given if appropriate: Sometimes the adaptive cruise control may display a symbol and/or text message. Here Symbol Message Specification The symbol is GREEN The car maintains the stored speed.
  • Page 206 The adaptive cruise control is disengaged. Service required • Contact a workshop - an authorised Volvo workshop is recommended. Press brake to hold vehi- The car is stationary and the cruise control will release the foot brake to allow the parking brake to take over and hold the car, but a fault in the parking brake means the car will shortly begin to roll.

  • Page 207: Distance Warning

    07 Driver support Distance Warning* tion is handled by the car's menu system MY NOTE CAR, MY CAR (p. 108) - once there, search Distance Warning (Distance Alert) is a function Distance warning is deactivated during the for the Distance Alert function..

  • Page 208: Distance Warning* - Limitations

    07 Driver support Distance Warning* - limitations The same symbol is also shown when Adap- tive cruise control (p. 191) is activated. Distance Warning (Distance Alert) is a function that informs the driver about the distance to NOTE vehicles in front. The function uses the same radar sensor as the Adaptive cruise control The higher the speed the longer the calcu- (p.

  • Page 209: Distance Warning* - Symbols And Messages

    Distance Warning and Collision Warning with Auto Brake fully or partially disengaged. Service required Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Symbols are schematic - may vary by market and car model. Related information •...

  • Page 210: City Safety

    - an authorised in the traffic ahead, combined with a lapse in of collision, City Safety™ will automatically Volvo workshop is recommended. attention, could lead to an incident. brake the car, which may be experienced as sudden braking.

  • Page 211: City Safety™ - Operation

    07 Driver support City Safety™ - operation When the function is activated and brakes, the combined instrument panel shows a text City Safety™ is a function for helping the message to the effect that the function is/has driver to avoid a collision when driving in been active.

  • Page 212: City Safety™ - Limitations

    07 Driver support City Safety™ - limitations tems will provide best possible braking force WARNING with maintained stability. The sensor in City Safety™ is designed to The laser sensor also transmits laser light detect cars and other large vehicles in front of When your own car is reversing, City Safety™...
  • Page 213 (see the illustration for sensor location The laser sensor field Remove the (p. 208)) - an authorised Volvo workshop is • Remove ice and snow from the bonnet of vision is blocked. blocking object.

  • Page 214: City Safety™ - Laser Sensor

    - an authorised tion) at a distance of 100 mm or closer Volvo workshop is recommended. It is abso- Radiation data for the laser sensor with magnifying optics such as a mag-...
  • Page 215 07 Driver support • The laser sensor must be fitted onto the windscreen before the sensor's connector is plugged in. • The laser sensor transmits a laser light when the remote control key is in key position II (p. 74) even if the engine is switched off.

  • Page 216: City Safety™ - Symbols And Messages

    Remove the object blocking the sensor and/or clean the windscreen in front of the sensor. Read about laser sensor limitations (p. 210). City Safety Service required City Safety™ is not operational. • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Related information • City Safety™ (p. 208) •...

  • Page 217: Collision Warning System

    "Collision Warning with Auto Brake and must only be performed at a workshop - Cyclist and Pedestrian Detection" must not an authorised Volvo workshop is recom- be used as an excuse for the driver to change mended. his/her driving style. If the driver solely relies...

  • Page 218: Collision Warning System* - Function

    07 Driver support Collision warning system* - function 1 - Collision warning If in this situation the driver has not yet started to take evasive action and the risk of The driver is first warned of a potentially collision is imminent then the automatic brak- imminent collision.

  • Page 219: Cyclists

    07 Driver support Collision warning system* - detection tours, directly from behind and in the car's cen- WARNING tre line. of cyclists The collision warning system does not Optimal performance of the system requires engage in all driving situations or traffic, that the system function that detects a cyclist weather or road conditions.

  • Page 220: Collision Warning System* - Detection Of Pedestrians

    07 Driver support • • Collision warning system* - detection The function's capacity to detect cyclists In order for a pedestrian to be detected is deactivated when driving in darkness of pedestrians he/she must appear full-length and have and tunnels - even when streetlights are a height of at least 80 cm.

  • Page 221: Collision Warning System* - Operation

    07 Driver support • Collision warning system* - operation Search for Warning distance Settings for the collision warning system are Collision Warning in the menu system made via the centre console's screen and the Warning signals On and Off MY CAR, MY CAR (p. 108) - and there menu system MY CAR, see MY CAR (p.

  • Page 222: Collision Warning System* - Limitations

    07 Driver support Collision warning system* - limitations Maintenance NOTE The function has certain limitations - for Even if the warning distance has been set example, it is not active until approx. 4 km/h. Long warnings could be perceived as being late in certain situations, e.g.

  • Page 223: Collision Warning System* - Camera Sensor Limitations

    07 Driver support Collision warning system* - camera Collision Warning with Auto Brake is tempo- WARNING sensor limitations rarily deactivated with reverse gear engaged. Warnings and brake interventions could be "Collision Warning with Auto Brake and Collision Warning with Auto Brake is not acti- implemented late or not at all if the traffic Cyclist and Pedestrian Detection"...
  • Page 224 Clean the wind- cleaned - an author- cles. surface in front of screen surface in ised Volvo work- the camera is dirty front of the camera shop is recom- The field of vision of the camera sensor is lim- or covered with ice from dirt, ice and mended.

  • Page 225: Collision Warning System* - Symbols And Messages

    07 Driver support Collision warning system* - symbols assist the driver when there is a risk of collid- and messages ing with a pedestrian, bicycle or vehicle in front that are stationary or moving in the same "Collision Warning with Auto Brake and direction.
  • Page 226 Collision Warning with Auto Brake is fully or partially disengaged. ice required • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Symbols are schematic - may vary by market and car model. Related information •...

  • Page 227: Driver Alert System

    07 Driver support Driver Alert Control (DAC)* Related information Driver Alert System* • Driver Alert Control (DAC)* (p. 225) The DAC function is intended to attract the The Driver Alert System is intended to assist • driver's attention when he/she starts to drive drivers whose driving ability is deteriorating or Lane Departure Warning (LDW)* (p.

  • Page 228: Driver Alert Control (Dac)* - Operation

    07 Driver support Driver Alert Control (DAC)* - operation For this reason it is always important to stop WARNING and take a break in the event of any signs of Settings are made from the centre console An alarm should be taken very seriously, driver fatigue, irrespective of whether or not display screen and its menu system.

  • Page 229: Driver Alert Control (Dac)* - Symbols And Messages

    Read about camera sensor limitations (p. 221). Driver Alert system Serv- The system is disengaged. ice required • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Symbols are schematic - may vary by market and car model. Display Sym- Message...
  • Page 230 07 Driver support Sym- Message Specification Driver Alert Standby <65 km/h The function is set in standby mode due to speed being lower than 65 km/h. Driver Alert Unavailable The carriageway does not have clear side markings or the camera sensor is temporarily disen- gaged.

  • Page 231: Lane Departure Warning (Ldw)

    07 Driver support Lane Departure Warning (LDW)* Lane Departure Warning (LDW) - NOTE function Lane Departure Warning is one of the func- The driver is only warned once each time tions in the Driver Alert System - sometimes Certain settings can be made for the Lane the wheels cross a line.

  • Page 232: Lane Departure Warning (Ldw) - Operation

    07 Driver support • Lane Departure Warning (LDW) - On at start-up - The function enters Related information standby mode every time the engine is operation • Lane Departure Warning (LDW)* (p. 229) started. Otherwise the same value as • LDW is complemented in the combined Lane Departure Warning (LDW) - limita- when the engine was switched off is...

  • Page 233: Lane Departure Warning (Ldw) - Limitations

    07 Driver support Lane Departure Warning (LDW) - limitations The Lane Keeping Aid camera sensor is restricted in a similar way to the human eye. For more information, read about camera sensor limitations (p. 221). NOTE There are some situations where LDW does not give any warning, such as: •...

