Foxda FM-6603 User Manual

Digital mp3 player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FM-6603
User Manual
D i g i t a l M p 3 P l a y e r

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM-6603 and is the answer not in the manual?

Questions and answers

Related Manuals for Foxda FM-6603

Summary of Contents for Foxda FM-6603

  • Page 1 FM-6603 FM-6603 User Manual D i g i t a l M p 3 P l a y e r...
  • Page 2 Thank you for purchasing Foxda digital Mp3 Player. Please read through the user manual carefully beforeoperating the machine in order tomaximize the ability and life of our product. Please take good care ofthis manual for future reference. The appearance of our...

  • Page 3: Table Of Contents

    Content Note...1 Overview MP3 Player...3 LCD...4 Earphone...5 Features...6 Technical Spec...7 Operational Notes...8 Operation Notes Battery/Power on or off...9 Operation MODE...10 Operation Notes...11-13 Advanced Function Menu/Function...15 Music...16 Voice... 16-17 FM tuner...18-20 CD Line-in... 20-21 Configuration...21-24 Erase files... 24-25 About/Return...25 Communication with Computer Connection...27...

  • Page 4: Mp3 Player

    OVERVIEW This player is an MP3 player with removable storage hard disk and fashionable appearance. It is user-friendly, easy to operate and provides recoding, music playing and repeating function. Player overview 1.Neck Strap Loop 2.Earphone/USB port/CD Line-in Jack 3.FF 4.PLAY 5.STOP...
  • Page 5 A - B JAZZ MUSIC.MP3 Song 001-01:05/04:47 1.Status indicator 2.Play mode display 3.Repeat A-B display 4.EQ 5.Volume 6.Power 7.Function Status 8.Song No. 9.Current Music playing time 10. Total music playing time 11.Song message 12.Hold status Earphone overview 1.Ear piece 2.USB cable 3.CD Line-in...

  • Page 6: Earphone

    Accessories 1.USB cable 2.Earphone 3.Manual Features Small in size, all-round functions One jack for USB, earphone and CD Line-in connection (patent) Online FM recording CD Line-in Animation Menu Playback MP3/ WMA multi-format files Equalizer mode options: Normal, Classic, Jazz, Pop, Rock, DBB. LCD display, blue light background.
  • Page 7 Data reference Size Weight Power Source Frequency Range Frequency Encode Bit Rate Distortion MP3 (Sound Track Separation) MP3 (Dynamic Range) Recorder Length Transfer Speed Delivery Speed Power Out 74 x 31 x 15 mm 25 g 1.5V "AAA" Alkaline Batt. (+-1db) 20Hz - 20KHz 8 KHz - 48 KHz ISO 11 172-3 (MPEG 1.0 Layer 3)

  • Page 8: Operational Notes

    Operational Notes “ If the MP3 player will not be operated for a prolonged period, remove the battery to avoid possible damage caused by electrical leakage. “ The MP3 player should be kept in areas free from extreme temperature changes, moisture and dust.
  • Page 9 Operating Instructions...

  • Page 10: Power Off

    Load battery Open the battery compartment and load one AAA7 battery as directed by + and - . Change battery When the LCD displays Low Battery , it indicates a need of battery change. Turn off the machine before replacing a new battery. Turning the power on/off The OSD with blue backlight appears when PLAY/STOP button is pressed.

  • Page 11: Functional Options

    Functional Options Music playing, voice playing & recording, radio function Press Menu to select music mode. Then press switch back to music mode if no operation for more than 10 seconds). You can play Mp3 and WMA format files in this mode.

  • Page 12: Music Playing Functions

    Music playing functions The default OSD is in stop status under music mode Play/Pause/Stop/FF/RW Press Play/Stop Press Play/Stop button Under play or pause mode, press down Play/Stop to jump to stop mode, and press Play/Stop button again to return to playing music mode, LCD displays as: Note: Only in stop mode, hold play/stop button to switch off the machine.

  • Page 13: Repeat A-B Function

    VOL+/ VOL- By pressing VOL+/VOL- button, you could control the volume under either Play or Pause mode. The volume steps (see illustration) will increase or decrease when then the VOL+/VOL- button is pressed correspondingly . Repeat A-B function Under music/voice mode, you can press A-B/EQ button to select A and B, then A-B music or voice will play continuously.
  • Page 14 EQ setting Under the playing mode, press A-B/EQ button for a period of time to select 6 different music modes: Normal Jazz Rock Classical Music/Voice information display: When in play/stop status, the display will scroll to show the information of music or voice file, e.g. song title, distributor, copyright, etc.

  • Page 15: Advanced Function

    Advanced function...
  • Page 16 Advanced function Followed are the more advanced functions of our MP3 player for you. You can press select 6 modes MENU Press Menu button to enter this mode. Press button again to confirm your selecting. Note: No operation in 5 seconds, machine returns to latest setting mode.
  • Page 17 Music mode ( Ref. P. 10) This is the default mode. Users can play MP3/WMA files under this mode. Users can also run repeat (Ref. P. 22) /A-B/RW/FF/V+,-/EQ setting in this mode. Voice mode Under music mode, press Menu confirm . Under voice mode, you can select play/record/repeat/A-B/RW/FF/V+,-/EQ setting. 1.

