Models:
SL-750TRS-IPI-D
SL-550TRS-IPI-D
SL-350TRS-C
Important operating and
maintenance instruc-
tions included.
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing proper-
ty damage, personal injury, or death.
• Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
• What to do if you smell gas
- Do not try to light any appliance
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
This appliance may be installed as an OEM installation in
manufactured home (USA only) or mobile home and must
be installed in accordance with the manufacturer's instruc-
tions and the manufactured home construction and safety
standard, Title 24 CFR, Part 3280 or Standard for Installa-
tion in Mobile Homes, CAN/CSA Z240MH.
This appliance is only for use with the type(s) of gas indi-
cated on the rating plate.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • SL-350TRS-C, SL-550/750TRS-IPI-D • 2065-985 Rev. J • 5/06
Owner's Manual
Installation and Operation
Leave this manual with
party responsible for
use and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as
appliance.
• Alert children and adults to hazards of high
temperatures.
• Do NOT operate with protective barriers open or
removed.
• Keep clothing, furniture, draperies and other
combustibles away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fixed glass panel. Do
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts:
• installation must be performed by a licensed plumber or
gas fitter;
See Table of Contents for location of additional
Commonwealth of Massachusetts requirements.
Installation and service of this appliance should be
performed by qualified personnel. Hearth & Home
Technologies suggests NFI certified or factory-trained
professionals, or technicians supervised
by an NFI certified professional.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-750TRS-IPI-D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Heat & Glo SL-750TRS-IPI-D

  • Page 1 Owner’s Manual Installation and Operation Models: SL-750TRS-IPI-D SL-550TRS-IPI-D SL-350TRS-C CAUTION DO NOT DISCARD THIS MANUAL • • • Important operating and Read, understand and follow Leave this manual with maintenance instruc- these instructions for safe party responsible for tions included.
  • Page 2: Safety And Warning Information

    SAFETY AND WARNING INFORMATION These units MUST use one of the vent systems READ and UNDERSTAND all instructions carefully described in the Installing the Appliance section of before starting the installation. FAILURE TO the Installers Guide. NO OTHER vent systems or FOLLOW these installation instructions may result components MAY BE USED.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Safety and Warning Information ............2 Service Parts Lists ................. 4 Section 1: Approvals and Codes ............12 Appliance Certification ................12 Installation Codes .................. 12 High Altitude Installations ..............12 Requirements for the Commonwealth of Massachusetts ......13 Section 2: Getting Started ..............
  • Page 4: Service Parts Lists

    SL-350TRS-C Service Parts Beginning Manufacturing Date: 4-01 (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: ______ Log Set Assembly Part number list on following page. Heat & Glo • SL-350TRS-C, SL-550/750TRS-IPI-D • 2065-985 Rev. J • 5/06...
  • Page 5 SL-350TRS-C (NG, LP) Service Parts List IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When order- ing, supply serial and model numbers to ensure correct service parts. ITEM STANDING PILOT SERIAL # PART NUMBER Burner Orifice NG (#43C) 582-843...
  • Page 6: Service Parts

    SL-350TRS-C Service Parts (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 4-01 Ending Manufacturing Date: ______ Standing Pilot Ignition Valve Assembly ITEM DESCRIPTION SERIAL # PART NUMBER Piezo Ignitor 291-513 Burner Neck Gasket 2045-407 00251404 Thermostat Wire Assembly POST 00251404 2045-024 Pilot Assembly NG 530-510A...
  • Page 7 SL-550TRS-IPI-D Service Parts (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 4-04 Ending Manufacturing Date: ______ Log Set Assembly Part number list on following page. Heat & Glo • SL-350TRS-C, SL-550/750TRS-IPI-D • 2065-985 Rev. J • 5/06...
  • Page 8 (NG, LP) Service Parts List SL-550TRS-IPI-D IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM DESCRIPTION SERIAL # PART NUMBER Burner Orifice NG (#38C) 582-838 Burner Orifice LP (#53C)
  • Page 9 Service Parts SL-750TRS-IPI-D (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 4-04 Ending Manufacturing Date: ______ Log Set Assembly Part number list on following page. Heat & Glo • SL-350TRS-C, SL-550/750TRS-IPI-D • 2065-985 Rev. J • 5/06...
  • Page 10 SL-750TRS-IPI-D (NG, LP) Service Parts List IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When order- ing, supply serial and model numbers to ensure correct service parts. ITEM DESCRIPTION SERIAL # PART NUMBER...
  • Page 11 Service Parts SL-750TRS-IPI-D, SL-550TRS-IPI-D (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 4-04 Ending Manufacturing Date: ______ Intermittent Pilot Ignition Valve Assembly ITEM / SERIAL # PART NUMBER DESCRIPTION PIÈCE / N° DE SÉRIE / N° DE PIÈCE Burner Neck Gasket / Joint de Cou de Brûleur 2045-407 Thermostat Wire Assembly / L'Assemblée de Fil de thermostat...
  • Page 12: Section 1: Approvals And Codes