  • Page 234: Lane Departure Warning (Ldw) - Symbols And Messages

    Read about camera sensor limitations (p. 221). Driver Alert system Service The system is disengaged. required • Visit a workshop if the message remains - an authorised Volvo workshop is recom- mended. Symbols are schematic - may vary by market and car model.
  • Page 235 07 Driver support Related information • Lane Departure Warning (LDW)* (p. 229) • Lane Departure Warning (LDW) - limita- tions (p. 231) • Lane Departure Warning (LDW) - function (p. 229) • Lane Departure Warning (LDW) - opera- tion (p. 230) Option/accessory, for more information, see Introduction.

  • Page 236: Park Assist

    07 Driver support Park Assist* Park assist syst* - function Related information • Park assist syst* - cleaning the sensors Parking assistance is used as an aid to park- The parking assistance system is automati- (p. 237) ing. An acoustic signal as well as symbols on cally activated when the engine is started - •...

  • Page 237: Park Assist Syst* - Backward

    07 Driver support Park assist syst* - backward The centre console's display screen shows IMPORTANT an overview of the relationship between the Parking assistance is used as an aid to park- Objects e.g. chains, thin glossy poles or car and detected obstacle. ing.

  • Page 238: Park Assist Syst* - Forward

    When reversing with e.g. a trailer or bike Front parking assistance is deactivated ing. An acoustic signal as well as symbols on carrier on the towbar - without Volvo genu- when the parking brake is applied or P the centre console's display screen indicate...

  • Page 239: Park Assist Syst* - Fault Indication

    07 Driver support Park assist syst* - fault indication Park assist syst* - cleaning the sensors Parking assistance is used as an aid to park- ing. An acoustic signal as well as symbols on Parking assistance is used as an aid to park- the centre console's display screen indicate ing.

  • Page 240: Park Assist Camera

    07 Driver support Park assist camera* Function and operation the car's approximate external dimensions will be positioned with the current steering Parking camera is an auxiliary system, which wheel angle - this facilitates parallel parking, is activated when the reverse gear is selected. reversing into tight spaces and for hitching a The camera image is shown on the centre trailer.
  • Page 241 0,8-1,5 The yellow side lines end approx. 2.0 m • The parking camera is deactivated behind the bumper. Yellow 0,4–0,8 automatically when towing a trailer if a Volvo genuine trailer cable is used. 0–0,4 Option/accessory, for more information, see Introduction.

  • Page 242: Park Assist Camera - Settings

    07 Driver support Park assist camera - settings Related information 3. Highlight the option by pressing OK/ • MENU once and go back out with EXIT. Park assist camera - settings (p. 240) Activate switched-off camera • Park assist camera - limitations (p. 241) Miscellaneous If the camera function is switched off when •...

  • Page 243: Park Assist Camera - Limitations

    07 Driver support Park assist camera - limitations BLIS* Overview BLIS (Blind Spot Information System) is a NOTE camera-based information system that under certain conditions can help the driver to A bike carrier or other accessory mounted notice vehicles moving in the same direction on the rear of the car could obscure the as the host vehicle in the so-called "blind camera's view.

  • Page 244: Blis* - Operation

    07 Driver support BLIS* - operation sponge. Clean the lenses carefully so that When BLIS is deactivated, the lamp in the they are not scratched. button extinguishes and a message is shown BLIS (Blind Spot Information System) is a in the combined instrument panel. function designed for providing support for IMPORTANT the driver when driving in dense traffic on...
  • Page 245 07 Driver support system's cameras are obscured then the In darkness the system reacts to the head- The following illustrations show examples of BLIS indicator lamp flashes and a message is lamps of surrounding vehicles. If the head- situations where the BLIS indicator lamp may shown in the combined instrument panel.

  • Page 246: Blis - Symbols And Messages

    Repair of the BLIS system components vated. must only be performed by a workshop - BLIS OFF The BLIS system is deacti- an authorised Volvo workshop is recom- BLIS Serv- Blind spot syst. disen- vated. mended. ice required gaged - contact a work- shop.

  • Page 247: Adjustable Steering Force

    07 Driver support Adjustable steering force* Type approval - radar system Coun- Speed related power steering causes the Type approval for the radar system can be try/ steering wheel force to increase with the read in the table. Area speed of the car in order to give the driver Singa- enhanced sensitivity.
  • Page 248 S T A R T I N G A N D D R I V I N G...

  • Page 249: 08 Starting And Driving

    08 Starting and driving Alcolock* Alcolock* - functions and operation Indicator Battery status The function of the Alcolock is to prevent the lamp (4) Functions car from being driven by individuals under the Green flash- Charging in progress influence of alcohol. Before the engine can be started the driver must take a breath test that verifies that he/she is not under the influence Green...

  • Page 250: Alcolock* - Storage

    08 Starting and driving • Alcolock* - storage Alcolock* - before starting the engine Alcolock* - symbols and text messages (p. 251) Store the Alcolock in its holder. Release the The Alcolock is activated automatically and is handheld unit by depressing it slightly in its then ready for use when the car is opened.
  • Page 251 08 Starting and driving • 3. Fold up the nozzle (1), take a deep breath Result after breath test Alcolock* - storage (p. 248) and blow with an even pressure until a • Alcolock* - to bear in mind (p. 250) Indicator lamp Specification "click"...

  • Page 252: Alcolock* - To Bear In Mind

    Alcolock approx. 5 seconds - the combined instru- ing heading "Emergency situation". indoors. Bypass activated ment panel first shows Please wait for 1 minute and then An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.

  • Page 253: Alcolock* - Symbols And Text Messages

    30 minutes - onds engine starting possible This function can be used once, after which a without new test. reset must be made at a workshop An authorised Volvo workshop is recommended. Alcoguard Contact a workshop Related information Related information Service •...

  • Page 254: Starting The Engine

    08 Starting and driving Starting the engine 1. Insert the remote control key in the igni- WARNING tion switch and press it in to its end posi- The engine is started and switched off using Never remove the remote control key from tion.

  • Page 255: Switching Off The Engine

    08 Starting and driving Switching off the engine Steering lock NOTE The engine is switched off using the START/ The steering lock makes steering difficult if A prerequisite for the engine to start is that STOP ENGINE button. the car is e.g. taken unlawfully. one of the car's remote control keys with the Keyless drive function is in the passen- Function...

  • Page 256: Remote Start (Ers)

    WARNING ERS is activated via key and/or via Volvo On Call*, see Volvo On Call supplement. To remote-start the engine, the following criteria must be met: The climate control starts with the same set- •...
  • Page 257 08 Starting and driving 1. Briefly press on the key's button (2). Active functions When an ERS-started engine is switched off, the direction indicators illuminate with a con- The following functions are activated with a 2. Follow this immediately afterwards with a stant glow for 3 seconds.

  • Page 258: Remote Start (Ers) - Symbols And Messages

    Remote start ERS interrupted since the passenger compart- off Low bat- the battery voltage is ment. An authorised Volvo workshop is recommended. tery too low. No remote ERS unavailable due to start Low Remote start ERS interrupted since low battery voltage.

  • Page 259: Starting The Engine - Flexifuel

    Fault tracing and repair of an electric engine block heater and its electri- cal connections must only be carried out by a workshop - an authorised Volvo work- shop is recommended. NOTE Points to remember for carrying reserve fuel: •...

  • Page 260: Jump Starting With Battery

    If the engine does not start despite repea- ted start attempts, you are recommended driving is required for the adaptation as the to contact an authorised Volvo workshop. memory for the electronics has been cleared. Related information Fuel adaptation •...

