NetVanta 644
VoIP Media Gateway

Product Specifications

Physical Interfaces
T1/E1 Interfaces
RJ-48C
■
Quad T1/E1
■
Ethernet Interfaces
RJ-45
■
Dual auto-sensing 10/100/1000 Base-T
■
Full duplex
■
May also be used as the WAN interface
■
Supports 802.1q VLAN trunking
■
Digital Voice
RJ-48C
■
PRI
■
NI-2 DMS-100
o o
5ESS ETSI
o o
T1 CAS Support
■
E&M Wink ❏ Feature Group D
■
Craft
DB-9
■
Processor and Memory
RAM: 128 Mb RAM
■
Flash: 64 Mb Flash
■
VoIP Protocol
SIP (TCP/UDP)
■
Packet-based Voice Resources
CODECs
■
G.711-64k PCM G.729a-8k CS-ACELP
■ ■
G.168 Echo Cancellation
■
Up to 128ms Echo-tail length
■
Supports up to 120 channels
■
Supports up to 120 T.38 sessions
■
Media Stream
RTP/UDP/IP (RFC 3550)
■
RTP payload for DTMF digits (RFC 2833/4733)
■
SDP (RFC 2327)
■
Tone Services
Local DTMF Detection
■
Local Tone Generation
■
Busy
■
Quality of Service (QoS)
DiffServ packet marking and recognition
■
Voice Quality Monitoring (VQM)
Mean Opinion Score (MOS) prediction
■
Jitter, Delay and Packet Loss
■
Past and Active Calls
■
Supports monitoring for 120 simultaneous calls
■
ADTRAN believes the information in this publication to be accurate as of publication
date, and is not responsible for error. Specifications subject to change without
notice. ADTRAN, NetVanta, and Total Access are registered trademarks of
ADTRAN, Inc. and its affiliates in the U.S. and certain other countries. All other
trademarks mentioned in this document are the property of their respective
owners. Five-year warranty applies only to products sold in North America.
ADTRAN products may be subject to U.S. export controls and other trade
restrictions. Any export, re-export, or transfer of the products contrary to law
is prohibited. For more information regarding ADTRAN's export license, please
visit www.adtran.com/exportlicense
DHCP
Client ❏ Relay ❏ Server
■ ■ ■
Management and Utilities
Familiar Command Line Interface (CLI)
■
Web-based GUI (HTTP/HTTPS)
■
n-Command support
■
SNMP v2 and v3
■
SYSLOG logging
■
Telnet, Craft/Console Port, SSH, Ping, Trace route,
■
NTP
Firmware Upgrade
FTP X-Modem
■ ■
TFTP HTTP
■ ■
n-Command
■
Environment
Operating Temperature: 0° to 50 °C (32° to 122 °F)
■
Storage Temperature: -20° to 70 °C (-40° to 158 °F)
■
Relative Humidity: Up to 95%, non-condensing
■
Maximum Altitude: 10,000 feet
■
Physical and Power
Chassis
■
Wallmount
■
1U Rackmount
■
Desktop metal enclosure
■
Dimensions:
1.72" H x 17.22" W x 7.75" D
■
4.37cm H x 43.74cm W x 19.69cm D
■
Weight:
5 lbs., 2.27 Kg
■
Power:
100-240 VAC, 60 Hz AC Power Supply
■
LEDs
Status ❏ Redundancy ❏ T1/E1 1–4
■ ■ ■
Warranty
Two years
■

Agency Approvals

FCC Part 15 Class A
■
Industry Canada
■
EN 60950
■
IEC 60950
■
CE Mark
■
Ordering Information
Equipment
NetVanta 644
Ethernet 1:2
■
FCC Part 68
■
UL 60950
■
AS/N25 60950
■
ACA 5016
■
ETSI 300
■
Part #
1700144G1#IN
