Cisco CATALYST 6000 Installation And Configuration Note page 3

These sections describe the CSM:
•
•
•
•
Features
Table 1
Table 1
Feature
Management
Load-Balancing Algorithms
Flow and URL Identification
Security
Statistics
78-11631-02 Rev. A0
Features, page 3
Front Panel Description, page 4
Operation Mode, page 5
Client-to-CSM-to-Server Traffic Flow, page 7
describes the features of the CSM.
Content Switching Module Features
Catalyst 6000 Family Content Switching Module Installation and Configuration Note
Description
Standard Cisco IOS command-line interface
Management interface integrated with host platform
Weighted round-robin
Weighted least connections
Connection high/low watermarks
Source address-based hashing algorithm
URL regular expression match
Cookie regular expression match
1
SSL session ID match
Source IP address
Standard ACLs
Source IP address and URL expression match and AC entry match
Packets through normal and special switching
Connections created, established, destroyed, current, and timed out
Failed server connections
Layer 4 load-balanced decisions and rejected connections
Layer 7 load-balanced decisions and rejected connections
Layer 4 and Layer 7 rejected connections
Checksum failures
Redirect and FTP connections
MAC frames
Overview
3