  • Page 261: Gearboxes

    08 Starting and driving Gearboxes 4. Connect one of the red jump lead's 11. Start the engine in the car with the dis- clamps to the donor battery's positive charged battery. There are two main types of gearbox. Manual terminal (1). gearbox and automatic gearbox.

  • Page 262: Manual Gearbox

    08 Starting and driving Manual gearbox Gear shift indicator* Reverse gear inhibitor The reverse gear inhibitor hinders the possi- The function of the gearbox is to change the The gear shift indicator notifies the driver bility of mistakenly attempting to engage gear ratio depending on speed and power when it is appropriate to engage the next reverse gear during normal forward travel.

  • Page 263: Automatic Gearbox -- Geartronic

    08 Starting and driving Automatic gearbox -- Geartronic* Automatic gearbox Parking position - P Select position P when starting the engine or The Geartronic gearbox has two different gear when the car is parked. modes - Automatic and Manual. • In order to be able to move the gear selector from P-position, the brake pedal must first be depressed firmly.
  • Page 264 08 Starting and driving Neutral position - N The manual gearshift mode "+S–" can be To then change gear one step: selected at any time while driving. No gear is engaged and the engine can be • Pull one of the paddles backwards - started.
  • Page 265 08 Starting and driving The gearbox "winter mode" means that the Geartronic - Sport mode* (S) NOTE car moves off with a lower engine speed and The Sport programme provides Automatic deactivation reduced engine power on the drive wheels. sportier characteristics and allows If the steering wheel paddles are not used higher engine speed for the gears.
  • Page 266 08 Starting and driving when the engine reaches its maximum speed in order to prevent damage to the engine. Towing If the car has to be towed - see important information in the section Towing (p. 301). Related information • Transmission fluid - grade and volume (p.

  • Page 267: Automatic Gearbox -- Powershift

    08 Starting and driving Automatic gearbox -- Powershift* Towing can also overheat during slow driving in queues (10 km/h or slower) on an uphill gradi- The model with Powershift transmission The Powershift automatic gearbox transmits ent, or with a trailer hitched. The transmission should not be towed as it is dependent on the the motive force from the engine to the drive cools down when the car is stationary, with...
  • Page 268 08 Starting and driving Symbol Message Driving characteristics Action Transmission hot Brake to Difficulty in maintaining even speed Transmission overheated. Keep the car stationary using the hold at constant engine speed. foot brake. Transmission hot Park Significant pulling in the car's trac- Transmission overheated.

  • Page 269: Gear Selector Inhibitor

    08 Starting and driving Gear selector inhibitor Deactivate automatic gear selector Stationary car with engine running: inhibitor There are two different types of gear selector • Keep your foot on the brake pedal when inhibitor - mechanical and automatic. moving the gear selector to another posi- tion.

  • Page 270: Hill Start Assist (Hsa)

    The function means that the pedal pressure in matically when the journey is due to continue. the brake system remains for several seconds Environmental care is one of Volvo Car Cor- while the driver's foot is moved from brake poration's core values and it influences all of pedal to accelerator pedal.

  • Page 271: Start/Stop* - Function And Operation

    08 Starting and driving Start/Stop* - function and operation The Start/Stop function gives the driver the Conditions opportunity for a more active environmentally The Start/Stop function is activated automati- conscious way of driving the car by means of cally when the engine is started with the key. being able to allow the engine to stop auto- Declutch, set the gear lever in neu- The Start/Stop function is...
  • Page 272 08 Starting and driving • Auto-starting the engine Deactivating the Start/Stop function Start/Stop* - settings (p. 274) In certain situations, it may • Start/Stop* - the engine does not auto- Conditions advisable to temporarily start (p. 273) switch off the automatic •...

  • Page 273: Start/Stop* - The Engine Does Not Stop

    08 Starting and driving Start/Stop* - the engine does not stop Conditions Conditions Although the Start/Stop function is activated, the engine does not always stop automati- cally. the car is reversed. the atmospheric air pressure is less than equivalent to The engine does not auto-stop if: 1500-2500 metres above sea level the starter battery temperature is...

  • Page 274: Start/Stop* - The Engine Auto-Starts

    08 Starting and driving • Start/Stop* - the engine auto-starts Start/Stop* - symbols and messages Conditions (p. 275) An auto-stopped engine may restart in certain • Battery - Start/Stop (p. 365) The driver's seatbelt buckle is cases without the driver having decided that opened with the gear selector in D the journey should continue.

  • Page 275: Start

    08 Starting and driving • • Start/Stop* - the engine does not Start/Stop* - settings (p. 274) Start/Stop* - involuntary stop manual auto-start gearbox (p. 274) • Start/Stop* - the engine does not auto- • start (p. 273) Start/Stop* - symbols and messages The engine does not always auto-start after (p.

  • Page 276: Gearbox

    Battery - Start/Stop (p. 365) In the event that a start-up fails and the DRIVe heading, contains information about Volvo's Start/Stop system, as well as recom- engine stops, proceed in accordance with the below: mendations for energy-saving driving techni- ques.

  • Page 277: Start/Stop* - Symbols And Messages

    Symbol Message Info/Action Auto Start/Stop Service Start/Stop is not operational. Contact a workshop - an authorised Volvo workshop is rec- M + A required ommended. Autostart Engine running Activated if the driver's door is opened with auto-stopped engine and the gear selector in D position.
  • Page 278 ENGINE button and the gear selector in P or N. M = Manual gearbox, A = Automatic gearbox. If a message does not go out following com- pletion of the action then a workshop should be contacted - an authorised Volvo workshop is recommended. Related information •...

  • Page 279: Eco

    ECO button lamp NOTE illuminating when the function is activated. is an innovative Volvo function for When the ECO function is activated, sev- automatic-gearbox cars, capable of reducing eral parameters in the climate control sys- ECO function On or Off...
  • Page 280 08 Starting and driving • on steep downhill gradients - to be able More information and settings tively contribute to reduced consumption. to use engine braking. Accordingly: • before an imminent overtaking manoeu- • Active Eco Coast: Long coasting without vre - in order to be able to complete it in engine braking = Low consumption the safest possible way.

  • Page 281: All Wheel Drive - Awd

    To keep the car as safe and reliable as possi- pedal will engage deeper and a higher pres- ble, follow the Volvo service intervals as sure on the pedal is needed to produce the specified in the Service and Warranty Book- normal braking effect.

  • Page 282: Foot Brake - Anti-Lock Braking System

    Vibration may be felt in a constant glow. tem checked - an authorised Volvo work- the brake pedal when this is engaged and this shop is recommended. is normal.

  • Page 283: Foot Brake - Emergency Brake Assis

    08 Starting and driving Foot brake - emergency brake assistance Emergency brake assistance EBA (Emergency Brake Assist) helps to increase the braking force and so reduce the braking distance. EBA detects the driver's braking style and increases the braking force when necessary. The brake force can be reinforced up to the level when the ABS system is engaged.

  • Page 284: Parking Brake

    08 Starting and driving Parking brake Applying the parking brake pressing and holding the control for PUSH LOCK/PULL RELEASE. The braking proce- The parking brake holds the car stationary, dure is stopped when the control is released. when the driver's seat is empty, by mechani- cally locking/blocking two wheels.
  • Page 285 The parking brake can also be released manually by depressing the clutch pedal 4. Move the gear selector to position D or R instead of the brake pedal. Volvo recom- and depress the accelerator. mends that the brake pedal is used.
  • Page 286 Try to apply and release the brake. If the fault persists after a few attempts: • Visit a workshop - an authorised Volvo workshop is recommended. Note: A warning signal sounds if the journey is continued with this error message.
  • Page 287 If the fault persists after a few attempts: • Visit a workshop - an authorised Volvo workshop is recommended. The message is also illuminated on cars with manual gearbox when the car is driven at low speed with the door open in order to alert the driver that the parking brake may have been unintentionally disengaged.

