Hitachi CP-X880 Features & Specifications

CP-X880 & CP-X885
Technical Specifications
OPTICAL CP-X880 CP-X885
Optical Structure 3 LCD Panels, One Projection Lens, RGB 3 LCD Panels, One Projection Lens, RGB
Shutter Method Shutter Method
LCD Panel 0.99", P-Si TFT Panel x 3 0.99", P-Si TFT Panel x 3 with Micro Lens
Resolution 1024 x 768 1024 x 768
Lens f=1.7~2.4 (f=31~46mm) f=1.7~2.4 (f=31~46mm)
Lamp 275W UHB 275W UHB
Lamp Life Over 2000 Hours Over 2000 Hours
Brightness 3000 ANSI lumens 3500 ANSI lumens
Contrast Ratio 500:1 800:1
Focus Distance 0.9~13.9m 0.9~13.9m
Display Size 30-300inches 30-300inches
Colour 8Bit/Colour, 16.7 Million Colours 8Bit/Colour, 16.7 Million Colours
COMPATIBILITY
Composite Video NTSC, NTSC4.43, PAL(-BGDHI), NTSC, NTSC4.43, PAL(-BGDHI),
PAL60, SECAM, PAL M,N PAL60, SECAM, PAL M,N
Component Video HDTV: 750p (720p), 1125i, HDTV: 750p (720p),1125i,
(1080i/1035i), (1080i/1035i),
SDTV: 525i (480i), 525p (480p), SDTV: 525i (480i), 525p (480p),
625i (575i) 625i (575i)
Computer VGA,SVGA, XGA, SXGA, UXGA, VGA,SVGA, XGA, SXGA, UXGA
MAC13", MAC16", MAC19" MAC13", MAC16", MAC19"
Plug & Play DDC1/2B DDC1/2B
Frequency Range Horizontal: 15~80kHz, Horizontal: 15~80kHz,
Vertical: 50~120Hz Vertical: 50~120Hz
FEATURES
Keystone Correction Keystone Automatic on Vertical only Keystone Automatic on Vertical only
Start Up Screen My Screen with Lock System My Screen with Lock System
Image Control H & V Keystone H & V Keystone
User Controls Picture in Picture, 11 Language Menus, Picture in Picture, 11 Language Menus,
Freeze Function, Magnifying, Freeze Function, Magnifying,
Digital Gamma Correction Digital Gamma Correction
Speakers 1W x 2 1W x 2
CONNECTORS
Computer Input 15pin D-sub, 5 x BNC, 1 x DVI 15pin D-sub, 5 x BNC, 1 x DVI
Video Input S-Video: Jack Terminal x 1, S-Video: Jack Terminal x 1,
Composite Video: RCA Jack terminal x 1, Composite Video: RCA Jack Terminal x 1
Component Video: RCA Jack Terminal x 3, Component Video: RCA Jack Terminal x 3,
Component Share RGB1 : BNC Terminal x 3 Component Share RGB1 : BNC Terminal x 3
RGB Output 15-pin Mini-Dsub Terminal x 1 (Selected OUT) 15-pin Mini-Dsub Terminal x 1 (Selected OUT)
Audio Output Stereo-mini Jack Terminal x 1 (Selected OUT) Stereo-mini Jack Terminal x 1 (Selected OUT)
Control 1 x RS-232 - 15-pin D-sub, 1 x USB 2 x RS-232 - 15-pin D-sub, 1 x USB
POWER
Power Supply AC100-120V/AC220~240V AC100-120V/AC220~240V
Power Consumption 430W 430W
PHYSICAL
Dimensions (WxHxD) 380 x 120 x 290mm 380 x 120 x 290mm
(excluding lens & legs) (excluding lens & legs)
Weight 5.7kg 5.7kg
Noise Level 35dB Whisper Mode 35dB Whisper Mode
Approvals UL60950/C-UL, FCC Part 15, UL60950/C-UL, FCC Part 15,
Class B, CE, TUV EN60950 Class B, CE, TUV EN60950
SUPPLIED WITH
Remote Control, Power Cord, RGB Cable, Remote Control, Power Cord, RGB Cable,
Video Cable, USB Cable, Video Cable, USB Cable,
8-language Operators Manual 8-language Operators Manual
OPTIONS
Long Throw Lens Long Throw Lens
Wireless RGB Wireless RGB
Wired Remote Control Wired Remote Control
Fabric Wheel Case (FLC800) Fabric Wheel Case (FLC800)
Image size Projector Distance
Diagonal Width (m) Min
30" (0.76m) 0.61 0.9m (34")
40" (1.02m) 0.81 1.2m (46")
50" (1.27m) 1.02 1.5m (58")
60" (1.52m) 1.22 1.8m (71")
70" (1.78m) 1.42 2.1m (83")
80" (2.03m) 1.62 2.4m (95")
90" (2.29m) 1.83 2.7m (108")
100" (2.54m) 2.03 3.0m (120")
120" (3.05m) 2.44 3.7m (144")
150" (3.81m) 3.04 4.6m (181")
200" (5.08m) 4.06 6.2m (243")
250" (6.35m) 5.08 7.7m (304")
300" (7.62m) 6.10 9.3m (366")
14
Width
Distance Min (m)
12
Distance Max (m)
10
8
6
4
2
0
1 2 3
Screen width - metres
Max
1.3m (52")
1.8m (71")
2.3m (89")
2.7m (107")
3.2m (126")
HITACHI DIGITAL MEDIA
3.7m (144")
Hitachi Europe Ltd
4.1m (162")
Dukes Meadow
4.6m (181")
5.5m (217")
Millboard Road
6.9m (272")
Bourne End
9.2m (364")
Buckinghamshire SL8 5XF
11.6m (455")
13.9m (547")
Tel: 01628 643 000
www.hitachidigitalmedia.com
The specification above and photography is for
reference only and may be subject to change.
CP-X885
CP-X880
4 5 6 7
CP-X885 CP-X880
3500 ANSI Lumens 3000 ANSI Lumens
