- Page 1 in100...
-
Page 2: Declaration Of Conformity
EU member states. Please follow the guidance of your local environmental authority or ask the shop where you purchased the product Input ratings: 100-240Vac, 3.2A, 50-60Hz for collection or recycling options. InFocus reserves the right to alter product offerings and specifications at any time without notice. -
Page 3: Table Of Contents
Table of Contents Positioning the projector Connecting a computer source VGA connection HDMI connection Connecting power Optional computer connections Displaying an image Adjusting the image Connecting a video device Video device connections Composite video connection VGA connection Component video connection S-video connection Shutting down the projector Troubleshooting your setup... -
Page 4: Important Operating Considerations For Safety
Place the projector in a horizontal position no greater than 15 degrees off • Only genuine InFocus lamps are tested for use in this projector. Use of non axis. InFocus lamps may cause electrical shock and fire, and may void the projector •... -
Page 5: Product Specifications
It is a versatile projector that is flexible enough for business presentations and home video focus viewing too. IN122ST has native SVGA 800 x 600 resolution, IN124ST has native XGA 1024 x 768 resolution, and IN126ST has native WXGA 1280 x 800 resolution. It is compatible with a wide variety of computers and video devices. -
Page 6: Connector Panel
Monitor out, for VGA pass through to an external monitor. • Audio input for video and computer. • Audio output to external speakers. • RS232 serial control. Command control codes are on our support website at www.infocus.com/support. composite security lock monitor video... -
Page 7: Positioning The Projector
Here are some general guidelines: (inches/m) (inches/m) • Position the projector on a flat surface at a right angle to the screen. IN122ST 50”/1.3m 40”/1.0m 24”/0.6m and IN124ST must be at least 24” (0.6m) from the projection screen, and 65”/1.6m... -
Page 8: Connecting A Computer Source
Connecting a computer source connect VGA cable VGA connection Computer in 1/Computer Connect one end of the provided computer cable to the in 2 connector on the projector and the other to the VGA connector on your computer. If you are using a desktop computer, you will need to disconnect the monitor cable from the computer’s video port first. -
Page 9: Displaying An Image
Displaying an image press Power button Power Press the button. The Power LED lights blue, and the fans start to run. When the lamp comes on, the start up screen displays. It can take up to a minute for the image to achieve full brightness. Note: When the feature, AC Power On, is enabled, the projector automatically turns on when power is connected. -
Page 10: Adjusting The Image
IN122ST/IN124ST IN126ST If the left or right side of the screen is larger or smaller the other, you can turn the projector to the left or to the right a few degrees to square the image. -
Page 11: Connecting A Video Device
Aspect Ratio setting is accessed through the Resize button on the remote or through the projector’s Basic Menu. See page 25 for more information. Video device connections No video cables are provided with the projector. You can order cables from InFocus or provide your own. HDMI connection HDMI is a standard, uncompressed, all-digital audio/video interface. -
Page 12: Shutting Down The Projector
The lamp failed to ignite. POWER: Solid blue Contact Technical Support if the problem TEMP/LAMP: Blinking pink persists. Visit www.infocus.com/support to contact service. POWER: Solid blue The lamp has reached its end of life and must be replaced. The lamp will continue TEMP/LAMP: Blinking red to operate until it fails. - Page 13 Problem Solution Result No start up screen Correct image Plug power cord into the projector press power button Computer image projected Only start up screen appears Press the Source button activate laptop’s external port Restart laptop...
- Page 14 Problem Solution Result Press the Auto Image button on remote Computer image projected No computer image, just the words “Signal out of Adjust computer refresh rate (Windows 7: Control range” Panel > Display > Screen Resolution > Advanced Settings > Adapter tab). Varies per operating system. You may also need to set a different resolution on your computer, as shown in the following problem, “image fuzzy or cropped”...
- Page 15 (Windows 7: Control Panel > Display > Screen Resolution). Varies per operating system. Move projector, adjust height Correct image Image not centered on screen MDL: IN122ST FW: 1.28 Force Wide Adjust horizontal or Phase Prevent PC Screen Saver...
- Page 16 Problem Solution Result Image not square Adjust Keystone on keypad Square image Adjust Sharpness in the Basic Menu Image not sharp Correct image Basic Menu MDL: IN122ST FW: 1.28 Aspect Ratio Auto Auto Image Execute Brightness Contrast Keystone Presets Presentation...
- Page 17 Problem Solution Result Turn off Ceiling Mount in Basic menu Correct image Image upside down Basic Menu MDL: IN122ST FW: 1.28 Aspect Ratio Auto Auto Image Execute Brightness Contrast Keystone Presets Presentation Sharpness Volume Ceiling Mount ◄ Off ► Advanced Menu Turn off Rear Project in Advanced Menu >...