  • Page 288: Fording

    - tow the car from the Water and mud for example can make the panel's information display and a text water to a workshop - an authorised Volvo brake linings wet resulting in delayed brake High engine temperature workshop is recommended.

  • Page 289: Driving With Open Tailgate

    08 Starting and driving Driving with open tailgate Overload - starter battery stop the car in a safe way and allow the engine to run at idling speed for a few When driving with the boot lid open, toxic The electrical functions in the car load the minutes in order to allow the gearbox to exhaust fumes can be sucked into the car starter battery (p.

  • Page 290: Before A Long Journey

    • Check that the engine is working normally To achieve optimum roadholding Volvo rec- and that fuel consumption (p. 404) is nor- Check the following in particular before the ommends using winter tyres on all wheels if mal.

  • Page 291: Fuel Filler Flap - Opening/Closing

    08 Starting and driving Fuel filler flap - Opening/closing Fuel filler flap - manual opening Filling up with fuel The fuel filler flap can be opened/closed as The fuel filler flap can be opened manually Important things to consider when refuelling. follows: when electric opening from the passenger Opening/closing the fuel cap...

  • Page 292: Fuel - Handling

    Fuel of a lower quality than that recom- Mixing different types of fuel or the use located under the floor hatch in the cargo mended by Volvo must not be used as engine of fuel that is not recommended invalid- area. power and fuel consumption is negatively ates Volvo's warranties, as well as any affected.

  • Page 293: Fuel - Petrol

    Diesel fuel must: • Do not use any additives which have • fulfil the EN 590 and/or SS 155435 not been recommended by Volvo. standards • have a sulphur content not exceeding 10 mg/kg • have a maximum of 7 vol % FAME...
  • Page 294 (p. 404) NOTE accordance with Volvo recommendations and generate increased wear and engine Before filling with fuel in the event of fuel damage that is not covered by the Volvo shortage: warranty. • Stop the car on as flat/level ground as...

  • Page 295: Catalytic Converters

    08 Starting and driving • Catalytic converters Fuel - bioethanol E85 Fuel - diesel (p. 291) The purpose of the catalytic converters is to Bioetanol E85 is used as the fuel for the car's purify exhaust gases. They are located close engine.

  • Page 296: Diesel Particle Filter (Dpf)

    08 Starting and driving Diesel particle filter (DPF) motorway. The car should then be driven for WARNING approximately 20 minutes more. Diesel cars are equipped with a particle filter, Ethanol is sensitive to sparks, and explo- which results in more efficient emission con- sive gases could form in the reserve fuel NOTE trol.

  • Page 297: Economical Driving

    • Avoid driving with open windows. road - lower engine speeds result in lower For more information about Volvo Car Corpo- fuel consumption. Use the gear indicator ration's environmental philosophy, see Volvo (p. 260).

  • Page 298: Driving With A Trailer

    (p. 392). detailed information, see Weights (p. 391). trailer up long, steep ascents. • If the towing bracket is mounted by Volvo, Avoid driving with a trailer on inclines of NOTE then the car is delivered with the necessary more than 12%.

  • Page 299: Driving With A Trailer - Manual Gearbox

    08 Starting and driving Driving with a trailer - manual gearbox Driving with a trailer - automatic IMPORTANT gearbox When driving with a trailer in hilly terrain in a See also the specific information on slow hot climate there may be a risk of overheating. When driving with a trailer in hilly terrain in a driving with a trailer for cars with the hot climate there may be a risk of overheating.

  • Page 300: Towing Bracket/Towbar

    Detachable towbar - attach- ment/removal (p. 299). WARNING If the car is fitted with a Volvo detachable towbar: • Follow the installation instructions carefully. •...

  • Page 301: Detachable Towbar - Attachment

    08 Starting and driving Detachable towbar - attachment/ removal The attachment/removal of the detachable towbar is performed in the following way: Attaching The indicator window must show red. Dimensions, mounting points (mm) 1127 Remove the protective cover by first pressing in the catch and then pulling the cover straight back Insert the towbar until you hear a click.
  • Page 302 08 Starting and driving Turn the key anticlockwise to locked Check that the towbar is secure by pull- Safety cable. position. Remove the key from the lock. ing it up, down and back. WARNING WARNING Take care to secure the trailer's safety If the towbar is not fitted correctly then it cable in the intended bracket.

  • Page 303: Towing

    08 Starting and driving Towing During towing, one vehicle is towed by another vehicle using a tow rope. Find out the statutory maximum speed limit for towing before towing begins. 1. Unlock the steering lock by inserting the remote control key in the ignition switch and giving a long press on the START/ STOP ENGINE button - key position II is Push the protective cover until it snaps...
  • Page 304 08 Starting and driving In the event of uncertainty as to whether or discharged and the engine does not start, see WARNING not the car is equipped with Powershift trans- Jump starting with battery (p. 258). The brake servo and power steering do not mission, this can be verified by checking the work when the engine is switched off - the designation on the gearbox label under the...

  • Page 305: Towing Eye

    08 Starting and driving Towing eye The cover for the towing eye's attach- WARNING ment point is available in two variants The towing eye is screwed into a threaded No one/nothing is allowed to remain which must be opened in different ways: socket behind a cover on the right-hand side behind the recovery vehicle while the car of the bumper, front or rear.

  • Page 306: Recovery

    08 Starting and driving Recovery IMPORTANT Recovery means that the vehicle is transpor- Note that the car must always be transpor- ted away by means of another vehicle. ted with the wheels rolling forward. • Call a recovery service for recovery assis- An All Wheel Drive car (AWD) with tance.
  • Page 307 W H E E L S A N D T Y R E S...

  • Page 308: 09 Wheels And Tyres

    09 Wheels and tyres Tyres - direction of rotation Tyres - maintenance NOTE Tyres with a tread pattern which are designed Amongst other things, the function of the Make sure that both pairs of wheels have to only turn in one direction have the direction tyres is to provide grip on the road surface, the same type and dimension, and also the of rotation marked with an arrow.
  • Page 309 Tyres - tread wear indicators (p. 308) switched with each other. A suitable distance for the first change is approx. 5000 km and then at 10000 km intervals. Volvo recom- mends that you contact an authorised Volvo workshop for checking if you are uncertain about tread depth.

  • Page 310: Tyres - Tread Wear Indicators

    The wheel bolts must be tightened to 140 Nm. Overtightening can damage the nuts and the bolts. Only use rims that are tested and approved by Volvo and which are Volvo genuine acces- sories. Check the torque with a torque wrench. Locking wheel bolts* Tread wear indicators.

  • Page 311: Jack

    Emergency puncture repair* (p. 325) to all four wheels. NOTE Volvo recommends that you consult a Volvo dealer about which wheel rim and tyre types are most suitable. Studded tyres Studded winter tyres should be run in gently for 500-1000 km so the studs settle properly into the tyres.

  • Page 312: Wheel And Wheel Rim Dimensions

    (wheel rims) and tyres are WARNING approved. Wheels (rims) have a designation of dimen- Use Volvo genuine snow chains or equiva- sions, for example: 7Jx16x50. The dimensions are stated on all car tyres. lent chains designed for the car model, Example of designation: 225/50R17 98W.

  • Page 313: Tyres - Load Index

    09 Wheels and tyres Tyres - load index Tyres - speed ratings WARNING Load index indicates a tyre's ability to carry a Each tyre can withstand a certain maximum 19-inch wheels must never be used on certain load. speed and therefore belongs to a particular cars that are not equipped with the R- speed rating (SS - Speed Symbol).

  • Page 314: Changing Wheels - Removing Wheels

    09 Wheels and tyres Changing wheels - removing wheels the foam block. The foam block contains all 270 km/h the tools needed to change the wheels. The car's wheels can be changed for e.g. win- 300 km/h ter wheels/winter tyres. Taking out the spare wheel under the cargo area floor Spare wheel*...
  • Page 315 NOTE Volvo recommends only using the jack* that belongs to the car model in question, which is indicated on the jack's label. The label also indicates the jack's maxi- mum lift capacity at a specified minimum lifting height.

