Troubleshooting - Audio Research Reference 10 User Manual

16
Operation
Display Intensity: Display Intensity adjusts the backlight for the screen
and its overall brightness. There are six levels plus 'off', with '6' being the
brightest. When 'off' is selected, the display will remain on for 8 seconds
and then shut off. To return illumination to the screen, simply touch it or
press a button on the remote. When adjusting the brightness, the words
'Display Intensity' will reflect the overall setting seleted. The display intensity
can also be adjusted from the remote using the 'DSP UP' and 'DSP DN'
buttons.
About: Touching the 'About' button displays a screen with the current
software version of the Reference 10. This information can be useful in
the event the Reference 10 needs troubleshooting. In the bottom right of
the About screen is a 'Defaults' button. Selecting the defaults button will
return all settings in the Reference 10 as they were shipped from the factory.
Please note that resetting the Reference 10 back to factory settings does
NOT reset the hours meter.

Troubleshooting

It is possible for a static discharge to temporarily disable the microprocessor
that allows the controls to function. If this should occur, depress the 'Mute'
button, then turn off the preamp and unplug the preamp from the A.C.
receptacle for 60 seconds. Reconnect the A.C. plug and turn the preamp
back on, along with other components. The controls should resume normal
operation. If the problem persists, contact your dealer or Audio Research
Customer Service at 763-577-9700.
Ref 10.indd 16 4/17/13 1:21 PM
