1.3 RS910W Front Panel Description
Ports 3 & 4
10/100Base-TX
or
100Base-FX
Or
10Base-FL
Ports 1 & 2
RS485/422/232
Serial
Or
Serial over Fiber
Power & Alarm
Failsafe Relay
Figure 1 - RS910W Front Panel Description
Status LED
Power LED
Alarm LED
Table 1 - Status LEDs
©
2007 RuggedCom Inc. All rights reserved
Colour
Green
Red
6
Port 9
Antenna #1
Port 9
Antenna #2
Power Port
Activity
Solid
Solid
Alarm condition exists
Comments
Power On