  • Page 316: Changing Wheels - Fitting

    09 Wheels and tyres Changing wheels - fitting Related information WARNING • Changing wheels - fitting (p. 314) It is important that the procedure for fitting Never position anything between the • the wheel is carried out correctly. Jack* (p. 309) ground and the jack, nor between the jack and the car's jacking point.

  • Page 317: Tyres - Air Pressure

    09 Wheels and tyres Tyres - air pressure NOTE NOTE Tyres can have different air pressures which • After a tyre has been inflated, always The car's regular jack is designed only for are measured in bar. use occasionally and for a short time, such refit the dust cap in order to avoid as when changing a wheel with a punc- damage to the valve from gravel, dirt,...

  • Page 318: Warning Triangle

    09 Wheels and tyres Warning triangle Tyre pressure label NOTE The warning triangle is used to warn other • Check the tyre pressure when the road users of a stationary vehicle. tyres are cold. "Cold tyres" means that the tyres are at the same temperature Storage and folding up as the outdoor temperature.

  • Page 319: First Aid Kit

    09 Wheels and tyres First aid kit* The warning triangle is fitted on the inside of Tyre pressure monitoring* the boot lid with two clips. The first aid box contains first aid equipment. Tyre pressure monitoring warns the driver when the pressure is too low in one or more Detach the warning triangle case by pull- of the car's tyres.

  • Page 320: Tpms (Tyre Pressure Monitoring System)* - General

    09 Wheels and tyres • • TPMS (Tyre Pressure Monitoring TPMS (Tyre Pressure Monitoring System)* Tyre pressure system Service - recommendations (p. 321) required System)* - general • TPMS (Tyre Pressure Monitoring System)* Both factory-fitted and optional wheels can Tyre pressure monitoring (TPMS) (Tyre - driveable punctured tyres* (p.

  • Page 321: Tpms (Tyre Pressure Monitoring System)* - Adjusting (Recalibration)

    09 Wheels and tyres • TPMS (Tyre Pressure Monitoring TPMS (Tyre Pressure Monitoring System)* 5. Drive for at least 10 minutes at a speed of - activate/deactivate (p. 321) at least 30 km/h. System)* - adjusting (recalibration) • TPMS (Tyre Pressure Monitoring System)* >...

  • Page 322: Tpms (Tyre Pressure Monitoring System)* - Status

    09 Wheels and tyres TPMS (Tyre Pressure Monitoring error has occurred in the system. Contact NOTE a Volvo dealer or workshop. System)* - status • The TPMS system uses a so-called Tyre pressure monitoring (TPMS) (Tyre Clearing warning messages compensated pressure value, based...

  • Page 323: Tpms (Tyre Pressure Monitoring System)* - Activate/Deactivate

    The car must be stationary when the tyre ing winter wheels. refit the dust cap in order to avoid pressure monitoring is activated/deacti- • Volvo recommends that sensors are not damage to the valve from gravel, dirt, vated. moved between different wheels. etc.

  • Page 324: Tpms (Tyre Pressure Monitoring System)* - Driveable Punctured Tyres

    09 Wheels and tyres TPMS (Tyre Pressure Monitoring TPMS (Tyre Pressure Monitoring WARNING System)* - driveable punctured System)* - rectifying low tyre Only people with knowledge of SST tyres tyres* pressure should fit them. If SST (Self Supporting run flat Tires)* is The tyre pressure monitoring system TPMS SST tyres must only be fitted together with selected, the car is also equipped with TPMS...

  • Page 325: Tm (Tyre Monitor)

    09 Wheels and tyres Calibrate tyre pressure TM (Tyre Monitor)* 4. Select IMPORTANT press OK. The TM (Tyre Monitor) system senses tyre If a fault occurs in the TM system the rotation speed in order to determine whether 5. Start and drive the car. warning lamp in the combined instru- the tyres have the correct tyre pressure.
  • Page 326 "Cold tyres" means the tyres are error has occurred in the system. Contact the same temperature as the ambient a Volvo dealer or workshop. temperature (approx. 3 hours after the car has been driven). After a few kilo- Clearing warning messages...

  • Page 327: Emergency Puncture Repair

    The sealing fluid bottle must be replaced The compressor for temporary emergency before its expiration date and after use. The puncture repair has been tested and sealing fluid effectively seals tyres punctured approved by Volvo. in the tread. Related information NOTE •...

  • Page 328: Emergency Puncture Repair Kit* - Overview

    (p. 405). • Emergency puncture repair* (p. 325) NOTE The compressor for temporary emergency puncture repair has been tested and approved by Volvo. Related information • Emergency puncture repair kit* - overview (p. 326) •...

  • Page 329: Emergency Puncture Repair* - Operation

    Emergency puncture repair after the emergency tyre repair kit has the valve. been used. Volvo recommends that you visit an authorised Volvo workshop for 6. Plug the cable into the 12 V socket and inspection of the sealed tyre (maximum start the car.

  • Page 330: Emergency Puncture Repair* - Rechecking

    09 Wheels and tyres Emergency puncture repair* - 7. Flick the switch to position I. 9. Switch off the compressor to check the rechecking pressure on the pressure gauge. Mini- mum pressure is 1.8 bar and maximum WARNING Emergency puncture repair, where the emer- 3.5 bar.

  • Page 331: Emergency Puncture Repair Kit* - Inflating The Tyres

    Check the tyre pressure regularly. 4. Start the compressor by flicking the switch to position I. Volvo recommends that you drive to the near- est authorised Volvo workshop for the replacement/repair of the damaged tyre. Option/accessory, for more information, see Introduction.

  • Page 332: Emergency Puncture Repair Kit* - Sealant

    09 Wheels and tyres Emergency puncture repair kit* - IMPORTANT sealant Risk of overheating. The compressor must The container (bottle) with the emergency not run for more than 10 minutes. puncture repair kit (p. 326) contains sealant and it can be replaced. 5.

  • Page 333: Type Approval - Tyre Pressure Monitoring

    09 Wheels and tyres Type approval - tyre pressure monitoring Type approval of the sensors in tyre pressure monitoring - TPMS (Tyre Pressure Monitoring System)* can be read in the table. Option/accessory, for more information, see Introduction.
  • Page 334 09 Wheels and tyres Country/Area Brazil Ukraine...
  • Page 335 09 Wheels and tyres Country/Area Israel...
  • Page 336 09 Wheels and tyres Declaration of Conformity (Declaration of Conformity) Country/ Area Countries in the EU: Exporting country: Germany Manufacturer: Continental Automotive GmbH Type of equipment: TPMS unit...
  • Page 337 09 Wheels and tyres Country/ Area Czech Repub- Continental tímto prohlašuje, že tento Radio Transmitter je ve shodě se základními požadavky a dalšími příslušnými lic: ustanoveními směrnice 1999/5/ES. Denmark: Undertegnede Continental erklærer herved, at følgende udstyr Radio Transmitter overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
  • Page 338 09 Wheels and tyres Country/ Area Malta: Hawnhekk, Continental, jiddikjara li dan Radio Transmitter jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Hungary: Alulírott, Continental nyilatkozom, hogy a Radio Transmitter megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
  • Page 339 M A I N T E N A N C E A N D S E R V I C E...

  • Page 340: 10 Maintenance And Service

    In the normal view for the MY ID (p. 19). CAR source, press OK/MENU and then • Log in to the web portal My Volvo, go to Service & repair Display your profile and carry out the following: notifications.
  • Page 341 • - A booking enquiry is sent to your Vehicle data is sent to a central Volvo data- dealer who then comes back with a You can also book a workshop visit via My base (not your dealer) from which Volvo deal- booking proposal.
  • Page 342 • Service requirement. • Function status. • Fluid levels. • Mileage (distance). • The car's vehicle identification number (VIN • The car's software version. Related information • Volvo ID (p. 19) Vehicle Identification Number...

