Foxda FM-6606 User Manual

Digital mp3 player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FM-6606
User Manual
D i g i t a l M p 3 P l a y e r

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM-6606 and is the answer not in the manual?

Questions and answers

Related Manuals for Foxda FM-6606

Summary of Contents for Foxda FM-6606

  • Page 1 FM-6606 User Manual D i g i t a l M p 3 P l a y e r...
  • Page 2 Thank you for purchasing Foxda We strongly recommend you to read through digital Mp3 Player. Please read this manual before connecting this machine with any PC. If you want to connect this player through the user manual carefully beforeoperating the machine in with the PC, please first connect the USB order tomaximize the ability and cable to the player and then to the PC.

  • Page 3: Table Of Contents

    Content Note........1 Communication with Computer Connection......29 Overview Installation......30 Download......31 MP3 Player.......3 Remove.........32 LCD.........4 Formatting......33 Earphone......5 Features......6 Technical Spec....7 FAQ........34 Operational Notes.....8 Menu Overview.......35 Operation Notes Battery/Power on or off..9 Operation MODE....10 Operation Notes....

  • Page 4: Note

    OVERVIEW This player is an MP3 player and fashionable appearance. It is user-friendly, easy to operate and provides recoding, music playing and repeating function. Player overview 1.Neck Strap Loop 2.Earphone/USB port/CD Line-in Jack 3.Internal Microphone 4.Function key(play/stop FF/RW Vol+/Vol-) 5.LCD 6.EQ/REC 7.Menu 8.Battery Cover...
  • Page 5 1.Status indicator 001-02:26/03:63 2.Holding state 3.Song Number 4.Playing status column V O L 1 5 5. Current Music playing time 6.Total playing time 7.Battery power level 8.Function status 9.Song information 10.Volume Earphone overview 1.Ear piece 2.USB cable 3.CD Line-in...

  • Page 6: Earphone

    Accessories 1.USB cable 5.CD-ROM 2.Earphone 6.Neck Strap 3.Manual 7.CD Line-in cable 4.AAA battery Features Small in size, all-round functions One jack for USB, earphone and CD Line-in connection (patent) Online FM recording CD Line-in Animation Menu Playback MP3/ WMA multi-format files Equalizer mode options: Normal, Classic, Jazz, Pop, Rock, DBB.
  • Page 7 Data reference Size 24 x 70 mm Weight 26 g Power Source 1.5V "AAA" Alkaline Batt. Frequency Range (+-1db) 20Hz - 20KHz Frequency 8 KHz - 48 KHz Encode ISO 11 172-3 (MPEG 1.0 Layer 3) Bit Rate 64 kdps - 320 kdps Distortion (1Khz) 0.

  • Page 8: Operational Notes

    Operational Notes “ If the MP3 player will not be operated for a prolonged period, remove the battery to avoid possible damage caused by electrical leakage. “ The MP3 player should be kept in areas free from extreme temperature changes, moisture and dust.
  • Page 9 Operating Instructions...
  • Page 10 Load battery Open the battery compartment and load one AAA battery as directed by + and - . Change battery When the LCD displays Low Battery , it indicates a need of battery change. Turn off the machine before replacing a new battery. Turning the power on/off The OSD with green backlight appears when EQ/REC...
  • Page 11 Functional Options Music playing, voice playing & recording, radio function Press Menu to select music mode. Then press Menu again to confirm playing music (machine will automatically switch back to music mode if no operation for more than 10 seconds). Y ou can play Mp3 and WMA format files in this mode.
  • Page 12 Music playing functions 001-00:00/04:47 music.mp3 The default OSD is in stop status under music mode V O L 1 5 Play/Pause/Stop/FF/RW 001-01:00/04:47 Press function button to play, LCD displays as: music.mp3 V O L 1 5 Under playing music mode, LCD displays music mode Press function...
  • Page 13 VOL+/ VOL- Push the function button to + - ,you could control the volume under either Play or Pause mode. The volume steps (see illustration) will increase or decrease when then the VOL+/VOL- button is pressed corre spondingly. 002-01:00/03:27 002-01:00/03:27 music.mp3 music.mp3 Min volume...
  • Page 14 EQ setting Under the playing mode, press EQ/REC button for a period of time to select 6 different music modes: Normal 002-01:00/03:27 music.mp3 V O L 1 5 Jazz LCD displays as: Rock Classical Press this button a period for EQ set, short time for repeat A-B set Music/Voice information display: When in play/stop status, the display will show the information of music or voice files e.g.

  • Page 15: Advanced Function

    Advanced function...

  • Page 16: Music

    Advanced function Followed are the more advanced functions of our MP3 player . Press Menu button to select modes press MENU button and push upon + - select change to Music different modes item, LCD display as : Voice FM Tuner Line in Settings Erase Files...
  • Page 17 Music mode This is the default mode. Users can play MP3/WMA files under this mode. Users can also run repeat (Ref. P. 22) /A-B/RW/FF/V+,-/EQ setting in this mode. Voice mode Under music mode, press Menu button and push upon + to select voice mode then press Menu button to confirm .

  • Page 18: Start Recording

    Start Recording Under Voice Function, press EQ/REC button to start recording (build-in Microphone, microphone's position can be seen on P.2). The display is as follows: 1.Recording Function display 2.Name and track of recorded file /VOICE/V001.WAV 00:01:00 05:21:29 3.REC Function 05:20:29 V O L 1 5 4.Time of recorded file 5.Total time of recorded file...

