Luxor Riviera-42 Installation And Owner's Manual

Direct vent gas fireplaces

Advertisement

Direct Vent Gas Fireplaces
Installation and Owner's Manual
WARNING: If the information in these
.
instructions is not followed exactly, a fire or
.
explosion may result causing property damage,
personal injury or death.
--Do not store or use gasoline or other
Flammable vapors and liquids in the
vicinity of this or any other appliance.
--WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance
• Do not touch any electrical switch; do
Not use any phone in your building;
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
The fire department.
-- Installation and service must be performed
By a qualified installer, service agency or
the gas supplier
Model Riviera-42
Canadian Fire Hearth Mfg
7075 Beatty Dr. Mission, B.C. Canada V2V-6C4
©
INSTALLER: Leave this manual with the customer
CUSTOMER: Retain this manual for
PLEASE NOTE: This product has been manufactured using
steel and screws. As a result, there are many sharp edges
that can easily cut exposed skin. It is highly recommended
that you wear proper protective gloves while installing the
unit, and during routine cleaning or maintenance.
Revision 12.0409
future reference
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Riviera-42 and is the answer not in the manual?

Questions and answers

Summary of Contents for Luxor Riviera-42

  • Page 1 © Direct Vent Gas Fireplaces Model Riviera-42 Canadian Fire Hearth Mfg 7075 Beatty Dr. Mission, B.C. Canada V2V-6C4 Installation and Owner’s Manual INSTALLER: Leave this manual with the customer WARNING: If the information in these future reference instructions is not followed exactly, a fire or...
  • Page 2: Table Of Contents

    Table of Contents Page 1……………………………………………………………………..Cover Page with Safety Information Page 2………………………………………………………………………….Table of Contents Page 3 & 4…………………………………………………………………..Customer Greeting & Safety Information Page 5 ………………………………………………………………………..Features and Specifications Page 6………………………………………………………………………..Framing Specifications Page 7………………………………………………………………………… Placement and Mantel Requirements Page. 8…………………………………………… …………………………..Corner Installation / Supply Lines Specs. Page 9………………………………………………………………………….Venting Components Page 10………………………………………………………………………...
  • Page 3 CONGRATULATIONS Welcome to Our Luxor Gas Fireplace Family We hope you’ve had an easy and enjoyable time choosing from our line of products, and we certainly appreciate your business. Please take some time to read through the following information, and make sure to heed all of the warnings.
  • Page 4 Do not operate the fireplace if damaged, or if the glass is cracked. Any repairs must be done by a certified technician. Certification The Model Riviera-42 is listed and certified for installation in the U.S.A. and Canada under the following standards: ANSI Z21.50/CSA 2.22.
  • Page 5: Features And Specifications

    Black Please Note: Only products supplied by the manufacturer may be used in the installation of this appliance. The Luxor Riviera 42 is a direct vent gas appliance utilizing an inclined vent for superior installation flexibility. It enables either horizontal...
  • Page 6: Minimum Framing Dimensions

    Installation Minimum Framing Dimensions Rear Venting Exit Minimum. Center vertical framing with appliance Clearance to side walls is 0 inches Metal support for Non- combustible facing • Gas Inlet Location 6” from front by 3.5” 42.5 above floor. •Electrical connection is centered 10”...
  • Page 7: Mantel Requirements

    Raised Fireplace Placement Elevated Height Options As the Riviera 42 contemporary design leads itself to installations higher in the wall as would other traditional appliances. All installations clearance still applies. Non- combustible panels and distances to combustible materials must be adhered to. The Clearance to the ceiling must not be less than the 43”...
  • Page 8: Corner Installation

    Corner Installation A 45º angle installation 68.00 Typical venting configuration for 50.49 corner installation 15.25 Installing Gas and Electrical Supply Lines. Both Gas and Electrical lines must be installed and accessible for the installation of the Riviera 42. Natural Gas requires a minimum inlet gas pressure of 5.0 in W.C.. Liquid Propane Fuel requires a minimum of 11.0 in.
  • Page 9: Installation Considerations

    Venting Venting Parameters. The Riviera 42 can be installed using either Canadian Firehearth Rigid 5 x 8 co-axial venting or 2-ply Aluminum Chimney liner that is supplied by Canadian Firehearth. A description of the details and limitation for venting are listed in this manual. Installer please note; there are variations with venting configurations specific to either Natural gas or Propane Fuels.
  • Page 10: Vent Installation

    Vent Installation Canadian Fire Hearth Rigid Vent System • All Rigid vent sections and elbows utilize slip type joints. • Each joint should be secured by three screws. • High temperature sealant is recommended at the connection start of the venting on the appliance end.
  • Page 11: Vertical Venting

