- Page 1 FM-6605 FM-6605 User Manual D i g i t a l M p 3 P l a y e r...
- Page 2 Thank you for purchasing Foxda s MP3 player. Please read through the user manual carefullybefore operating the machine in order to maximizethe ability and life of our product. Please take goodcare of this manual for future reference. Theappearance of our players shown in the manual may differ from the actual products since all pictures are based on the prototype of our models.
-
Page 3: Table Of Contents
Note...1 Overview MP3 Player...3 LCD...4 Earphone...4 Features... 5 Technical Spec...6 Operational Notes...7 Operational Notes Battery/Power on or off...9 Operation MODE..10 Music..11-14 Voice...15-16 FM tuner...17-19 Content Communication with Computer Connection...21 Installation...22 Download...23-24 Disconnection...25 Formatting...25... -
Page 4: Overview
OVERVIEW This player is an MP3 player with removable storage hard disk and fashionable appearance. It is user-friendly, easy to operate and provides recoding, music playing and repeating function. Player overview 1.Earphone Jack 2.Neck Strap Loop 3.Internal Microphone 4.RW 5.PLAY 6.STOP... - Page 5 1.Repeat A-B display 2.Status indicator 3.Play mode display 001-004:02 4.Volume JAZZ 5.Hold Status 6.Power 7.Current music playing time 8.EQ 9.Song number 10.Function Earphone overview 1.Ear piece 2.USB cable 3.CD Line-in...
-
Page 6: Earphone
Accessories 1.USB cable 2.Earphone 3.Manual Features “ “ “ “ “ “ “ “ “ “ “ 4.CD-ROM 5.Neck Strap 6.CD Line-in cable Online FM recording CD Line-in Playback MP3/ WMA multi-format files Equalizer mode options: Normal, Class, Jazz, Pop, Rock, DBB. LCD display, blue light background. - Page 7 Data reference Size Weight Power Source Encode Bit Rate Frequency Frequency Range Distortion MP3 (Sound Track Separation) MP3 (Dynamic Range) Recorder Length Transfer Speed Delivery Speed Power 69 x 31 x 16 mm 25 g 1.5V "AAA" Alkaline Batt. ISO 11172-3 (MPEG 1.0 Layer 3) 64 kdps - 320 kdps 8 KHz - 48 Khz (+ -1db) 20Hz - 20KHz...
-
Page 8: Operational Notes
Operational Notes “ If the MP3 player will not be operated for a prolonged period, remove the battery to avoid possible damage caused by electrical leakage. “ The MP3 player should be kept in areas free from extreme temperature changes, moisture and dust. - Page 9 Operating Instructions...
- Page 10 Load battery Open the battery compartment and load one AAA7 battery as directed by "+"and"-" Change battery When the LCD displays Low Battery it indicates a need of battery change. Turn off the machine before replacing a new battery. Turning the power on/off The HELLO greeting appears when backlight to stay on is depending on user preference.
-
Page 11: Functional Options
Functional Options Music playing, voice playing & recording, radio function Press Function to enter music mode (default setting). You can play Mp3 and WMA format files in this mode. Function Press button again to enter voice mode. Press Function button again to enter FM Tuner mode. 001-004:02 017-001:09 01 88.60... -
Page 12: Music
Music playing functions The default OSD is in stop status under music mode Play/Pause/Stop/FF/RW Press Play/Stopbutton to play, LCD displays Press Play/Stop button Under pause mode, press down Play/Stop button for 3 seconds to jump to stop mode, and press Play/Stop button again to return to playing music mode, LCD displays as: Press FF button to select next song. -
Page 13: Repeat A-B Function
VOL+/ VOL- By pressing VOL+/VOL- button, you could control the volume under either Play or Pause mode. The volume steps (see illustration) will increase or decrease when then the VOL+ /VOL- button is pressed correspondingly. Repeat A-B function Under music/voice mode, you can press A-B/EQ button to select A and B, then A-B music or voice will play continuously. -
Page 14: Music Playing Mode
EQ setting Under the playing mode, press A-B/EQ button for a period of time to select 6 different music modes: Normal, DBB, Jazz, Rock, Classical, and Pop. LCD displays as: Music playing mode: Press FUNCTION There are five playing mode: Selected EQ display relative change Press this button long time for EQ set, short time for repeat A-B set... - Page 15 Interpreting the message regarding music file and voice file When in play/stop status, the display will show the number of music or voice file, e.g. 003. After the file number is the current playing time of the music or voice file. The total time for the music and voice file is shown at the beginning when the file starts playing (for 1 second) Erasing a music file Under...