  • Page 343: Raising The Car

    NOTE Volvo recommends only using the jack that belongs to the car model in question. If a jack is selected other than the one recom- mended by Volvo, follow the instructions...
  • Page 344 10 Maintenance and service Jacking points (arrows) for the jack that belongs to the car and lifting points (marked in red). If the car is raised with a front workshop jack then this must be positioned under one of the four lifting points furthest in under the car.

  • Page 345: Bonnet - Opening And Closing

    10 Maintenance and service Bonnet - opening and closing Engine compartment - overview WARNING The bonnet can be opened when the handle The overview shows normal checking points. Check that the bonnet locks properly when by the pedals has been pulled backwards, closed.

  • Page 346: Engine Compartment - Checking

    Always have the engine cleaned by a 0 when work is being performed in the workshop - an authorised Volvo workshop engine compartment; see Key positions - is recommended. There is a risk of fire if functions at different levels (p.

  • Page 347: Engine Oil - General

    If the car is driven in adverse con- filled with a specially adapted synthetic ditions, Volvo recommends using an oil of a engine oil at the factory. The choice of oil higher grade; see Engine oil - adverse driving has been made very carefully with regard conditions (p.

  • Page 348: Engine Oil - Checking And Filling

    3. Re-insert the dipstick. change. 4. Pull it out and check the level. Volvo recommends checking the oil level every 2 500 km. The most accurate measure- 5. If the level is close to MIN then 0.5 litres ments are made on a cold engine before star- should be added.
  • Page 349 10 Maintenance and service You do not need to take action with respect 2. Rotate the thumbwheel on the left-hand WARNING Oil level to the engine oil level before a message is stalk switch to position Oil service required If the message shown in the display, see following illustra- >...
  • Page 350 10 Maintenance and service Engine with electronic oil level sensor, IMPORTANT 5-cyl. diesel Oil level low In the event of the message Refill 0.5 litre , only fill with 0.5 litres. NOTE The oil level is only detected by the system during driving.

  • Page 351: Coolant - Level

    10 Maintenance and service Coolant - level Measuring the oil level, 5-cyl. diesel Related information • If the oil level needs to be checked then it Engine oil - general (p. 345) The coolant cools the internal combustion should be carried out in accordance with the engine to the correct operating temperature.

  • Page 352: Brake And Clutch Fluid - Level

    (cracks) in the cylinder head. ther before topping up the brake fluid. Volvo recommends that the reason for the loss of brake fluid is investigated by an authorised Volvo workshop.

  • Page 353: Power Steering Fluid - Level

    10 Maintenance and service Power steering fluid - level Filling NOTE The power steering fluid level must be If a fault should arise in the power steering between the reservoir's MIN and MAX marks. system, or if the engine is switched off and The fluid does not need to be changed.

  • Page 354: Climate Control System - Fault Tracing And Repair

    Side marker lamps rear • Brake light. NOTE If an error message remains after the bro- ken bulb has been replaced then we rec- ommend that you visit an authorised Volvo workshop. LED (Light Emitting Diode) An authorised Volvo workshop is recommended.

  • Page 355: Lamp Replacement - Headlamps

    10 Maintenance and service Lamp replacement - headlamps NOTE All of the headlamp bulbs are replaced via the Outside lighting such as headlamps, fog engine compartment. First loosen and remove lamps and rear lamps may temporarily the whole headlamp. have condensation on the inside of the lens.

  • Page 356: Lamp Replacement - Cover For Main

    10 Maintenance and service Lamp replacement - cover for main/ Lamp replacement - dipped beam Related information • dipped beam bulbs Lamp replacement (p. 352) The dipped beam bulb is fitted inside the • Main/dipped beam bulbs are accessed by headlamp's larger cover.

  • Page 357: Lamp Replacement - Main Beam

    10 Maintenance and service Lamp replacement - main beam Lamp replacement - extra main beam Lamp replacement - direction indicators front The main beam bulb is fitted inside the head- The extra main beam bulb is fitted inside the lamp's larger cover. headlamp's larger cover.

  • Page 358: Lamp Replacement - Rear Lamp

    10 Maintenance and service Lamp replacement - rear lamp Lamp replacement - location of rear Related information • lamps Lamp replacement - location of rear Lamps in the rear lamp cluster are replaced lamps (p. 356) from inside the cargo area. The overview shows the location of the lamps •...

  • Page 359: Ing

    10 Maintenance and service Lamp replacement - number plate Lamp replacement - lighting in cargo lighting area The number plate lighting is located under the The cargo area lighting is positioned on both tailgate handle. sides of the boot lid opening. Rear lamp cluster bulb holder Reversing lamp (p.

  • Page 360: Lamp Replacement - Vanity Mirror Light- Ing

    10 Maintenance and service Lamp replacement - vanity mirror Lamps - specifications Related information lighting • Lamps - specifications (p. 358) The specifications apply to bulbs. When The vanity mirror's lamps are fitted inside the replacing LED and Xenon lamps, please refer to a workshop.

  • Page 361: Wiper Blades

    10 Maintenance and service Wiper blades 1. Insert the remote control key in the igni- Lighting Type tion switch and briefly press the The windscreen wiper blades must be in serv- START/STOP ENGINE button to set the Reversing lamp P21W LL ice position when they are to be replaced.
  • Page 362 10 Maintenance and service Replacing the wiper blades Cleaning Fold up the wiper arm when it is in serv- ice position. Press the button located on For cleaning wiper blades and windscreen, the wiper blade mounting and pull see Car washing (p. 380). straight out parallel with the wiper arm.

  • Page 363: Washer Fluid - Filling

    Engine The windscreen and headlamp washers share a common reservoir. Petrol Diesel (Ethanol) IMPORTANT Voltage (V) Use Volvo genuine washer fluid or equiva- lent with a recommended pH of between 6 Cold start and 8. capacity 520–800 700–800 IMPORTANT In accordance with SAE or EN standard.
  • Page 364 10 Maintenance and service IMPORTANT IMPORTANT NOTE If the starter battery is replaced, make sure When charging the starter battery or the The life of the battery is shortened if it you replace it with a battery with the same support battery (p.

  • Page 365: Battery - Symbols

    10 Maintenance and service Battery - symbols Starter battery - replacement Avoid sparks and naked There are information and warning symbols The starter battery in the car can be replaced flames. on the battery. without the help of a workshop. Symbols on the battery The starter battery is a traditional 12 V bat- tery.
  • Page 366 10 Maintenance and service Remove the rear cover by screwing one 1. Lower the battery into the battery box. quarter turn and lifting it away. 2. Move the battery inward and to the side until it reaches the rear edge of the box. WARNING 3.

  • Page 367: Battery - Start/Stop

    10 Maintenance and service Battery - Start/Stop Battery Battery Cars with the Start/Stop function are equip- Start, 12 V Support, 12 Start, 12 V Support, 12 ped with a support battery in addition to the starter battery. Left-hand Left-hand Cars with the Start/Stop function are equip- drive car: drive car: ped with two 12 V batteries - one extra pow-...
  • Page 368 - an authorised brake pedal (automatic gearbox). Volvo workshop is recommended. Automatic starting can only take place if the gear lever is in neutral position. See Starter battery - general (p. 361) for detailed description of the starter battery.

  • Page 369: Electrical System

    Start/Stop the same fuse fails repeatedly then there is a function may fail to auto-start the engine fault in the circuit. Volvo recommends that IMPORTANT due to inadequate capacity in the battery. you visit an authorised Volvo workshop for The battery must first be charged in order checking.