- Page 18 Problem Solution Result Turn off the internal LCD display on your laptop The video embedded in my PowerPoint presentation Embedded video plays correctly does not play on the screen Make sure vents aren’t blocked, turn off the projector Lamp turns on Lamp won’t turn on, the projector is overheating and allow it to cool for one minute Overheating...
- Page 19 Still need assistance? www.infocus.com/support If you need assistance, visit our website at or call us. See the Warranty/Safety booklet for support contact information. This product is backed by a limited warranty. An extended warranty plan may be purchased from your dealer.
-
Page 20: Using The Remote Control
Using the remote control • Auto Image button to resynch the projector to the source. • Resize button to switch among aspect ratios (see page 25). The remote uses two (2) AAA batteries (not provided). They are easily installed by •... -
Page 21: Using The Audio
Using the audio connect audio cable Using the projector’s speaker Connect the audio source to the Audio In connectors to hear audio through the projector speaker. Amplified speakers may also be connected to the projector using the Audio Out connector. To adjust the volume, press the Volume buttons on the remote. -
Page 22: Using The Keypad Buttons
Using the keypad buttons Most buttons are described in detail in other sections, but here is an overview of their functions: Power–turns the projector on and off (page 8). Right arrow/Presets - When the menu is displayed, the right arrow button navi- gates through the menu. -
Page 23: Optimizing Computer Images
Optimizing computer images Presentation features After the projector is running and the image is on the screen, you can optimize the Several features are provided to make giving presentations easier. Here is an image using the onscreen menus. For general information on using the menus, see overview, details are found in the menu section. -
Page 24: Optimizing Video Images
Optimizing video images Customizing the projector After your video device is connected properly and the image is on the screen, you You can customize the projector for your specific setup and needs. See page 27 for can optimize the image using the onscreen menus. For general information on details on these features. -
Page 25: Using The Menus
Press the Menu button to exit the menu system. The menus are grouped by usage: • The Basic Menu provides common adjustments. • The Advanced Menu provides more complex adjustments. Advanced Menu Basic Menu MDL: IN122ST MDL: IN122ST FW: 1.28 FW: 1.28 Image 3D Control... Aspect Ratio Auto... -
Page 26: Basic Menu
Basic Menu Basic Menu Basic Menu MDL: IN122ST To adjust the following settings, highlight the setting, use the right and left arrows FW: 1.28 to adjust the values. Aspect Ratio Auto Execute Auto Image Aspect Ratio: Aspect ratio is the ratio of the image width to image height. TV Brightness screens are usually 4:3. -
Page 27: Advanced Menu
When Auto is selected, the projector automatically determines the standard. Advanced Menu Advanced Menu MDL: IN122ST To choose a different setting, turn off Auto, then choose RGB for computer FW: 1.28 sources or choose either REC709 or REC601 for component video sources. - Page 28 Overscan: removes noise around the video image. • Mute : turns off all sound. Source • : brings up a menu of available sources. Set Black Level: analyzes the current input image and calculates an offset value which is then added to the analog to digital converter black level value. Auto Image •...
- Page 29 If you lose or forget your custom PIN, contact screen at startup, and when no source is detected. InFocus Technical Support. To enter the PIN at projector startup: Power up the projector. The “Enter PIN” dialog box displays after the startup screen.
- Page 30 Timer Auto Off Time: automatically turns the projector off after no signals are detected for a preset number of minutes. If an active signal is received before the projector powers down, the image will be displayed. High Altitude Setting High Altitude Setting: We recommend you turn on the High Altitude Mode when your environment is between 5000' (1500m) and 10,000' (3000m) above sea level.
-
Page 31: Maintenance
Maintenance Cleaning the lens Apply a non-abrasive camera lens cleaner to a soft, dry cloth. • Projector must be off and the lens must be at room temperature. • Avoid using an excessive amount of cleaner, and don’t apply the cleaner directly to the lens. -
Page 32: Replacing The Projection Lamp
“Replace lamp” displays on the screen at startup. • NOTE: Be sure to use the InFocus lamp module designed for this projector. You can order new lamps from www.infocus.com (in select areas), your retailer or your dealer. Only genuine InFocus lamps are tested for use in this projector. - Page 33 Replace the lamp door by (a) aligning the hinges, (b) putting the lamp door down and (c) locking it back into place. Replace the lamp door screw and tighten securely. Advanced Menu MDL: IN122ST FW: 1.28 Plug in the power cord and press the Power button to turn the projector back Image Source Info...