    Certification feet, it may be necessary to decrease the input rating by changing the existing burner orifice to a smaller size. Input MODELS: SL-750TRS-IPI-D, SL-550TRS-IPI-D, rate should be reduced by 4% for each 1000 feet above a SL-350TRS-C 2000 foot elevation in the U.S.A. or 10% for elevations between 2000 and 4500 feet in Canada.
  • Page 13: Requirements For The Commonwealth Of Massachusetts

    Inspection NOTE: The following requirements reference various The state or local gas inspector of the side wall horizontally Massachusetts and national codes not contained in vented gas fueled equipment shall not approve the installa- this document. tion unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with Requirements for the Commonwealth of the provisions of 248 CMR 5.08(2)(a)1 through 4.
  • Page 14: Section 2: Getting Started

    Getting Started Introducing the Heat & Glo Gas Appliances The Heat & Glo Warranty will be voided by, and Heat & Glo disclaims any responsibility for, the following actions: Heat & Glo direct vent gas appliances are designed to op- •...
  • Page 15 1041.4 TOP STANDOFFS VENT COLLARS HOOD CERAMIC FIBER PAD RATING PLATES & LABELS BOTTOM GRILLE GAS LINE ELECTRICAL COVER ACCESS CONTROLS ACCESS Figure 1. Diagram of the SL-750TRS-IPI-D Heat & Glo • SL-350TRS-C, SL-550/750TRS-IPI-D • 2065-985 Rev. J • 5/06...
  • Page 16 25-3/4 1/2 13 12-7/8 16-1/4 15-7/8 8-13/16 168.3 ø 8 ø 6-5/8 168.3 5-1/2 35-7/16 3-1/2 900.1 2-1/8 32-1/8 32-9/16 GAS LINE ELECTRICAL ACCESS ACCESS 31-1/8 6-7/8 TOP STANDOFFS VENT COLLARS HOOD CERAMIC FIBER PAD RATING PLATES & LABELS BOTTOM GRILLE GAS LINE ELECTRICAL COVER...
  • Page 17 22-3/4 577 1/2 13 11-3/8 289 16-1/4 15-7/8 402 8-3/4 ø8 [203] ø 6-5/8 168.3 34-1/2 30-5/8 15-1/4 3-1/2 30-1/2 2-1/8 21-1/4 28-1/8 GAS LINE ELECTRICAL ACCESS ACCESS 6-7/8 TOP STANDOFFS VENT COLLARS HOOD CERAMIC FIBER PAD RATING PLATES & LABELS BOTTOM GRILLE GAS LINE ELECTRICAL...
  • Page 18: Section 3: Installing The Appliance

    Gas line holes and other openings should be *Top 3 1/4 ... 83 caulked or stuffed with insulation. If the unit is being in- (SL-750TRS-IPI-D) .......... 1 1/2 ... 38 stalled on a cement slab, a layer of plywood may be placed (SL-550TRS-IPI-D, SL-350TRS-C) ....
  • Page 19: Step 2 Framing The Appliance

    (1) inch (25.4mm) above the center of the hori- zontal vent pipe. Framing should be constructed of 2 X 4 lumber or heavier. Models SL-750TRS-IPI-D 42” 38 1/4” 16 1/4” 41” 27 7/8” SL-550TRS-IPI-D 37” 33”...
  • Page 20 DVP4 DVP6 DVP12 14-1/4 12-3/16 MAX. MIN. DVP12A 9-7/8 DVP24 45.0 10-1/4 DVP45 DVP36 11-1/4 7-1/4 1-1/4 TYP DVP48 8-9/16 1/2 TYP 12-9/16 NOTE: PIPES OVERLAP 1-1/4 INCHES (34.93mm) AT EACH JOINT. Figure 6. DVP-Series Direct Vent Component Specifications (5-inch inner pipe / 8-inch outer pipe) Heat &...
  • Page 21 6 1/2 6 3/8 9 1/4 6 1/2 9 5/8 6 3/8 6 5/8 SL-45D 6 5/8 9 5/8 SL-90D SL-09D SL-12/17D (SL12-17D) SL-24D SL-48D SL-36D 8 3/4 12-17 23 3/4 35 3/4 47 3/4 17-24 6 1/2 11 3/4 5 3/4 6 5/8 SL-17/24D...
  • Page 22: Step 3 Installing The Vent System