  • Page 370: Fuses - In The Control Module Under The Glovebox

    10 Maintenance and service • Location of central electrical units Fuses - in the engine compartment's cold zone (p. 378) Central electrical unit locations in a left-hand drive car. In a right-hand drive car the central electrical units under the glovebox change sides.

  • Page 371: Fuses - In Engine Compartment

    10 Maintenance and service Fuses - in engine compartment Fuses in the engine compartment protect engine and brake functions, amongst other things.
  • Page 372 Heated windscreen*, left-hand shop side • Fuses 16-33 and 35-41 are of the "Mini Fuse" type. Windscreen wipers Headlamp control Parking heater* Ventilation fan Heated windscreen*, right- hand side An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 373 10 Maintenance and service Function Function Function Relay coils Ignition coils (1.6 l petrol); Glow Solenoid clutch A/C (5, 6-cyl.); control module (5-cyl. diesel) Valves (1.6 l, 5, 6-cyl.); Engine Auxiliary lamps* control module (6-cyl.) Sole- Engine control module (4-cyl. noids (6-cyl.
  • Page 374 10 Maintenance and service Function Function Coolant pump (1.6 l petrol Cooling fan (1.6 l, 4-cyl. 2.0 l Start/Stop) petrol, 5-cyl. petrol) Coolant pump (5-cyl. petrol); Cooling fan (6-cyl., 4-cyl. 2.0 l Crankcase ventilation heater diesel, 5-cyl. diesel) (5-cyl. petrol); Oil pump auto- Power steering matic gearbox (5-cyl.

  • Page 375: Fuses - Under Glovebox

    10 Maintenance and service Fuses - under glovebox Fuses under the glovebox protect the info- tainment system and seat functions, amongst other things. Positions Function Function Function Control panel, rear passenger door, right Primary fuse for audio control module*; Primary fuse for fuses Control panel, rear passenger 16-20: Infotainment door, left...
  • Page 376 10 Maintenance and service Function Function Parking assistance*; Parking camera*; Towbar control mod- Infotainment Control Module or ule* Screen AWD control module* Audio control unit (amplifier)*; Active chassis Four-C* Digital radio*; TV* Audio control module or Control Certain model variants. module Sensus Related information •...

  • Page 377: Fuses - In The Control Module Under The Glovebox

    10 Maintenance and service Fuses - in the control module under the glovebox Fuses in the control module under the glove- box protect airbag and collision warning sys- tem functions, amongst other things. Positions Function Function Function Adaptive cruise control, ACC*; Windscreen washers collision warning system* Unlocking, boot lid...
  • Page 378 10 Maintenance and service Function Steering lock Siren*; Data link connector OBDII Airbags Collision warning system* Accelerator pedal sensor; Dim- ming interior rearview mirror*; Seat heating, rear* Electric additional heater* Infotainment control module (Performance); Audio (Perform- ance) Brake light Sunroof* Immobiliser Related information •...

  • Page 379: Fuses - In Cargo Area

    10 Maintenance and service Fuses - in cargo area Fuses in the cargo area protect trailer and electric drive functions, amongst other things. The fuse box is located behind the upholstery on the left-hand side. Positions Function Function Function Trailer socket 1* Electric parking brake, left Electric parking brake, right Related information...

  • Page 380: Fuses - In The Engine Compartment's

    Primary fuse for relay/fuse box For more information on Start/Stop - see box, relay/fuse box under the under the glovebox Start/Stop* (p. 268). glovebox, central electrical unit in cargo area An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 381 10 Maintenance and service Function Primary fuse for relay/fuse box under the glovebox Primary fuse for central electri- cal unit in cargo area Ventilation fan Start relay Internal diode Support battery Central electronic module (CEM) - reference voltage sup- port battery; Charging point support battery Related information •...

  • Page 382: Car Washing

    An authorised for example. everywhere. Handwashing the car is recom- Volvo workshop is recommended for the Do not use any corrosive cleaning agents removal of any discoloration. mended for achieving optimum results.

  • Page 383: Polishing And Waxing

    Strong rim cleaning agents can damage the components contain both polish and wax. surface and cause stains on chrome-plated A special cleaning agent available from Volvo aluminium rims. dealers is recommended for the cleaning and IMPORTANT care of coloured plastic parts, rubber and trim Related information components, such as glossy trim mouldings.

  • Page 384: Lamp Replacement - Number Plate Light-Rustproofing

    Treatment with a special finishing agent ted at three-year intervals. Volvo recom- available from Volvo dealers is recom- mends that you engage an authorised Volvo Only use one inlaid mat at each seat, and mended in order to maintain the water-...
  • Page 385 (or more if A special fabric cleaning agent, available from 1. Pour a small amount of the protective necessary). The Volvo Leather Care kit is authorised Volvo dealers, is recommended to cream on the felted cloth and massage in available from your Volvo dealer.

  • Page 386: Paint Damage

    Materials stain removers. A special cleaning agent • primer - a special adhesive primer in a available from Volvo dealers can be used for Exterior colour code spray can is available for e.g. plastic- more difficult cleaning. coated bumpers Any secondary exterior colour code •...
  • Page 387 10 Maintenance and service Repairing minor paint damage such as 3. Stir the primer well and apply using a fine brush, matchstick or similar. Finish with stone chips and scratches base coat and clear coat once the primer has dried. 4.
  • Page 388 S P E C I F I C A T I O N S...

  • Page 389: 11 Specifications

    11 Specifications Type designations Type designation, vehicle identification num- ber, etc., i.e. information unique to the car, can be read on a label in the car.
  • Page 390 Knowing the car's type designation, vehicle dealer regarding the car and when ordering Type designation, vehicle identification identification and engine numbers can facili- spare parts and accessories. number, permissible maximum weights tate all contact with an authorised Volvo and code designation for exterior colour...
  • Page 391 11 Specifications and date of manufacture. The label is visi- ble when the right rear door is opened. Label for parking heater. Engine code and engine serial number. Label for engine oil. Gearbox type designation and serial num- ber. Manual gearbox Automatic gearbox Car's identification number.

  • Page 392: Dimensions

    11 Specifications Dimensions Measurement of car length, height, etc. can be read in the table. Dimensions Dimensions Dimensions Wheelbase 2835 Front track Width including door 2106 1588 mirrors 1578 Length 4854 Width including folded- 1907 Rear track Load length, floor, 1927 1585 in door mirrors...

  • Page 393: Weights

    11 Specifications Weights WARNING Max. gross vehicle weight, etc. can be read The car's driving characteristics change on a label in the car. depending on how heavily it is loaded and how the load is distributed. Kerb weight includes the driver, the fuel tank 90% full and all fluids.

  • Page 394: Towing Capacity And Towball Load

    11 Specifications Towing capacity and towball load Max. weight braked trailer Towing capacity and towball load for driving NOTE with a trailer can be read in the tables. The use of a stabiliser hitch on the towing bracket is recommended for trailers heav- ier than 1800 kg.
  • Page 395 11 Specifications Engine Gearbox Max. weight braked trailer (kg) Max. towball load (kg) Engine code 1200 B4164T Automatic, MPS6 1600 B4204T11 Automatic, TG-81SC 1800 B4204T15 Automatic, TG-81SC 1800 T6 AWD B6304T4 Automatic, TF-80SC 2000 D4162T Manual, MMT6 1300 D4162T Automatic, MPS6 1300 D5204T3 Manual, M66...
  • Page 396 11 Specifications Related information • Weights (p. 391) • Driving with a trailer (p. 296)

  • Page 397: Engine Specifications

    11 Specifications Engine specifications NOTE Engine specifications (output etc.) for each Not all engines are available in all markets. respective engine alternative can be read in the table. Engine Output Output Torque No. of cylin- Bore Stroke Swept vol- Compres- Engine code ders sion ratio...

