Foxda FM-6602 User Manual

Foxda technology user manual mp3 digital player fm-6602
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
Mp3 Digital Player
FM-6602
USB
CERTIFIER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM-6602 and is the answer not in the manual?

Questions and answers

Related Manuals for Foxda FM-6602

Summary of Contents for Foxda FM-6602

  • Page 1 FM-6602 FM-6602 CERTIFIER USER MANUAL Mp3 Digital Player...

  • Page 2: Table Of Contents

    Subject Note...1 Overview Player overview...2 LCD overview...3 Earphone overview...3 Features..4 Technical Spec...5 Operational Notes... 6 OPERATION NOTES Battery/ Turn on or off...8 Three MODE...9 Operation Notes... Advanced function Music...15 Voice... 15-16 FM tuner...17-18 Settings... 19-21 Erase Files... 22 About /Exit... 23 Communication with Computer Connection...25 Installation...

  • Page 3: Note

    MP3 player with removable storage hard disk, fashionable appearance, easy operation, provide recording, music playing and repeating for you. 1/14 OVERVIEW 9/11 Player overview 1 EAR HOLE 2 HANG HOLE BATTERY COVER 4 INTERNAL MIC 5 VOL+ 6 REC/A-B/EQ 7 LCD 8 VOL- 9.

  • Page 4: Lcd Overview

    A - B TRYING MUSIC.MP3 Song 001-01:05/04:47 JAZZ LCD overview 1.Playing state 2.Playing mode display 3.Repeat A-B display 4.EQ 5.Volume 6.Power 7.Function 8.Song No. 9.Current Music playing time 10.Total playing time 11.Song s informations 12.Holding state Earphone overview 1.Ear 2.USB cable...

  • Page 5: Features

    Accessories 1 USB cable 2 EARPHONE 3 Manual 4. CD-ROM 5. Strip hang Features Playback Mp3/ WMA multi-format files. Equalizer mode options: Normal, Class, Jazz, Pop, Rock, DBB. LCD display, blue light background. A-B repeat, Selected content repeat function. 10 hours recording time (128M). 12MB full speed USB internal Flash memory.

  • Page 6: Technical Spec

    TECHNICAL SPECIFICATIONS SIZE ( L x W x H ) WEIGHT POWER DECODE BIT RATE SAMPLE FREQUENCY FREQUENCY RANGE DISTORTION MP3 sound track separation dynamic range REC RDER LENGTH TRANSFER SPEED DELIVERY SPEED POWER OUT 86*31*18.2mm 29 g AAA BATTERY X 1 ISO11172-3(MPEG1.0 Layer 3),ADPCM 64Kdps-320Kdps 8KHz-48KHz...

  • Page 7: Operational Notes

    Operational Notes If the Mp3 player is not operated for a prolonged period, remove the battery to avoid possible damage caused by electrical leakage. The Mp3 player should be kept in areas free from extreme temperature changes, moisture and dust.

  • Page 8: Operation Notes

    OPERATION NOTES...

  • Page 9: Load Battery

    Load battery Open the battery compartment, and load one AAA battery as the direction of marked Change battery When power is not enough, machine display as illustration, that means you must change battery, it is a good suggestion for you that you had better turn off machine before change new battery .

  • Page 10: Music

    OPERATION NOTES music playing, voice playing & recording, radio function Press menu to select music mode, press auto back to playing music mode if no operation more than 3 seconds), LCD display mode as : Press menu button into music mode, press menu button to confirm this mode.

  • Page 11: Music Playing Functions

    Music playing functions The default OSD is stop state under music mode Play / Pause / Stop / FF / FW Under playing music mode, LCD displays music mode Press Play/Stop button LCD displays pause mode when music is pause playing Under pause mode, press Play/Stop Play/Stop button again into playing music mode,LCD display as: LCD displays stop mode when...
  • Page 12 OPERATION NOTES VOL+/VOL- By pressing VOL+/VOL-button ,you could control the volume under either PLAY or PAUSE status. The volume steps (see illustration)will increase or decrease when the VOL+/VOL-button is pressed correspondingly Repeat A-B function Under music/voice mode, you can press A-B/EQ button to select A and B, then play A-B music or voice again and again, press A-B/EQ button to cancel, LCD display as: JAZZ TRYING MUSIC.MP3...
  • Page 13 EQ setting Under the playing mode press A-B/EQ button long time to select 6 modes of different music Normal,DBB,Jazz,Rock,Classical,Pop, you cycle to select ( ref. Page ),and LCD display as: Normal Selected EQ display relative change DOBB Rock Jazz Class Music / voice information display: Under playing/stopping mode,LCD is rolling to display as: TRYING MUSIC.MP3...

  • Page 14: Advanced Function

    Advanced function...

