Tripp Lite SMART1500CRMXL Brochure & Specs

Model #: SMART1500CRMXL
SmartPro Compact Rackmount UPS System - Precision Protection for Network / Telecom Wiring Closets and
Reduced Depth Installations
Description
Tripp Lite's SmartPro Compact Rackmount Uninterruptible Power Supply (UPS) offers line interactive voltage regulation, network grade surge
suppression and long lasting battery support for critical network hardware during blackouts and extended power failures. Larger internal batteries
and higher rated wattage makes these systems ideal for network and telecom wiring closets and other limited-space installations. Runtime is
expandable with optional BP48V48RT4U and BP48V24-2U reduced-depth external battery packs.
SMART1500CRMXL 2U rackmount 1500VA/1440 watt UPS offers battery-derived sine wave AC output during power failures and extreme voltage
variations. Line interactive Automatic Voltage Regulation (AVR) provides two levels of voltage boost during brownouts and one level of voltage cut
during overvoltage conditions to maintain regulated 120V nominal output over an input range of 83-145V. Includes NEMA 5-15P input plug and
NEMA 5-15R output receptacles. Network management interfaces support simultaneous communications via USB port, DB9 serial port and optional
SNMP/Web management accessory card slot. Optional SNMPWEBCARD offers remote management and control of the UPS via direct network
connection. Additional ENVIROSENSE accessory, when used in conjunction with SNMPWEBCARD reports temperature, humidity and status of up
to two directly connected contact closure sensors. HID-compliant USB interface enables full integration with built-in power management and auto
shutdown features of Windows and Mac OS X. Supports detailed monitoring of equipment load levels, self-test data and utility power conditions via
all 3 network interfaces at once. Includes PowerAlert monitoring software with USB and serial cables. Emergency Power Off (EPO) interface.
Integrated 3-bank programmable PDU switching supports load shedding and remote-reboot of up to 3 individual connected devices. 3-stage
metered current monitoring and battery charge status LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rackmount
accessories included; 2-9USTAND tower stands and 2POSTRMKITWM 2 post rackmount kit available. Field-replaceable, hot-swappable internal
batteries and external battery packs. Attractive all-black color scheme. 2-year warranty and $250,000
warranty and service contracts available.
Applications
Higher rated wattage make these systems ideal for network and telecom wiring closets and other limited-space installations
Package Includes
SmartPro compact rackmount UPS System
4-post rackmount installation hardware
Highlights
1500VA / 1.5kVA line interactive 2U rack / tower UPS with high power factor
1440W capacity
Maintains sine-wave 120V nominal output over an input range of 87 to 145V
Network communications supported via USB port, serial port, SNMP/Web card
slot and EPO interface
Expandable runtime with optional external battery packs
Input: NEMA 5-15P (120V 15A) / Output: 8 NEMA 5-15R (120V)
2 year product warranty / $250,000
Rico & Canada only)
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: saleshelp@tripplite.com
Ultimate Lifetime Insurance
connected equipment insurance; extended
Tripp Lite
(USA, Puerto
