Tannoy VXP 6 Features & Specifications

VXP 6

Product Description

Conceived, engineered and built with precision in the United Kingdom, VXP Series
represents the latest evolution of Tannoy's core philosophies in self-powered loudspeaker
system design. The Tannoy VXP 6 features the brand new IDEEA™ (IntelliDrive Energy
Efficient Amplifier) integrated power module from Lab.gruppen. The result is a highly
compact, ultra-reliable and exceptionally efficient self-powered loudspeaker. VXP 6 offers
a punchy and sonically superior solution for small-scale sound reinforcement as well as
for critical-quality speech reproduction where clarity and natural vocal characteristics are
paramount. The VXP 6 been sonically matched with the wider range of VXP Series models,
this allows consistency in installations where a mix of products is utilised.
The VXP 6 is built around a single 150 mm (6") Dual Concentric™ driver mounted in
an ultra-compact, rugged birch plywood cabinet with aesthetically profiled edges and
an Airnet -backed, powder-coated steel grille. The latest version of Tannoy's exclusive
TM
point source, constant directivity Dual Concentric drive unit ensures high sensitivity
and exceptional efficiency. More than 60 years of research into Dual Concentric
technology allows this unique configuration to deliver exceptionally smooth beam-width
characteristics resulting in an even coverage pattern at all frequencies aiding predictable
system design. Symmetrical dispersion characteristics enhance loudspeaker placement
flexibility, allowing vertical or horizontal mounting of single or multi-cabinet arrays
without compromising sound quality.
The perfectly matched Lab.gruppen IDEEA) integrated power module efficiently and
effectively handles the demands of both fixed installation and portable audio. IDEEA
modules are designed for superlative audio performance, robust power output and
long-term durability – even with extended duty cycles up to round-the-clock operation.
Extensive features to safeguard internal circuits and connected drivers ensure a long and
trouble-free service life. At the heart of the IDEEA module is a patented Class D output
stage capable of high power levels with very low distortion and minimal current draw – all
with a net operating efficiency in excess of 80%. A universal switching power supply
accepts any mains voltage from 70 – 265 V (+/- 10%) at 50 Hz or 60 Hz through the
appropriate IEC cord. In Auto mode, the speaker turns on with signal present and
switches to standby mode after 20 minutes of no input, with standby power consumption
of less than 1 W. Manual control mode allows the speaker to be turned on and off as
required. A switchable 90 Hz high-pass filter tailors response for use with a subwoofer.
Rear panel connections are provided for audio input (XLR-F), audio link (XLR-M) and AC
power (Neutrik powerCON
® ®
standard, with matching grilles, and is also available in custom matched RAL colours as
an option.
Tannoy (Direct UK) T: +44 (0) 1236 420199
TCGI (ROW sales) T: +45 8742 7000
TCGA (Americas sales) T: +1 (519) 745 1158
Tannoy Middle East T: +971 (04) 4401208
). VXP 6 is available in black or white textured paint finish as
E: enquiries@tannoy.com
E: info@tcgroup-international.com
E: info@tcgroup-americas.com
E: enquiries@tannoy.com
Features
• 150 mm (6") Dual Concentric full-range driver
• Well defined 90 degree dispersion for
optimum coverage and forward gain
• Peak output of 118 dB
• Integrated Lab.gruppen IDEEA module
providing ultra-reliable Class D amplification
• Versatile mounting via optional custom –
designed hardware
• Pole-mountable for small-scale portable PA
applications
• Exceptional sound and performance for a cabinet
of this size
• Rugged and highly compact birch plywood
enclosure
• Available in black or white textured paint finish;
custom colours optional
• XLR input and link, powerCON mains (included)
Applications
• Theatres, Auditoria and Houses of Worship
• Small scale PA and compact voice reinforcement
• Bars and infill for nightclubs
• Portable and installed corporate AV
• Theme parks and leisure venues
• Gymnasiums and small/medium sports arenas
VXP 6 // issue 1.00 // 20.02.12
