Direct Vent Gas Fireplaces
#103-7075 Beatty Dr. Mission, B.C. Canada V2V-6C4
Installation and Owner's Manual
WARNING: If the information in these
.
instructions is not followed exactly, a fire or
.
explosion may result causing property damage,
personal injury or death.
--Do not store or use gasoline or other
Flammable vapors and liquids in the
vicinity of this or any other appliance.
--WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance
• Do not touch any electrical switch; do
Not use any phone in your building;
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
The fire department.
-- Installation and service must be performed
By a qualified installer, service agency or
the gas supplier
Model Riviera-66
Luxor Manufacturing Mfg.
INSTALLER: Leave this manual with the customer
CUSTOMER: Retain this manual for
PLEASE NOTE: This product has been manufactured using
steel and screws. As a result, there are many sharp edges
that can easily cut exposed skin. It is highly recommended
that you wear proper protective gloves while installing the
unit, and during routine cleaning or maintenance.
©
future reference
1
Advertisement
Table of Contents
Related Manuals for Luxor Riviera-66
Summary of Contents for Luxor Riviera-66
- Page 1 © Direct Vent Gas Fireplaces Model Riviera-66 Luxor Manufacturing Mfg. #103-7075 Beatty Dr. Mission, B.C. Canada V2V-6C4 Installation and Owner’s Manual INSTALLER: Leave this manual with the customer WARNING: If the information in these future reference CUSTOMER: Retain this manual for...
-
Page 2: Table Of Contents
Table of Contents Page 1……………………………………………………………………..Cover Page with Safety Information Page 2………………………………………………………………………….Table of Contents Page 3 & 4…………………………………………………………………..Customer Greeting & Safety Information Page 5 ………………………………………………………………………..Features and Specifications Page 6………………………………………………………………………..Framing Specifications Page 7………………………………………………………………………… Placement and Mantel Requirements Page. 8…………………………………………… …………………………..Corner Installation / Supply Lines Specs. Page 9………………………………………………………………………….Venting Components Page 10………………………………………………………………………... - Page 3 CONGRATULATIONS Welcome to Our Luxor Gas Fireplace Family We hope you’ve had an easy and enjoyable time choosing from our line of products, and we certainly appreciate your business. Please take some time to read through the following information, and make sure to heed all of the warnings.
- Page 4 Do not operate the fireplace if damaged, or if the glass is cracked. Any repairs must be done by a certified technician. Certification The Model Riviera-66 is listed and certified for installation in the U.S.A. and Canada under the following standards: ANSI Z21.88 (2009)/CSA 2.23.(2009) The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas and Propane Installation Code, ANSI Z223.1 / NFPA 54 in the US or the Natural Gas and Propane...
-
Page 5: Features And Specifications
2000ft (610M) and above: 46,000 BTU/hr (13.48kW) less 4% per 1000 ft. (305M) Please Note: Only products supplied by the manufacturer may be used in the installation of this appliance. The Luxor Riviera 66 is a direct vent gas appliance utilizing an inclined vent for superior installation flexibility. -
Page 6: Minimum Framing Dimensions
DRA W ING IS TH E SO LE PRO PERTY O F CA NA DIA N FIRE H EA RTH . A NY Combustible panel (supplied by Luxor) must be installed on the top of the opening. FINISH REPRO DU CTIO N IN PA RT O R A S A W H O LE... -
Page 7: Mantel Requirements
Placement of Appliance Non-Combustible Panels The factory supplies two non-combustible panels that must be secured in place before the appliance can be installed. The 66 1/4” X 17 ¼” panel is placed on the base centered directly beneath the unit as shown (A). -
Page 8: Corner Installation
Corner Installation A 45º angle installation Typical layout for a corner installation Installing Gas and Electrical Supply Lines. Both Gas and Electrical lines must be installed and accessible for the installation of the Riviera 66. Natural Gas requires a minimum inlet gas pressure of 5.0 in W.C.. Liquid Propane Fuel requires a minimum of 11.0 in. -
Page 9: Installation Considerations
Venting Venting Parameters. The Riviera 66 must be installed using Simpson Duravent Rigid 5 x 8 co-axial venting or that can be supplied by Canadian Firehearth. A description of the details and limitation for venting are listed in this manual. Installer please note; there are variations with venting configurations specific to either Natural gas or Propane Fuels. -
Page 10: Vent Installation
Vent Installation Simpson “DuraVent” Rigid Vent System • All vent sections and elbows utilize twist lock type joints. • Each joint should be secured by three screws. • High temperature sealant is recommended at the connection start of the venting on the appliance end. Use high-temperature silicone or Mill- Pac©. -
Page 11: Vertical Venting
Vertical Venting Installations Special Note for all Rigid Pipe Vent installations ° Configuration starting at the rear of the fireplace either a 30 elbow will be required allow proper alignment of subsequent piping: • Up to four elbows (45º or 90º) may be used •... -
Page 12: Horizontal Venting
Horizontal Venting Installations Special Note for all Rigid Pipe Vent installations ° Regardless on the configuration starting at the rear of the fireplace a 30 elbow will be required allow proper alignment of subsequent piping: • When elbows are required up to four elbows (45ºor 90º) may be used. - Page 13 Minimum Vent Termination Clearances Letter CDN Installation US Installation Description 12” 30cm Clearance above grade, verandah, porch, deck, or balcony. 30cm 9” Clearance from window or door that may be opened. 15”* 38cm* Clearance from permanently closed window (to prevent condensation) 22”...