  • Page 398: Engine Oil - Adverse Driving Conditions

    Volvo Car Corporation disclaims all war- ranty liability if engine oil of the prescribed grade and viscosity is not used. Volvo recommends that oil changes are carried out at an authorised Volvo work- shop.

  • Page 399: Engine Oil - Grade And Volume

    11 Specifications Engine oil - grade and volume Engine oil grade and volume for each respec- tive engine alternative can be read in the table. Volvo recommends: Engine Oil grade Volume, incl. oil filter Engine code (litres) B6304T4 Oil grade: ACEA A5/B5 approx 6.8...
  • Page 400 11 Specifications Engine Oil grade Volume, incl. oil filter Engine code (litres) B4204T11 Castrol Edge Professional V 0W-20 or VCC RBS0-2AE 0w20 approx. 5.4 B4204T15 approx. 5.4 D4204T5 approx 5.2 Engine code, component and serial number can be read on the engine; see Type designations (p. 387). Automatic gearbox.

  • Page 401: Coolant - Grade And Volume

    Related information • Coolant - level (p. 349) Approved coolant volume for each respective engine alternative can be read in the table. Prescribed grade: Coolant recommended by Volvo mixed with 50% water , see the pack- aging. Volume Engine (litres) 10.5...

  • Page 402: Transmission Fluid - Grade And Volume

    11 Specifications Transmission fluid - grade and volume The prescribed transmission fluid and volume for each respective gearbox alternative can be read in the table. Manual gearbox Manual gearbox Volume (litres) Prescribed transmission fluid MMT6 approx. 1.7 BOT 350M3 approx. 1.9 (approx. 1.45 Applies to the D4204T5 engine.
  • Page 403 11 Specifications Automatic gearbox Volume (litres) Prescribed transmission fluid TF-80SD approx 7.0 approx. 6.6 TG-81SC approx. 7.5 Petrol engines Diesel engines NOTE For the MPS6, oil changes must take place within certain service intervals. For other gearboxes the gearbox oil does not need to be changed under normal driv- ing conditions.

  • Page 404: Brake Fluid - Grade And Volume

    Prescribed grade: Washer fluid recom- Prescribed grade: DOT 4 mended by Volvo - with frost protection dur- Related information ing cold weather and below freezing point. Volume: 0.6 litres •...

  • Page 405: Fuel Tank - Volume

    11 Specifications Fuel tank - volume Fuel tank volume for each respective engine alternative can be read in the table. Engine Volume (litres) Prescribed grade Petrol engine approx. 70 Petrol: Fuel - petrol (p. 291) Diesel engine approx. 70 Diesel: Fuel - diesel (p. 291) Related information •...

  • Page 406: Fuel Consumption And Co2 Emissions

    11 Specifications Fuel consumption and CO2 emissions Fuel consumption and CO2 emissions can be affected negatively by several causes. Examples of this are: • If the car is equipped with extra equip- ment that affects the car's weight. • The driver's driving style. •...

  • Page 407: Tyres - Approved Tyre Pressures

    11 Specifications Tyres - approved tyre pressures NOTE Approved tyre pressures for each respective All engines, tyres or combinations of these engine alternative can be read in the table. are not always available in all markets. Tyre size Speed Load, 1-3 persons Max.
  • Page 408 11 Specifications Tyre size Speed Load, 1-3 persons Max. load ECO pressure Engine Front Rear Front Rear Front/rear (km/h) (kPa) (kPa) (kPa) (kPa) (kPa) 225/55 R 16 0 - 160 225/50 R 17 160 + 0 - 160 205/60 R 16 205/55 R 17 215/50 R 17 160 +...
  • Page 409 11 Specifications...
  • Page 410 12 Alphabetical Index Airbag All Wheel Drive (AWD)......279 activating/deactivating, PACOS... 32 Approach lighting......91, 159 ACC – Adaptive cruise control....190 driver's side........30, 38 Automatic car washes......380 passenger side......31, 32, 38 Active Bending Lights (ABL)...... 87 Automatic gearbox......
  • Page 411 12 Alphabetical Index Book service and repair......338 Car key memory........156 Clean Zone Interior Package (CZIP)..123 Boot lid............ 173 Car upholstery......... 382 Climate control Locking/unlocking......173 actual temperature......122 Car washing..........380 auto-regulation........130 Brake and clutch fluid......350 Catalytic converter........
  • Page 412 12 Alphabetical Index Coolant Dimensions..........390 volume and grade....... 399 Dipstick, electronic......346, 348 ECC, electronic climate control....127 Coolant, checking and filling....349 Direction indicator........89 Eco Cruise..........277 Cooling system........286 Direction indicators........89 overheating......... 286 EcoGuide........... 63 direction of rotation.........
  • Page 413 12 Alphabetical Index Engine Error messages in BLIS......244 Fuel-driven heater deactivate........... 253 timer............ 138 ERS - Remote Start......... 254 overheating......... 296 Fuelling exhaust gases, toxic, sucked in....287 start............. 252 filling........... 289 External dimensions........ 390 Start/Stop........... 268 fuel cap..........289 Engine and passenger compartment heater fuel filler flap........
  • Page 414 12 Alphabetical Index Gear selector inhibitor, mechanical disen- Heating Instruments and controls..... 53, 56 gagement..........267 rearview and door mirrors....101 Interior Air Quality System (IAQS) rear window........101 Geartronic..........262 Air cleaning......... 124 seats........... 128 Glass Interior lighting, see Lighting..... 90 steering wheel........
  • Page 415 12 Alphabetical Index Keyless - unlocking......... 169 in the passenger compartment..... 90 Locking/unlocking main/dipped beam....... 84 glovebox..........172 Keypad in the steering wheel....80 position/parking lamps......83 inside..........171 Key positions..........74 rear fog lamp........87 tunnel detection........84 Lighting, bulb replacement...... 353 bulb holder, rear.........
  • Page 416 12 Alphabetical Index Engine block heater and passenger Polishing..........381 compartment heater......140 Position/parking lamps......83 Lane Departure Warning..... 232 PACOS............32 Power guide..........63 Messages in BLIS........244 Paddle on the steering wheel....80 Power seat..........77 Meters Paintwork Powershift gearbox......
  • Page 417 12 Alphabetical Index Rearview and door mirrors Resetting the power windows....98 Seatbelt tensioner........ 28, 38 compass..........102 Retractable power door mirrors....100 Seats............76 door............99 head restraints, rear......78 Reverse gear inhibitor......260 electrically retractable......100 heating..........128 Road sign information......
  • Page 418 12 Alphabetical Index Stability and traction control system 181, sunscreen........... 104 Towbar, see Towing equipment....298 ventilation position......104 Towbar - detachable operation..........182 Sunscreen, sunroof........104 attachment/removal....299, 300 Stability system........181 Switching off the engine......253 Towing............. 301 Stains............
  • Page 419 Ventilation..........125 Warning symbols......60, 62, 66 deactivate........... 321 driveable punctured tyres (SST)..322 Vibration damper........298 Warning triangle........316 low tyre pressure........ 322 Volvo ID............. 19 Washer fluid recommendations....... 321 volume..........402 Volvo Sensus..........73 Tyres Washer fluid, filling........361 direction of rotation......
  • Page 420 12 Alphabetical Index Waxing............. 381 Wiper blades..........359 changing..........360 Weights Cleaning..........360 kerb weight......... 391 Service position........359 Wheel bolts..........308 Wipers and washing........96 lockable..........308 Wheel rim, dimensions......310 Wheel rims cleaning..........381 Wheels installation........... 314 removal..........312 snow chains........
  • Page 422 TP 17647 (English Int.), AT 1420, MY15, Printed in Sweden, Göteborg 2014, Copyright © 2000-2014 Volvo Car Corporation...

Table of Contents
