2 0 0 5
D O D G E
SPECIFICATIONS
All dimensions are in inches (millimeters) unless otherwise noted.
GENERAL INFORMATION
Body Style __________________________________________________Full-size van, passenger and cargo, cab/chassis
Assembly Plant _________________________________ Dusseldorf, Germany; Gaffney, South Carolina (Cargo Van only)
ENGINE: 2.7-LITER, I-5 TURBODIESEL
Type and Description _____________________________________________ Inline five-cyl. turbodiesel with intercooler
Displacement _________________________________________________________________ 164 cu. in. (2687 cu. cm)
Bore x Stroke __________________________________________________________________3.46 x 3.48 (87.9 x 88.4)
Valve System ________________________________________________________________________ DOHC, 20 valves,
Fuel Injection ______________________________________Common rail injection with valve-covered injection nozzles
Construction _________________________________________________________________ Cast-iron block and heads
Compression Ratio ______________________________________________________________________________ 18:1
Power (SAE net) ________________________________________________ 154 bhp (115 kW) @ 3800 rpm (57.3 bhp/L)
Torque (SAE net) ___________________________________________________243 lb.-ft. (330 N•m) @ 1600-2400 rpm
Max. Engine Speed __________________________________________________________________________ 4150 rpm
Fuel Requirement __________________________________ Diesel fuel (No. 2 or No. 1: ASTM D275 No. 2-D or No. 1-D)
Oil Capacity _______________________________________________________________________________ 9.5 qt. (9L)
Coolant Capacity ________________________________________________________________________ 2.7 qt. (2.6L)
Emission Controls ______________________________________________________ Oxygen sensor, catalytic converter
Max. Gross Trailer Weight ____________________________________________________________________5,000 lbs.
Estimated Fuel Economy ________________________________________________________________22 mpg average
ELECTRICAL SYSTEM
Alternator ___________________________________________________________ 90-amp; optional 115- and 150-amp
Auxiliary Battery _____________________________________________________Available option with disconnect relay
Battery _______________________________________________________________________________12 volt/110-ah
Radio ____________________________________ AM/FM radio with cassette (two speakers), optional single CD player
AUTOMATIC TRANSMISSION
Description ___________________________________________________Electronically controlled five-speed overdrive
Gear Ratios
1st _______________________________________________________________________________________ 3.595
2nd ______________________________________________________________________________________ 2.186
3rd _______________________________________________________________________________________ 1.405
4th ___________________________________________________________________________________________1
5th _______________________________________________________________________________________ 0.831
Axle Ratio ________________________________________________________________ Standard—3.72, Optional—4.11
Final Drive ________________________________________________________ 3.09 with 3.72 axle, 3.42 with 4.11 axle
8
D O D G E
S P R I N T E R
B R A N D
P R O D U C T
V A N
I N F O R M A T I O N
continued
