LCD Projector CP-X880/CP-X885 USER'S MANUAL USER'S MANUAL Vol.1 (Basic) Thank you for purchasing this projector. WARNING • Please read the accompanying manual “SAFETY INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct usage through understanding. After reading, store this instruction manual in a safe place for future reference.
Page 2: Projector Features
This liquid crystal projector is used to project PROJECTOR various computer signals as well as NTSC / PAL / FEATURES SECAM video signals onto a screen. Little space is required for installation and large images can easily be realized. Ultra High Brightness One Touch Function Crisp, ultra-bright presentations is achieved Just press the ONE TOUCH button to...
Page 3 WARNING Precautions to observe in regards to the power cord: Please use extra caution when connecting the projector's power cord as incorrect or faulty connections may result in FIRE AND/OR ELECTRICAL SHOCK. Please adhere to the following safety guidelines to insure safe operation of the projector: •...
Page 4: Part Names
THE PROJECTOR PART NAMES Indicates the corresponding reference page KEYSTONE button INPUT dial ONE TOUCH button RGB indicator RESET button BNC indicator FOCUS button INPUT DVI indicator KEYSTONE ZOOM button ONE TOUCH VIDEO indicator FOCUS ZOOM VIDEO RESET MENU button S-VIDEO indicator S-VIDEO MENU...
Page 5 THE REMOTE CONTROL LASER INDICATOR RGB button VIDEO button ZOOM buttons LASER INDICATOR VIDEO STANDBY/ON STANDBY/ON button PAGE buttons FOCUS buttons FOCUS ZOOM PAGE DOWN LASER button BLANK button BLANK LASER Right mouse button Disk pad <For mouse control> <For mouse control> Right mouse click Mouse cursor movement ASPECT...
Page 6: Setting Up The Projector
SETTING UP THE PROJECTOR CAUTION • Install the projector in a suitable environment according to instructions of the accompanying manual “SAFETY INSTRUCTIONS” and this manual. • If you press the elevator buttons without holding the projector, the projector might crash down, overturn, smash your fingers and possibly result in malfunction. To prevent damaging the projector and injuring yourself, ALWAYS HOLD THE PROJECTOR whenever using the elevator buttons to adjust the elevator feet.
Page 7 Adjusting the Screen Size and Projection Distance Refer to the illustrations and tables below to determine the screen size and projection distance. The values shown in the table are calculated for a full size screen a:Distance from the projector to the screen (±10%) b:Distance from the lens center to the bottom of the screen (±10%) c:Distance from the lens center to the top of the screen (±10%) The screen...
Page 8: Connecting Your Devices
CONNECTING YOUR DEVICES Devices You Can Connect to the Projector (Refer to this section for planning your device configuration to use for your presentation.) CAUTION • Incorrect connecting could result in fire or electrical shock. Please read this manual and the separate “SAFETY INSTRUCTIONS”. ATTENTION Precautions to observe when connecting other devices to the projector •...
Page 9 Ports and Cables Refer to the table below to find out which projector port and cable to use for connecting a given device. Use this table for determining which cables to prepare. Function Projector Port Connection Cables RGB cable (With D-sub 15-pin shrink jack and inch thread screws) Analog RGB input BNC(R/C...
Page 10 CONNECTING YOUR DEVICES (continued) Connecting to a Computer ATTENTION Whenever attempting to connect a laptop computer to the projector, be sure to activate the laptop's RGB external image output (set the laptop to CRT display or to simultaneous LCD and CRT display). For details on how this is done, please refer to the instruction manual of the corresponding laptop computer.
Page 11 Connecting to a Computer (continued) BNC Input DVI Input REMOTE REMOTE CONTROL CONTROL COMPONENT VIIDEO Ca/Pa Ca/Pa COMPONENT VIIDEO RGB OUT CONTROL RGB OUT CONTROL R-AUDIO IN-L VIDEO IN S-VIDEO IN R-AUDIO IN-L VIDEO IN S-VIDEO IN B/Ca/Pa B/Ca/Pa A A A A A AUDIO IN AUDIO OUT AUDIO IN...
Page 12 CONNECTING YOUR DEVICES (continued) Connecting to a VCR Connecting to a DVD Player REMOTE REMOTE CONTROL CONTROL Ca/Pa COMPONENT VIIDEO COMPONENT VIIDEO Ca/Pa A A A B B B A A A RGB OUT CONTROL RGB OUT CONTROL R-AUDIO IN-L VIDEO IN S-VIDEO IN R-AUDIO IN-L...
Page 13: Using The Remote Control
USING THE REMOTE CONTROL Putting batteries into the remote control unit CAUTION Precautions to observe in regards to the batteries Always handle the batteries with care and use them only as directed. Improper use may result in battery cracking or leakage, which could result in fire, injury and/or pollution of the surrounding environment. •...
Page 14 USING THE REMOTE CONTROL (continued) Operating the remote control WARNING • The laser pointer of the remote control transmitter is used in place of a finger or rod. Never look directly into the laser beam outlet or point the laser beam at other people. The laser beam can cause vision problems. CAUTION •...
Page 15: Turning On The Power
TURNING ON THE POWER Precautions 〜 Connect all devices to be used to the projector prior to turning on the power. WARNING When the power is ON, a strong light is emitted. Do not look into the lens. Make sure that the power cord is firmly and LASER INDICATOR correctly connected to the projector and outlet...
Page 16 TURNING ON THE POWER (continued) Selecting an Input Signal Using the remote control Using the projector's control panel If selecting RGB input Turn the INPUT dial Press the RGB button Turning the dial cycles INPUT Press this button to toggle between the devices through the inputs as connected to RGB IN 1 and 2.