  • Page 18: Start Recording

    Start Recording Under Voice Function, press microphone's position can be seen in P.2). The display is as follows: Stop Recording Press A-B/EQ button again to stop recording. Play Recording The operating procedure is the same as operating music files (Ref. page 11). (Display reference in Page 13) Note: "A-B"...

  • Page 19: Fm Tuner

    FM Tuner FM tuner mode Press Menu button and press +,- to select FM tuner, and then press Menu to confirm. (Adjust the direction of earphone line to get better radio effect) VOL+/VOL Auto search Press 'menu' button to auto search and memorize up to 32 radio channels. FM fine tuner Press to fine tune.
  • Page 20 Operation of FM files in PC When the USB connection between the mp3 player and PC has completed, you can find that there is a folder called 'FM' in the player. Inside you can find the recorded FM files. Just like other music files, you can rename, copy or delete the Recorded FM files.

  • Page 21: Cd Line-In

    Line-in recording function 1.Connection Use the CD line-in cable to connect the player with CD player (or other audio equipment) as shown below: 2.Recording Press Menu and then press tart recording. As the mean time, press the play button on the CD player and start the recording as shown below: 3.Playing recorded files Press Menu...
  • Page 22 Settings Enter this mode according to the instructions in Page 15. Play Mode Contrast PowerSaving BackLight Language Exit EQ Setting (Ref. page 13 for another setting method) Press +,- button to cycle selecting, and press Menu to confirm. Note: Except in record mode, you can select setting function both in play and stop mode.

  • Page 23: Play Mode

    Play Mode playing mode includes: 3.Contrast User can customize the contrast setting for better visual effect. 4.Power Saving In order to save power, the machine can be set to auto power-off if it has idled for a certain period of time under voice and music mode.
  • Page 24 5.Backlight User can disable or change the backlight lasting time in this setting. 6.Language 7.Exit A - B JAZZ Press button to select and press Menu button to confirm. A - B JAZZ Press +, - button to cycle selecting, and press Menu to confirm.

  • Page 25: Erase Files

    Erase files (Ref. P . 15) Erase music files File name Press or no, and then press to confirm. TRYING MUSIC.MP3 Delete the file? When the files has been erased, you File deleted can see the display shown above Erase voice files File name and path /VOICE/V001.WAV Delete the file?
  • Page 26 About Please refer to P . 15 on how to enter this mode Note: As some components would take up spaces in the flash memory, it is normal to find out that the available memory size is lesser than normal. Exit Please refer to P .

  • Page 27: Connection

    CONNECTION WITH COMPUTER...
  • Page 28 Requirements for computer system 1. Operating systems: Microsoft Windows 98 SE, Windows Me, Windows 2000, Windows NT, Windows XP 2. CPU: Intel Pentium 3, Pentium 4 or above CPU 3. Memory: 64 MB or above 4. HD: 200MB idle memory and above 5.

  • Page 29: Installation Of Driver

    Installation of Driver After connecting with computer, Windows 2000/ME/XP will automatically identify and install the driver. The machine is ready to use when a is needed for Windows 98SE to install Driver. Windows 98SE CD-ROM installation removable drive icon appears in The icon will be displayed in my computer .
  • Page 30 Save and rename music and voice files After successful connection between the machine and computer, it is displayed as Double-click removable disk, it is displayed as VOICE LINE IN Music file Note: This machine can recognize and play .Mp3, .WMA and .WA V format files FM file Voice Voice...
  • Page 31 Users may copy files to relevant folder. You may also rename it for your own convenience Write Disconnection with computer Please follow the instruction below for disconnection between Mp3 player and computer. Right click plug and play Note: Do not unplug the machine with computer when the file is reading, writing or deleting. Foxda Technology is not liable for any damage/lose of any files.

  • Page 32: Formatting

    Formatting Right click the removable disk icon then select mode to format. The machine may not be able to play music if FAT 32 NTFS mode selected. To recover, please format the machine again as mode. Press"Begin"button...
  • Page 33 General question&answer Problems Unable to switch on the machine No audio output from the earphone LCD cannot display Poor FM receiving Cannot upload/download Mp3 /WMA/WAV files Cannot record or receive FM Possible causes No battery Incorrect battery position Loosen plug Volume is Check the battery status Check the plug for whether it...
  • Page 34 MUSIC FM Tuner VOICE Play Mode Contrast PowerSaving BackLight Language Exit MENU Press button to select Line in Settings Normal Rock Normal Jazz Repeat Track Classical Repeat All Shuffle Shuffle Repeat Disables 3Sec 10Sec CHINESE Traditional CHINESE ENGLISH Erase Files About Exit Music...
  • Page 35 Hong Kong - Global Sales and Marketing Head Office Unit 1205, Tower 1 Lippo Centre, Admiralty, Hong Kong Tel: (852) 2521-6669 Fax: (852) 2521-2229 Canada office Office Address: #3200-8888 Odlin Crescent Richmond, B.C., Canada V6X 3Z8 Mailing Address: PO Box 88082, RPO Lansdowne Centre, 5300 No.