-
Page 14: Installation Planning
Installation Planning The recommended order of installation is as follows: 1 – Familiarize yourself with this manual. 2 – Check the minimum installation dimensions and vent installation. 3 – Check your local installation codes. 4 – Check you have the parts and components necessary to complete the installation. 5 –... - Page 15 Cleanface from at the factory and require no special attention and are mentioned only to avoid confusion. The large 75” x 35.5” mounts to the cleanface front surface panel. The 66.25”x17.25” panel is for installation beneath the appliance. In addition a single 14 ½ x 3 ½ must be installed at the top of the wall opening when venting is routed horizontally through a side wall.
- Page 16 Attaching the Cleanface Mounting Frame before Installation. As noted previously, Gas and Electrical lines should be hooked to the appliance before attaching Cleanface Surround and fitting Non-combustible front. The Cleanface Front Assembly is fastened to the front of the Firebox unit by the self-tapping sheet metal screws.
- Page 17 The brace should be fastened by either or screws to secure it in place. The Non-combustible board can be fastened with standard drywall screws through the recessed holes provided when the appliance is ready to close in Figure 5 Figure 6 Install metal brace at 36”...
- Page 18 When Door assembly is aligned pull latch mechanism forward and up to secure door. Replace the Valve Compartment Grille NOTE: In the event of glass fracture or other related damage the Glass door must be replaced as a complete assembly. The Robax Glazing/Frame Assembly must be provided by Luxor Mfg.ONLY. Part #RGD66RIV.
-
Page 19: Electrical
Electrical Diagram This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three prong receptacle. Do not cut or remove the grounding prong from this plug This appliance, when installed, must be electrically grounded in accordance with L1(BK) -
Page 20: Lighting Instructions
Lighting Instructions For your safety, read the following before lighting: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage and personal injury or death A. This appliance is equipped with an ignition device which Use only your hand to push in or turn control knob. -
Page 21: Final Checks
Final Checks Installer: Before leaving the appliance with the customer, you Clean the glass regularly as soon as you notice must check the operation of the appliance. the buildup, (white film). If the film is left for a *Check correct rating by clocking the appliance at 15 minutes. longer period of time, build up will bake on. - Page 22 Thermostat Installation (not allowed in US installations) Thermostat or wall switch installation The burner control switch is located in the centre of the control department opening. For your convenience, the unit can also be operated by a thermostat or a wall switch control. Electronic are available from any authorized CFHMfg dealer.
- Page 23 Flame Quality Adjustment Adjustment Procedure Air / Fuel mixture is adjusted at the burner tube. Access to this feature is done through the top of the burner cover by removing the two fasteners from the rectangular metal cover. Once the screws have been remove lift off the metal cover plate.
-
Page 24: Replacement Parts
Replacement Parts List BURNER COMPONENTS Burner Tube CDC006PT Glass Door (Robax panel in frame) RGD42RIV Pilot Assy. (NG) DC006NG Riviera 42 Valve Tray Riv 42 Gas Tray Valve tray Gasket GK01 Gas Valve American Flame Electronic 4000 (NG) GC1001 CFH Electronic Pilot Assembly DC006E LP Pilot Orifice (Danna Controls) LPPO... - Page 25 Burner Component Servicing For maintenance, proper re-assembly and resealing of the venting system is required. The appliance should be inspected before use and at least annually by a professional service person. More frequent cleaning may be required due to excessive lint from carpet bedding material etc. It is imperative that control compartment, covers of the appliance to be kept clean.
-
Page 26: Warranty
After the first year, with respect to the Luxor Limited Lifetime Warranty, CFHMfg may, at its discretion, fully discharge all obligations with respect to this warranty by refunding to the original warranted purchaser the wholesale price of any warranted but defective part(s).
