Summary of Contents for InFocus in1144
-
Page 2: Safety Warnings
afety arnIngS Avoid staring/facing directly into the projector beam at all times. Keep your back to the beam as much as possible. A stick or laser pointer is recommended to avoid the need for the user to enter the beam. When projector is used in a classroom, adequately supervise students when they are asked to point out something on the screen. -
Page 3: Fcc Warning
DLP® and the DLP logo are registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of Texas Instruments. Microsoft, PowerPoint, and Windows are trademarks or registered trademarks of Microsoft Corporation. Adobe and Acrobat are trademarks or registered trademarks of Adobe Systems Incorporated. InFocus, In Focus, and INFOCUS (stylized) are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries. -
Page 4: A Ccessory O Verview
roDuct vervIeW roDuct vervIeW Remote Control 1. Power Button 2. Up Button 3. Auto Source Button 4. Menu Button 5. Enter Button 6. Left Button 7. Right Button 8. Zoom Button 9. Aspect Ratio Button 10. Down Button 11. PC Button / Conference clear 12. - Page 5 - vga / HDmI SD c DjuSt rojecteD mage eIgHt onnect nput ource nSert Insert an SD card into the slot with the gold contacts facing down. The projector is equipped with an elevator foot for adjusting the projected Note image height.
-
Page 6: How To Use The Menu
oW to Se tHe Remote Control Home menu Up Button Menu Button Enter Button Auto Source Button Left Button Right Button Down Button Control Panel Up Button Press p/q to select the menu item that you want to Menu Button access and press u to enter the menu screen. - Page 7 IeWIng HotoS Viewing Photos from the USB Flash Drive or SD Card Select Data Source Enter Home Menu Change data source Select Photo File Preview File Browse file Select [Photo] Full Screen mode (see page 8) Note The displayed screen may vary depending on the data source selected in the previous step.
-
Page 8: Adjust Settings
IeWIng HotoS creen ISplay If the slide show function is enabled, photos are played continuously at specified intervals. Note • The button guide disappears when the keypad is not used for 3 seconds. To display the button guide, press any key. •... - Page 9 layIng IDeoS Playing Videos from the USB Flash Drive or SD Card Select Data Source Enter Home Menu Change data source Select Video File Select [Video] Playback File Video Playback mode (see page 10) Note The displayed screen may vary depending on the data source selected in the previous step.
-
Page 10: Ideo S Ettings
layIng IDeoS IDeo layBack Note The button guide disappears when the keypad is not used for 3 seconds. To display the button guide, press any key. Media Playback Control Pause/Resume Fast forward Exit playback Rewind IDeo ettIngS Enter Home Menu Enter Settings Menu Adjust Settings p/q: Select item... -
Page 11: Playing Music
layIng uSIc Playing Music from the USB Flash Drive or SD Card Select Data Source Enter Home Menu Change data source Select Audio File Select [Audio] Playback File Music Playback mode (see page 12) Note The displayed screen may vary depending on the data source selected in the previous step. -
Page 12: Music Settings
layIng uSIc uSIc layBack Note The button guide disappears when the keypad is not used for 3 seconds. Media Playback Control To display the button guide, press any key. Pause/Resume Fast forward Exit playback Rewind uSIc ettIngS Enter Home Menu Enter Settings Menu Adjust Settings p/q: Select item... - Page 13 IeWIng ocumentS Viewing Documents from the USB Flash Drive or SD Card Select Data Source Enter Home Menu Change data source Select File Select [Office viewer] View File View mode (see page 14) Note The displayed screen may vary depending on the data source selected in the previous step.
- Page 14 IeWIng ocumentS Note Full screen view The button guide disappears when the keypad is not used for 3 seconds. To display the button guide, press any key. Media Playback Control Page up Move to the right Page down Enter Display mode Move to the left Enter Advanced menu mode Advanced menu mode...
- Page 15 uSB D ISplay Enter Home Menu Enter EZ Display Menu Connect to PC Select [EZ Display] Connect the USB cable View PC Display Select [USB display] Note The computer will automatically detect the connection and install the necessary driver.
- Page 16 ISplay Note Select [EZ Display] Select the dongle name listed in the Wireless When using the Wi-Fi Display function for the first time, download and install Network Connection list on the PC. EZ WiFi Display Tool software into your PC: From the Windows desktop, double-click "Windows OS".
-
Page 17: Menu Operation
DjuSt ettIngS for xternal nput ource Selecting Input Source Once a video source device is connected and turned on, press on the remote control or on the control panel to automatically switch the input source. Sources are available in the following order: 1. - Page 18 SIng Refer to the table below for menu item details. Menu Menu item Description Display Mode Set the brightness of the display. Brightness Adjust the brightness of the image. Contrast Adjust the contrast of the image. Tint Adjust the balance of the red, green, and blue colors of the image. Sharpness Adjust the sharpness or softness of the image.
- Page 19 eDIa upport Video Photo image Type (Ext name) Sub Type Encode Type Max Pixels File Type Video Resolution Bit Rate Frame Rate Audio Code Remark YUV400 No Limit XVID YUV420 No Limit No VC 1AP support MPEG4 Baseline YUV422 No Limit MPEG1/2/3 H.264 1080P...
-
Page 20: Specifications
Power Input AC adapter 100~240 V Power Consumption Typical 85W@110Vac Standby <0.5W Lamp Lamp Life 20,000 Hours Speakers 2Wx1 VGA (15 pin D-sub) HDMI Input Ports A/V In 3.5mm SD card Security Kensington Slot Regulatory Model: IN1144 www.infocus.com/support Part Number: 4J.10410.001...
