Connecting a computer source

VGA connection

Connect one end of the provided computer cable to the
in 2
connector on the projector and the other to the VGA connector on your computer. If
you are using a desktop computer, you will need to disconnect the monitor cable from the
computer's video port first.

HDMI connection

HDMI is a standard, uncompressed, all-digital audio/video interface. HDMI provides an
interface between sources, such as set-top boxes, DVD players, and receivers and your
projector. Plug an HDMI cable into the video-out connector on the video device and into the
HDMI connector on the projector.

Connecting power

Connect the black power cord to the
your electrical outlet. If the Power Saving Mode feature is off, the Power LED on the Status
Indicator Panel (page 11) blinks blue. If the Power Saving Mode feature is on, the Power LED
is steady blue. By default, this feature is off. You can change the setting, see page 28
Always use the power cord that shipped with the projector.

Optional computer connections

To get sound from the projector, connect an audio cable (optional cable, not included) to
Audio in
your computer and to the
adapter.
If you are using a desktop computer and want to see the image on your computer screen as
well as on the projection screen, connect to the desktop's computer cable to Computer 1
and the desktop's monitor cable to the Computer out connector on the projector.
Computer in 1/Computer
Power
connector on the rear of the projector and to
connector on the projector. You may also need an
connect VGA cable
connect HDMI
connect power
. NOTE
:
connect audio cable
7
