Operation Mode - Cisco CATALYST 6000 Installation And Configuration Note

Table 2
Color
Off
Red
Orange
Green
Green to Orange
1. Enter the show environment temperature mod command to display the temperature of each of four sensors on the CSM.
2. CLI = command-line interface.
RJ-45 Connector
The RJ-45 connector on the front panel provides a connection point for a management station or test
device. The RJ-45 connector is covered by a removable plate. Typically, this connector is used by field
engineers to perform testing and to obtain dump information.

Operation Mode

Clients and servers communicate through the CSM using Layer 2 and Layer 3 technology in a specific
VLAN configuration. (See
server side VLAN. Servers and clients can exist on different subnets. Servers can also be located one or
more Layer 3 hops away and connect to the server-side VLAN through routers.
A client sends a request that arrives on one of the module's VIP addresses. The CSM forwards this
request to a server that can satisfy the request. The server then forwards the response to the CSM. The
CSM forwards the response to the client.
78-11631-02 Rev. A0
Content Switching Module Status LED
Description
The module is waiting for the supervisor engine to grant power.
•
The module is not online.
•
The module is not receiving power, which could be caused by the following:
•
Power is not available to the CSM.
–
Module temperature is over the limit
–
The module is released from reset by the supervisor engine and is booting.
•
If the boot code fails to execute, the LED stays red after power up.
•
• The module is initializing hardware or communicating with the supervisor
engine.
• A fault occurred during the initialization sequence.
• If the module fails to download its Field Programmable Gate Arrays (FPGAs)
on power up, it still proceeds with the rest of the initialization sequence and
is granted module online status from the supervisor engine, but the LED stays
orange.
If the module is not granted module online status from the supervisor engine,
•
the LED stays orange. This problem could be caused by the supervisor engine
detecting a failure in an external loopback test that it issued to the CSM.
The module is operational; the supervisor engine has granted module online
•
status.
The module is disabled through the supervisor engine CLI
•
module disable mod command.
Figure 2.) Clients connect to the client side VLAN and servers connect to the
Catalyst 6000 Family Content Switching Module Installation and Configuration Note
1
.
2
using the set
Overview
5