  • Page 15: Fm Tuner

    Advanced function Followed is the more advanced functions of our MP3 player for you,you can press button to select 6 functions Music Voice FM tuner Settings Erase Files About Exit Menu function Press MENU button into this mode, press and press menu button again to confirm your selecting, and into relative display.
  • Page 16 Advanced function Music Function: This mode is default mode when machine is used first time. Function description: playing/stopping/FF/FW/V+,-/EQ setting/repeat A-B ( Ref. Page10 ) Voice Function: Under music mode, press menu button to confirm (Ref. Page 9) .under voice mode, you can select playing/recording /repeating A-B/FW/FF/ V+,-/EQ setting ( Ref.
  • Page 17 Start Recording Under Voice Function, press Microphone), LCD display as: /VOICE/V001.WAV Stop recording Press A-B/EQ button again to stop recording, LCD display as ( Ref. Page 15 ) Play recording It is same operation as music playing ( Ref. Page 10 ),LCD display ( Ref. Page 15) Repeat A-B function only be operated under playing/pausing mode, no response under recording/stopping mode NOTE EQ function only be worked by pressing A-B/EQ/REC button long time under playing/pausing/stopping mode,...
  • Page 18 Advanced function FM tuner function press menu button and press ( Adjust the direction of earphone line to get good radio effect ) VOL+/VOL By pressing VOL+/VOL-button ,you could control the volume. The volume steps will increase or decrease when the VOL+/VOL-button is pressed correspondingly 87.6 Mhz Mono(Stereo) 87.6 Mhz...
  • Page 19 Auto search Press button to auto search radio and memorize, mark. ( Note : press long time would power off ) Selecting the memorized radio circularly Press A-B/EQ and MENU Exit FM tuner Press MENU button long time, machine return to latest setting mode. button to select the memorized radio circularly .

  • Page 20: Settings

    Advanced function Settings press + to select setting mode, it include functions displayed as: PlayMode Contrast PowerSaving Backlignt Language Exit 1. EQ Ref.page12,another set method 6 EQ mode included:,Normal, DBB,Rock,Jazz,Classical, Pop, press button to cycle selecting, and press to confirm. Playmode NOTE: Except in recording mode, you can select setting function both in playing and stopping mode.5 min standby time later, machine...
  • Page 21 2. PlayMode 5 playing mode included: normal, repeat single song, repeat all, Shuffle play, Shuffle button to cycle selecting, and press 3. Contrast User can self-set to get good contrast, LCD display as : Press "+/-"button to display relative change,and press "menu"button to confirm 3.

  • Page 22: Settings

    Advanced function 4. BackLignt 3 backlight mode included: prohibition,3 SEC,10 Secretary, machine backlight can last above setting time when you operate machine, special using in the night, press cycle selecting, and press 5. Language English and Chinese, Traditional Chinese, press menu to confirm, LCD display as : 6.

  • Page 23: Advanced Function Music

    Earas Files Press + to select delete mode,LCD display music/voice file, press button to cycle selecting, and press menu to confirm, LCD display as : Delete Music File name TRYING MUSIC.MP3 Delete the file? When file deleted, LCD display as, and return last mode File deleted Delete Voice /VOICE/V001.WAV...
  • Page 24 Advanced function About 1.Production Model Exit Press + to select button to return voice/music mode,LCD display Note: Under exit mode,5 min standby time can cause machine to return to voice/music mode ( the latest setting mode ) Press + to select about 2.Firmware VER.

  • Page 25: Communication With Computer

    COMMUNICATION WITH COMPUTER...

  • Page 26: Connection

    COMMUNICATION WITH COMPUTER Requirements for computer system Operating systems: Microsoft Windows 98, Windows Me, Windows 2000,Windows NT, Windows XP. 2 CPU Intel Pentium 3,Pentium 4 or above CPU 3 Memory 32 MB and above 4 HD 200MB idle memory and above 5 Intface full speed USB 6 CD-ROM Connection with computer...

  • Page 27: Installation

    Installation of communication software After good connection with computer, computer can auto install to use, and appear the mark removable drive , Windows 98 Operation system need additional CD-ROM. Windows 98 CD-ROM installation Put attached CD-ROM into computer, and install to finish according to computer direction COMMUNICATION WITH COMPUTER The mark will be displayed here after installation The mark will be displayed in "my computer"...

  • Page 28: Download

    COMMUNICATION WITH COMPUTER Save and rename downloaded music and voice files After successful connection between the Ready machine and computer, it is displayed as Double-click removable disk, it is displayed as Open 1.voice box 3.voice file information 2.music file information Note : This machine as USB drive is the same operation as normal USB drive, you can select copy/rename/download/delete functions for your inquiry.

  • Page 29: Disconnection

    Disconnection with computer The play/Stop button is out of work when connecting with PC. Click by touching right key, and when appear Note: you could not open machine when read/written/deleted,data damage or lose caused by any illegal operation Is out of our responsibilityFirst take off the USB port then take off the earphone.

  • Page 30: Check Quickly

    Check quickly General question answer 1. How to turn on machine? 2. What is meaning of LCD s display ? 3. Why return to initial music playing mode? 4. How record and repeat? 5. How download and delete song in computer? Ref page 8 Ref page 3 Ref page 9...

  • Page 31: Menu Overview

    FM Tuner MUSIC VOICE Classical Play Mode Contrast PowerSaving BackLight CHINESE Language Traditional CHINESE ENGLISH Exit MENU Press button to select Settings Erase Files Normal Rock Normal Jazz Repeat Track Repeat All Shuffle Shuffle Repeat Disables 3Sec 10Sec Menu overview About Exit Music...
  • Page 32 F o x d a Te c h n o l o g y I n d u s t r i a l ( s h e n z h e n ) c o . , L t d . Sales office : Add:6/F,Fuxing Bldg, Binlang Road, Futian Free Duty Zone, Shenzhen, 518038, CHINA.
