Zenith ZHD-311 Quick Setup Manual

Speaker Positioning

For a normal setup, use 6 speakers (2 front speakers, center speaker, 2 rear speakers and subwoofer).
• Front Speakers
Set up the speakers at an equal distance from your listening position. For best hearing position, set up an interval
between speakers of 45 degree.
• Center Speaker
It is ideal if the center speaker and front speakers are at the same height. But normally place the center speaker
above or below the television as shown below.
• Rear Speakers
Place the rear surround speakers to the left and right behind the primary listening area. These speakers recreate
sound motion and atmosphere required for surround playback. For best results, do not install the rear speakers too far
behind the listening position, install them at or above the level of the listener's ears. It is also effective to direct the
rear speakers towards a wall or the ceiling to further disperse the sound.
For smaller room sizes, if the audience is near the rear wall, place the rear speakers opposite each other, and
between 23.5 - 35.5 inches above the listener's ears.
• Subwoofer
This can be placed in any front position.
Subwoofer
Front Speaker
(Left)
Rear Speaker
(Left)
P/N: 3840R-Q056Y
Center
Front Speaker
Speaker
(Right)
Rear Speaker
(Right)
Q u i c k S e t u p
Q u i c k S e t u p
MODEL: ZHD-311
DVD Receiver Home Theater System
Please read this manual first!
Congratulations on purchasing this ZENITH product.
We've included everything you need to get started.
If you have any problems, ZENITH Representatives are
your resource for answering your questions and helping you
get the most from your new product.
Please read this manual before attempting to return this
product to the store.
Thank you for making ZENITH a part of your home!
G u i d e
G u i d e
For fast help, call us first!
1-877-993-6484
