Technical Data Sheet
Elements 403FP
BENEFITS
• Uniquely designed to be used as a fl at panel fl oor
stand, or separate video table and mount
• Includes interchangeable inserts for four color
options (High gloss black, Cherry, Brushed stainless steel, Walnut)
• Ideal for corners or fl at against a wall
• Pans 30° left and right to adjust viewing
angle (when used as fl at panel fl oor stand)
• Low 1.5" mounting profi le (when used as separate wall mount)
• Includes universal adapter for greater panel compatibility
• Lift n Lock™ allows you to easily attach
your fl at panel to the mount
• Open area shelves accommodate multiple components
• Neatly route and organize wires through cable management post
• Locking system secures panel to mount
• Plastic feet protect fl oors
• Easy to assemble
SPECIFICATIONS
• Accommodates most 32"- 47"fl at panels up to 110 lbs (50 kg)
• 8 mm tempered glass top shelf supports up to 110 lbs (50 kg)
• Two 6 mm tempered glass component shelves supports
up to 50 lbs (22.7 kg)
• Universal and VESA compliant: 75x75 to 400x600
• Dimensions: 40"w x 52.8"h x 20"d (1016mm x 1341mm x 508mm)
• Warranty: 5 years
• Color: Black with black glass
Color
Americas
BLK
International
BLK
Box Contents
Vertical rail
Mount plate
Swivel head
Column cap
Cable management column
Column base
Top shelf support
Middle shelf bracket
The Core Collection is OmniMount's tried and true furniture collection made up of two diff erent series of
steel and glass A/V furniture. With clean lines, black glass and various high-gloss fi nishes, these pieces blend
seamlessly into any environment. The Elements Series has an all-in-one design and exclusive interchangeable
color inserts that reinvents A/V furniture with an adaptable approach to displaying fl at panels and components.
Ideal for A/V enthusiasts looking for extreme décor fl exibility, the Elements 403FP can display medium to
large fl at panels in three diff erent confi gurations and comes with four interchangeable color panel options.
03252010
Stock Code
Packaging UPC
1004679-1
728901024641
NA
NA
Dimensions WxDxH inches (mm)
Product Box
25.4 x 45 x 6.7 (645x1142x170)
Qty
Box Contents
2
Base shelf support
1
Front frame horizontal rail
1
Front frame horizontal inserts
1
Glass shelves
3
Complete furniture assembly hardware kit
1
Complete panel mounting hardware kit
2
Complete panel attachment hardware kit
2
Instruction manual
Wt lbs (kg)
89.9 (40.8)
Qty
2
2
8
3
1
1
1
1
800.MOUNT.IT (800.668.6848)