    Step 3. Installing the Vent System WARNING: YOU MUST NOT MIX DVP-SERIES AND SL D-SERIES COMPONENTS IN ANY VENT A. Vent System Approvals SYSTEM CONFIGURATION. These models have vent starting collars on both the top and the back of the unit. Depending upon the installation, Identifying Vent Components decide which ONE set of starting collars will be used to Approved vent system components are labeled for identifi-...
  • Page 23 Flex Vent The flex vent must be supported with the spacing between STRAIGHT UP support intervals not exceeding 4 feet, with no more than ½ VERTICAL VENTING inch sag between supports. V (FT.) A support is required at each change in venting direction, 45' MAX.
  • Page 24 1' MIN. (305mm) 2' MAX. (610mm) 2' MIN. (610mm) 4' MAX. (1.22m) 3' MIN. (914mm) 6' MAX. (1.86m) 4' MIN. (1.22m) 8' MAX. (2.4m) V+H=40' MAX. (12.4m) H = 8' MAX. (2.4m) Use DVP-Series components only. Figure 12. Venting with One 90° Elbow Use SL D-Series components only.
  • Page 25 H + H 1' MIN. (305 mm) 2' MAX. (610 mm) 4' MAX. (1.22m) 2' MIN. (610 mm) 4' MAX. (1.22 m) 8' MAX. (2.4m) 3' MIN. (914 mm) 6' MAX. (1.86 m) 12' MAX. (3.6m) 4' MIN. (1.22 m) 8' MAX.
  • Page 26 VENTING WITH TWO (2) 90 ELBOWS NATURAL GAS MODEL: SL-350TRS-C MODELS: SL-550TRS-D, SL-750TRS-D V (MIN.) H + H (MAX.) H + H (MAX.) Elbow on Top 2.5 FT (762mm) 2 FT (610mm) 1 FT (305mm) 3 FT (914mm) 3 FT (914mm) 2 FT (610mm) 4 FT (1.22m) 4 FT (1.22m)
  • Page 27 VENTING WITH TWO (2) 90 ELBOWS NATURAL GAS MODELS: SL-550TRS-D, SL-750TRS-D MODEL: SL-350TRS-C H (MAX.) V (MIN.) H (MAX.) 2 FT (610mm) Elbow on Top 2.5 FT (762mm) 3 FT (914mm) 1 FT (305mm) 3 FT (914mm) 4 FT (1.22m) 2 FT (610mm) 4 FT (1.22m) 6 FT (1.86m)
  • Page 28 H + H 1' MIN. (305 mm) 2' MAX. (610mm) 4' MAX. (1.22m) 2' MIN. (610 mm) 4' MAX. (1.22m) 8' MAX. (2.48m) 3' MIN. (914 mm) 6' MAX. (1.86m) 12' MAX. (3.72m) 4' MIN. (1.22 m) 8' MAX. (2.48m) 16' MAX.
  • Page 29 VENTING WITH THREE (3) 90 ELBOWS NATURAL GAS MODEL: SL-350TRS-C MODELS: SL-550TRS-D, SL-750TRS-D V (MIN.) H (MAX.) H + H (MAX.) H (MAX.) H + H (MAX.) Elbow on Top 2.5 FT (762mm) 4 FT (1.22m) 2 FT (610mm) 4 FT (1.22m) 1 FT (305mm) 3 FT (914mm) 6 FT (1.86m)
  • Page 30 VENTING WITH THREE (3) 90 ELBOWS NATURAL GAS MODEL SL-550TRS-D MODEL SL-750TRS-D V (MIN.) H + H (MAX.) H + H (MAX.) Elbow on Top 2 FT (610mm) 2 FT (610mm) 1 FT (305mm) 3 FT (914mm) 3 FT (914mm) 2 FT (610mm) 4 FT (1.22m) 4 FT (1.22m)
  • Page 31 90° VENTING WITH FOUR (4) ELBOWS NATURAL AND PROPANE GAS V (MIN.) H (MAX.) (MIN.) (MAX.) (MIN.) 5' (1.52m) 5' (1.52m) 4.5' (1.37m) 2' (609mm) 5' (1.52m) V + V + H + H MAX. = 40' (12.2m) Use SL D-Series components only.
  • Page 32: Installing Vent Components