-
Page 16: Voice
Press At the mean time, if you press CD line-in function we be activated. Under CD line-in mode, press file transfer from CD to Mp3 player. The screen will show the same display as above Note: Under CD Line in voice distortion you can adjust the volume properly. -
Page 17: Voice
Stop Recording Press button again to stop recording. Display is shown below Play / Recording The operating procedure is the same as playing normal music files Remarks: A-B repeating function can only function in play/stop status. EQ mode can only be changed by pressing the A-B/EQ function in recording mode. -
Page 18: Fm Tuner
FM tuner function Enter FM tuner mode Press Function button to enter FM tuner mode. (Adjust the direction of earphone line to get better radio effect) VOL+/VOL 107.95 Auto search Press Function button for a while to auto search and memorize radio channels. When the LCD displays the auto search has finished. - Page 19 FM fine tuner Press to fine tune. By pressing current radio frequency. If you want to repeat the auto search function, press stop/play button until appeared on the screen, then press want to fine tune any channels, you only need to press play/stop button once till the the screen.
-
Page 20: Fm Tuner
EQ setup and other related functions Operation of FM files in PC When the USB connection between the mp3 player and PC has completed, you can find that there is a folder called Just like other music files, you can rename, copy or delete the Recorded FM files. -
Page 21: Connection
CONNECTION WITH COMPUTER... - Page 22 Requirements for computer system 1. Operating systems: Microsoft Windows 98 SE, Windows Me, Windows 2000, Windows NT, Windows XP 2. CPU: Intel Pentium 3, Pentium 4 or above CPU 3. Memory: 64 MB or above 4. HD: 200MB idle memory and above 5.
-
Page 23: Installation
nInstallation of Driver After connecting with computer, Windows 2000/ME/XP will automatically identify and install the driver. The machine is ready to use when a needed for Windows 98 to install Driver. The icon will be displayed in My computer after installation Windows 98 SE installation Removable drive icon appears in y computer... -
Page 24: Download
After the machine has connected with a PC, choose the files that you want to copy and drag it to the removable device folder (mp3 player). The saved files will play according to their file names. If you want to change their order of playing, please change their file names... - Page 25 Save and rename music and voice files After successful connection between the machine and computer (switch on), it is displayed as: Double-click removable disk, it is displayed as VOICE LINE IN Music file FM file Note: This machine can recognize and play mp3 and WMA format files. FM file Voice Voice...
-
Page 26: Disconnection
Disconnection with computer Right click Plug and play icon then select Note: Do not unplug the machine with computer with the file is read/written/deleted. Foxda Technology is not liable for any damage/lose of any files. Formatting Right click the removable disk icon then select play music if FAT 32 or mode. - Page 27 Foxda Technology Industrial (Shenzhen) Co. Ltd Sales Office: Add: 6/F, Fuxing Bldg, Binlang Road, Futian Free Duty Zone, Shenzhen, 518038, CHINA. Tel: (852) 2521-6669 Fax: (852) 2521-2229 Factory: Add: E/Flat, New Century Industrial Park, Longgang Large Industrial Zone, Shenzhen, 518118, CHINA Tel: 86-755-84637555 Fax: 86-755-84637700 Hong Kong Office: Add: Unit 1205, Tower 1, Lippo Centre, Admiralty , Hong KongTel: (852)