    Vertical Venting Installations Special Note for all Rigid Pipe Vent installations ° ° Depending on the configuration starting at the rear of the fireplace either a 60 or 30 elbow will be required allow proper alignment of subsequent piping: ° required for horizontal direction first °...
  • Page 12: Horizontal Venting

    Horizontal Venting Installations Special Note for all Rigid Pipe Vent installations ° ° Depending on the configuration starting at the rear of the fireplace either a 60 or 30 elbow will be required allow proper alignment of subsequent piping: ° required for horizontal direction first °...
  • Page 13 Minimum Vent Termination Clearances Letter CDN Installation US Installation Description 12” 30cm Clearance above grade, verandah, porch, deck, or balcony. 30cm 9” Clearance from window or door that may be opened. 15”* 38cm* Clearance from permanently closed window (to prevent condensation) 22”...
  • Page 14: Installation Planning

    Installation Planning The recommended order of installation is as follows: 1 – Familiarize yourself with this manual. 2 – Check the minimum installation dimensions and vent installation. 3 – Check your local installation codes. 4 – Check you have the parts and components necessary to complete the installation. 5 –...
  • Page 15 Placing and Securing Non-Combustible Panels The Riviera 42 is shipped with five (5) separate panels of non-combustible panels which must be installed with the appliance to conform with to certified safety standards. Two of the panels are secured to the Cleanface from at the factory and require no special attention and are mentioned only to avoid confusion.
  • Page 16 Attaching the Cleanface Mounting Frame before Installation. As noted previously, Gas and Electrical lines should be hooked to the appliance before attaching Cleanface Surround and fitting Non-combustible front. The Cleanface Front Assembly is fastened to the front of the Firebox unit by the self-tapping sheet metal screws.
  • Page 17 The brace should be fastened by either or screws to secure it in place. The Non-combustible board can be fastened with standard drywall screws through the recessed holes provided when the appliance is ready to close in Figure 5 Figure 6 Install metal brace at 36”...
  • Page 18 Door Removal and Re-Installation Instructions WARNING: Do not abuse the appliance’s glass by striking, slamming or similar trauma. Do not use the appliance with the door removed, glass panel cracked or broken. Only use OEM door assembly designed for use with this appliance. Do not use substitute materials. Replacement of the panel should only be carried out by a licensed qualified service person 1) Remove the Control Valve Compartment cover grille which provides access to the door latch mechanism...
  • Page 19: Electrical

    Electrical Diagram This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three prong receptacle. Do not cut or remove the grounding prong from this plug This appliance, when installed, must be electrically grounded in accordance with L1(BK)
  • Page 20: Lighting Instructions

    Lighting Instructions For your safety, read the following before lighting: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage and personal injury or death A. This appliance is equipped with an ignition device which Use only your hand to push in or turn control knob.
  • Page 21: Final Checks

    Final Checks Installer: Before leaving the appliance with the customer, you Clean the glass regularly as soon as you notice must check the operation of the appliance. the buildup, (white film). If the film is left for a *Check correct rating by clocking the appliance at 15 minutes. longer period of time, build up will bake on.
  • Page 22 Thermostat Installation(not allowed in US installations) Thermostat or wall switch installation The burner control switch is located in the centre of the control department opening. For your convenience, the unit can also be operated by a thermostat or a wall switch control. Electronic are available from any authorized CFHMfg dealer.
  • Page 23 Flame Quality Adjustment Adjustment Procedure Air / Fuel mixture is adjusted at the burner tube. Access to this feature is done through the top of the burner cover by removing the two fasteners from the rectangular metal cover. Once the screws have been remove lift off the metal cover plate.
  • Page 24: Replacement Parts

    Replacement Parts List BURNER COMPONENTS Burner Tube CDC006PT Glass Door (Robax panel in frame) RGD42RIV Pilot Assy. (NG) DC006NG Riviera 42 Valve Tray Riv 42 Gas Tray Valve tray Gasket GK01 Gas Valve American Flame Electronic 4000 (NG) GC1001 CFH Electronic Pilot Assembly DC006E LP Pilot Orifice (Danna Controls) LPPO...
  • Page 25 Burner Component Servicing For maintenance, proper re-assembly and resealing of the venting system is required. The appliance should be inspected before use and at least annually by a professional service person. More frequent cleaning may be required due to excessive lint from carpet bedding material etc. It is imperative that control compartment, covers of the appliance to be kept clean.
  • Page 26: Warranty

    After the first year, with respect to the Luxor Limited Lifetime Warranty, CFHMfg may, at its discretion, fully discharge all obligations with respect to this warranty by refunding to the original warranted purchaser the wholesale price of any warranted but defective part(s).