Page 17: Turning Off The Power
TURNING OFF THE POWER Press the STANDBY/ON button (control LASER panel or remote control) INDICATOR STANDBY/ON VIDEO The message "Power off?" will appear on the screen for STANDBY/ON approximately 5 seconds. FOCUS ZOOM PAGE DOWN BLANK LASER Press the STANDBY/ON button again (control panel or remote control) Press the STANDBY/ON button again while the "Power off?"...
Page 18: Adjusting The Volume
ADJUSTING THE VOLUME Press the VOLUME button VOLUME LASER As illustrated on the right, a dialog will INDICATOR VIDEO STANDBY/ON appear on the screen to aid you in adjusting the volume. VOLUME FOCUS ZOOM PAGE DOWN BLANK LASER Use the lever switch to adjust the volume ASPECT...
Page 19: Adjusting The Position
ADJUSTING THE POSITION Press the POSITION button LASER INDICATOR As illustrated on the right, a dialog will appear on the screen to VIDEO STANDBY/ON aid you in adjusting the position. FOCUS ZOOM PAGE DOWN BLANK LASER POSITION POSITION ASPECT Use the buttons to adjust the PUSH ENTER...
Page 20: Using The Automatic Adjustment Feature
USING THE AUTOMATIC ADJUSTMENT FEATURE Press the AUTO button BLANK LASER AUTO Automatic Adjustment for RGB Input ASPECT Horizontal position (H. POSIT), vertical position (V. POSIT), clock phase (H. PHASE) and horizontal size (H. PUSH ENTER SIZE) are automatically adjusted. MENU RESET Make sure that the application window is set to its...
Page 21: Correcting Keystone Distortions
CORRECTING KEYSTONE DISTORTIONS Press the KEYSTONE button KEYSTONE As illustrated on the right, a dialog will appear on the screen to aid you in correcting the distortion. ASPECT KEYSTONE PUSH ENTER MENU RESET POSITION AUTO PinP MAGNIFY VOLUME Use the buttons to select the FREEZE MUTE...
Page 22: Using The Magnify Feature
USING THE MAGNIFY FEATURE Press the MAGNIFY (ON) button MAGNIFY DOWN The projector enters MAGNIFY mode. BLANK LASER Press the POSITION button, then use the lever switch to select the area to zoom. Press the ASPECT POSITION button again to finalize the zoom area. PUSH ENTER POSITION...
Page 23: Adjusting Screen With One-Touch
ADJUSTING SCREEN WITH ONE-TOUCH Press the ONE TOUCH button FOCUS ZOOM PAGE ONE TOUCH DOWN You can activate the following functions just by pressing the ONE TOUCH button: BLANK LASER (1) Signal search: Cycle through input signals, displaying the images of retrieved signals. If no signal is found, returns to the signal that was selected before the search ASPECT was begun.
Page 24: Selecting The Aspect Ratio
SELECTING THE ASPECT RATIO Press the ASPECT button DOWN RGB, DVI, COMPONENT VIDEO BLANK LASER (HDTV signals : 1125i (1035i/1080i), 750p) ASPECT 16:9 VIDEO IN, S-VIDEO IN, COMPONENT VIDEO (Non-HDTV signals : 525i, 525p,625i) 16:9 SMALL ASPECT PUSH ENTER MENU RESET POSITION AUTO...
Page 25: Using The Menu Functions
USING THE MENU FUNCTIONS Press the MENU button MENU LASER The menu display appears on the screen. The projector INDICATOR STANDBY/ON VIDEO has the following menus: MAIN, PICTURE-1, PICTURE-2, INPUT, AUTO, SCREEN, and OPTION, WIRELESS. When you select a menu name using the lever switch / , the FOCUS ZOOM...
Page 26: Operating The Pc Screen
OPERATING THE PC SCREEN You can use the remote control as a simplified mouse or keyboard. CAUTION Caution: Mistaken use of the mouse/keyboard control could damage your equipment. • Only connect to a PC. • Before connecting, read the manuals of the device you will connect. •...
Page 27: The Lamp
THE LAMP HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE To replace the lamp, check the model number of the replacement lamp (sold separately) and contact your local dealer. Replacement lamp model number: DT00531 If the projector is mounted on the ceiling, or if the lamp has broken, ask your dealer to replace the lamp.
Page 28 THE LAMP (continued) Replacing the lamp All projector lamps will wear out eventually. If used for long periods of time, the image could become darkened, and the color contrast could be impacted as well. We recommend that you replace your lamps early.
Page 29: The Air Filter
THE AIR FILTER Caring for the air filter The air filter should be cleaned about every 100 hours. If the LAMP indicator and TEMP indicator blink red simultaneously, or a message prompts you to clean the air filter when you turn on the unit, the filter needs to be cleaned. (See "Related Messages"...
Page 30 THE AIR FILTER (continued) Replacing the air filter If the soiling will not come off the air filter, or it becomes damaged, then it needs to be replaced. Please contact your local dealer, after confirming the model of your separately sold replacement air filter. Replacement air filter model: NJ07081 Turn off the projector, and unplug the power cord.
Page 31: Other Care
OTHER CARE Caring for the inside of the projector : In order to ensure the safe use of your projector, please have it cleaned and inspected by your local dealer about once every 2 years. Never try to care for the inside of the unit yourself.
Page 32 Hitachi, Ltd. Tokyo, Japan International Sales Division THE HITACHI ATAGO BUILDING, No. 15 –12 Nishi Shinbashi, 2 – Chome, Minato – Ku, Tokyo 105-8430, Japan. Tel: 03 35022111 HITACHI EUROPE LTD. HITACHI EUROPE S.A. Dukes Meadow 364, Kifissias Ave. & 1, Delfon Str.