  • Page 19: Fm Tuner

    FM Tuner Press Menu button and Push the function button to + to select FM tuner, and then press Menu to confirm.(Adjust the direction of earphone line to get better radio effect) Auto search Press 'menu' button to auto search and memorize up to 32 radio channels. V O L 2 5 FM fine tuner Push the function button to...
  • Page 20 FM Recording Press EQ/REC button to start recording the current listening radio channel. The display is shown below: 00:02:10 02:34:58 02:32:48 V O L 1 5 Record the current listening channel Playing recorded FM files Press Menu button to return to voice playing mode. Push the function button to to search for the recorded files and press play button to play the file.

  • Page 21: Cd Line-In

    Line-in recording function 1.Connection Use the CD line-in cable to connect the player with CD player (or other audio equipment) as shown below: 2.Recording Press Menu and then push + or - upon. Press Menu to confirm and start recording. At the same time, press the play button on the CD player and start the recording as shown below: /LINE-IN/L007.WAV...
  • Page 22 Settings Enter this mode according to the instructions on Page 15. Push the function button to + to select, and press Menu to confirm. Play Mode Contrast PowerSaving Backlight Backlight color Note: Except in record mode, you can select setting Language function both in play and stop mode.

  • Page 23: Play Mode

    Play Mode playing mode includes: Normal Push the function button to + to Repeat singlesong select, and press Menu to confirm. Repeat all MENU Shuffle play Shuffle repeat 3.Contrast User can customize the contrast setting for better visual effect. MENU CONTRAST Push the function button to + to...

  • Page 24: Backlight Color

    5.Backlight User can disable or change the backlight lasting time in this setting. Note: when low battery, backlight maybe wink. Push the function button to + to select, and press Menu to confirm. Disables 3Sec MENU 10Sec 6.Backlight color it contains the setting of seven backlight colors, you can select color preference. MENU...
  • Page 25 7.Language MENU Chinese Push the function button to Traditional Chinese to select, and press Menu to confirm. English 8.Exit When LCD displays Exit , press Menu to confirm, and return to setting mode.

  • Page 26: Erase Files

    Erase files Push the function button to to select, and then press Menu to confirm. MENU Erase music files Push the function button to + to Push the function button to + - to select File name the music files selection select yes or no , and then press...
  • Page 27 Erase voice files MENU Push the function button to + to Are you sure want to delete the file select yes or no , and then press Menu to confirm. Push the function button to + - to select When the files has been erased, you music files can see the display shown below Are you sure want to...
  • Page 28 About Please refer to P . 15 on how to enter this mode Production Model Firmware VER. MENU About Free memery Note: As some components would take up spaces in the flash memory, it is normal to find out that the available memory size is less than normal. Exit Please refer to P .

  • Page 29: Connection

    CONNECTION WITH COMPUTER...
  • Page 30 Requirements for computer system 1. Operating systems: Microsoft Windows 98 SE, Windows Me, Windows 2000, Windows NT, Windows XP 2. CPU: Intel Pentium 3, Pentium 4 or above CPU 3. Memory: 64 MB or above 4. HD: 200MB idle memory and above 5.

  • Page 31: Installation

    Installation of Driver After connecting with computer, Windows 2000/ME/XP will automatically identify and install the driver. The machine is ready to use when a removable drive icon appears in my computer . The attached CD-ROM is needed for Windows 98SE to install Driver. The icon will be displayed here after installation The icon will be displayed in...
  • Page 32 Save and rename music and voice files Ver 2.413.000 After successful connection between the machine and computer, it is displayed as READY Double-click removable disk, it is displayed as VOICE LINE IN FM file Music file Voice Voice Voice file Line in Line in Line in file...
  • Page 33 The operating procedure of the removable flash disk is the same as normal USB storage device. Users may copy files to relevant folder. You may also rename it for your own convenience The icon will move with importing or exporting Ver 2.413.000 WRITING It show when writing...

  • Page 34: Formatting

    Formatting Right click the removable disk icon then select mode to format. The machine may not be able to play music if FAT 32 NTFS mode selected. To recover, please format the machine again as mode. Press"Begin"button...
  • Page 35 General question&answer Suggested solutions Problems Possible causes Unable to switch No battery Change for new battery on the machine Place the battery appropriately Incorrect battery position Re-plug the earphone Loosen plug No audio output Increase the volume Volume is from the earphone Change the battery Check the battery status Clean the plug...
  • Page 36 MENU Press button to select FM Tuner Line in MUSIC VOICE Settings Erase Files About Exit Normal Music Voice Rock Normal Jazz Exit Repeat Track Play Mode Classical Repeat All Contrast Shuffle Disable Shuffle Repeat PowerSaving 1 Mins 2 Mins BackLight Disables 5 Mins...
  • Page 37 Hong Kong - Global Sales and Marketing Head Office Unit 1205, Tower 1 Lippo Centre, Admiralty, Hong Kong Tel: (852) 2521-6669 Fax: (852) 2521-2229 Canada office Office Address: #3200-8888 Odlin Crescent Richmond, B.C., Canada V6X 3Z8 Mailing Address: PO Box 88082, RPO Lansdowne Centre, 5300 No.