    B. Installing Vent Components DVP Series Venting Only: After determining which set of starting collars will be used 1. Attaching the Venting to the Appliance (top or rear), follow venting instructions accordingly. Refer to Cinch Pipe and Termination Cap installation in- NOTE: The SL-350TRS-C and SL-350TRS-C LP are built structions.
  • Page 33 SL-D and SL-Flex Series Venting Only: 1. Attach the First Vent Component to the Starting Collars To attach the first vent component to the starting collars of the appliance: • Lock the vent components into place by sliding the con- centric pipe sections with four (4) equally spaced interior beads into the appliance collar or previously installed com- ponent end with four (4) equally spaced indented sections.
  • Page 34 DVP, SL-D and SL-Flex Series Venting: For Vertical Runs - One ceiling firestop is REQUIRED at the hole in each ceiling through which the vent passes. STEP 4. Install Firestops To install firestops for vertical runs that pass through ceilings: For Horizontal Runs - Firestops are REQUIRED on both sides of a combustible wall through which the vent passes.
  • Page 35: Vent Termination

    C. Vent Termination If the area above the ceiling is NOT an attic, position and secure the ceiling firestop on the ceiling side of the previously SL-Series Venting Only: cut and framed hole. For Horizontal Terminations - To attach and secure the termination to the last section of horizontal vent: •...
  • Page 36 (See Note 2) U.S. (3 FT) Electrical Service J or K = VENT TERMINAL = AREA WHERE TERMINAL IS NOT PERMITTED = AIR SUPPLY INLET = 12" ....... clearances above grade, veran- = 3 ft. (U.S.A.) (See Note 1) da, porch, deck or balcony 6 ft.
  • Page 37 For Vertical Terminations - To locate the vent and install To seal the roof hole, and to divert rain and snow from the vent system: the vent sections: • Locate and mark the vent centerpoint on the underside • Attach a flashing to the roof using nails, and use a non- of the roof, and drive a nail through the centerpoint.
  • Page 38: Step 4. Positioning, Leveling, And Securing The Appliance

    Step 4. Positioning, Leveling, and Step 5. The Gas Control Systems Securing the Appliance WARNING: THIS UNIT IS NOT FOR USE WITH The diagram below shows how to properly position, level, SOLID FUEL. and secure the appliance. The two types of gas control systems used with this model: Standing Pilot Ignition and Intellifire Pilot Ignition (IPI).
  • Page 39: Step 6 The Gas Supply Line

    Step 6. The Gas Supply Line NOTE: Have the gas supply line installed in accordance with local building codes by a qualified installer approved and/or licensed as required by the locality. (In the Commonwealth of Massachusetts installation must be performed by a licensed plumber or gas fitter).
  • Page 40: Step 8 Wiring The Appliance

    Optional Accessories Step 8. Wiring the Appliance Optional fan and remote control kits require that 110-120 NOTE: Electrical wiring must be installed by a licensed VAC be wired to the factory installed junction box before electrician. the appliance is permanently installed. CAUTION: DISCONNECT REMOTE CONTROLS IF AB- SENT FOR EXTENDED TIME PERIODS.
  • Page 41 For Intermittent Pilot Ignition (IPI) Wiring Wiring to the battery pack should be left disconnected in order to conserve battery life. In the case of a loss of power, Appliance Requirements simply connect red and black wire leads to activate battery power (connect red to red, black to black).
  • Page 42: Step 9 Finishing

    VARIABLE SPEED CONTROL NOTE: IF ANY OF THE ORIGINAL WIRE AS SUPPLIED WITH THE APPLIANCE MUST BE REPLACED, IT MUST BE JUNCTION BOX REPLACED WITH TYPE 105 C RATED WIRE. BLOWER RECEPTACLE GROUND TEMPERATURE BLOWER SENSOR SWITCH SENSOR BLOWER SWITCH 110-120 VAC “FAN”...
  • Page 43: Step 10 Installing Trim, Logs, And Ember Material

    GLASS SPECIFICATIONS: If the gas logs have been factory installed they should not need to be positioned. If the logs have been packaged SL-750TRS-IPI-D ..........CERAMIC separately, refer to the instructions that accompany the SL-550TRS-IPI-D ..........CERAMIC logs. Save the log instructions with this manual.
  • Page 44: Step 11 Before Lighting The Appliance

    Step 11. Before Lighting the Appliance During this break-in period it is recommended that some windows in the house be opened for air circulation. This will Before lighting the appliance, be sure to do the following: help avoid setting off smoke detectors, and help eliminate Remove all paperwork from underneath the appliance.
  • Page 45: Section 4: Maintaining And Servicing Your Appliance

    Maintaining and Servicing Your Appliance Appliance Maintenance Cleaning Flame Sensor Rod (IPI Systems) Although the frequency of your appliance servicing and main- Frequency: Periodically. tenance will depend on use and the type of installation, you should have a qualified service technician perform an appli- By: Qualified service technician.
