IL-380 Camera Users Manual and

Installation Instructions

I. General

The new IL-380 series camera features a high performance, mid-resolution
1/3" color CCD processor and built-in vari-focal lens, which provides excellent
picture quality, flexibility and cost savings. A mounting bracket is included with every
IL series camera making it one of the most complete and easy to install camera
packages on the market.

II. Precautions

• Do not expose the camera to humidity and dust. If the camera is mounted outdoor,
a camera housing is required.
• Do not disassemble it or place it on an unstable base.
• Do not touch the surface of CCD sensor by hand directly. Use a soft cloth to
remove the dirt from the camera body. Use lens tissue or a cotton tipped applicator
and ethanol to clean the camera lens and CCD sensor.
• Never face the camera toward the sun.
• Use proper power source otherwise the camera will not function correctly.
III. Installation Instructions
1. Connect the video output of the camera to a color monitor or other video device
through a 75 ohm type coaxial cable with BNC female connector at camera end.
2. Plug the power cord to the outlet. Power indicator LED should light if the power
source is properly connected.
3. Remove the lens cover cap from the top of the camera for adjusting the vari-focal
lens.
4. Once the image appears on the monitor, adjust the focus and diaphragm of the
lens to obtain the best picture.
5. If the subject is not in focus when adjusting focus of the lens, do back focus
adjustment as following:
i. Set the focus ring of the lens to infinity position.
ii. Take picture of subject at a distance more than 20m away from the camera.
iii. Loosen the lens mount fixing screw located at bottom of the front panel by
using the L wrench.
iv. Turn the lens and the mount together so that the subject is in focus.
v. Secure the lens mount fixing screw firmly again.
6. Mount the camera on the mounting bracket by using the mounting hole on the top
and bottom of camera casing.
.
