Controls Clock / Minute Minder Operation Grill Pan and Handle Using the Grill Guide to Grilling Using the Oven for Fan Cooking Using the Oven for Other Functions Temperature Conversion Chart Oven Temperature Charts Cooking Results Not Satisfactory? Care and Cleaning...
It is suggested that any pets be removed from the room until the smell has ceased. This odour is due to temporary finish on oven liners and elements and also any moisture absorbed by the insulation.
Always make sure all controls are turned off when you have finished cooking and when not in use. Always stand back when opening an oven door to allow any build up of steam or heat to disperse. Always use dry, good quality oven gloves when removing items from the oven/grill.
Page 5
Never allow anyone to sit or stand on any part of the appliance. Never store items above the appliance that children may attempt to reach. Never remove the oven shelves whilst the oven is hot. Never heat up unopened food containers as pressure can build up causing the container to burst.
Features OVEN CONTROL & SELECTOR GRILL CONTROL CLOCK / MINUTE MINDER STAY CLEAN LINER GRILL ELEMENT GRILL PAN GRILL DOOR OVEN LIGHT STAY CLEAN OVEN SHELF LINER OVEN FAN RATING PLATE DOOR SWITCH INNER DOOR OVEN DOOR GLASS...
The main oven has a light only position. Slow Cooking ‘S’ The main oven has a “Slow Cook Setting” , ‘S’ , this can be used for slow cooking, keeping food warm and warming plates for a short period. Element and Fan...
THE TIME OF DAY IS NOW SET. To change the time of day repeat Steps 4 & 5 above. Make sure all oven controls are turned off. Check the electricity supply to the cooker is turned on. When switched on, the display will show 0.00 Press and release both buttons simultaneously.
Clock/Minute Minder Operation Here you can set a time period of up to 10 hours, that will count down. When it reaches zero, the timer will emit an audible tone. For Example: If you set 20 minutes, the audible tone will occur 20 minutes later.
If a detachable handle is required, do not replace screw & washers. Note: If a fixed handle is required, the grill pan is unable to be kept in the main oven with the door closed but may be stored in the top oven with the door closed.
Place the shelf in the correct position (see Grilling Guide). Place the food/grill pan on the shelf, positioned centrally under the grill element. Leave the top oven door full open. Step 2 Turn knob (A) clockwise to select TWIN GRILL or anti-clockwise to select SINGLE GRILL Grill Setting (1–4).
Food or utensils should never be placed directly on the floor of the oven for cooking. DO NOT allow young children near to the appliance when the main oven is in use as the surfaces get extremely hot. OVEN UTENSILS...
(allowing 5-6 hours per lb.) or at room temperature (allowing 2-3 hours per lb.). Frozen meat or poultry must be completely defrosted before cooking in the oven. However, to decrease the amount of time required to defrost food items, a non- heating fan only setting may be selected for the main oven only.
Extra care should be taken when warming bone china, as it may be damaged in a hot oven. DO NOT place food or plates directly on the oven floor as this could damage both the oven lining and the plates which are being warmed.
Beef Rare 60 Mediun 70 Main Fan Oven Cooking Note: Up to two shelves may be used in this oven. The position of these is not important providing they are evenly spaced. Pre- Temperature heat ˚C...
Page 18
Main Fan Oven Cooking Note: Up to two shelves may be used in this oven. The position of these is not important providing they are evenly spaced.
Remember when using a food mixer or processor not to over-cream soft margarine. Refer to the cooking times and temperatures given in the Oven Temperature Charts provided, however, it may be necessary to increase or decrease temperatures by 10˚C to suit personal taste.
OVEN BASE (a) How "Stay clean" works. The surfaces of the "Stay clean" oven liners are treated with a special vitreous enamel which absorbs cooking soils. At temperatures of 220˚C (425˚F) or above, the special surface enables these soils to be slowly destroyed.
Open the oven door and remove the oven shelves. Using a thick cloth, grip the lamp lens, unscrew anti- clockwise and remove the lens.
Page 22
INNER PANEL Fig. 4 1. Position top or main oven door as shown in fig. 1. Note: The door can be wedged open using a towel between the door and the side trim thus leaving your hands free. 2. Grip inner door panel and handle/outer glass assembly.
Installation Electrical Requirements For your own safety, we recommend that your cooker is installed by a competent person such as one who is registered with NICEIC (National Inspection Council for Electrical Installation Contracting). The cooker should be installed in accordance with the latest edition of the IEE Regulations.
Page 24
Check that the plinth can be fitted. If necessary re - adjust the feet and check that the cooker is level. h. Open the top oven door and fix the cooker to the brackets through the holes in the side trims.
Page 25
Installation 597mm min 720mm min 565mm 150mm Min 170mm Max A minimum distance of 25mm should be maintained between the front face of the cabinet side and the front face of the plinth.
Page 26
Installation Wall Fixing Bracket Cooker 1mm min Cabinet Doors Top View Double pole control switch Hob Cable 2.5mm Cable size to suit heat resistant current cable to rating of BS 6141 Table 15 appliance/s Connector Cable...
(a) Check If you find :- Display is blank. Then it is likely that there is no electricity supply to your oven. Check: That the main cooker wall switch is turned on. (ii) Check other appliances to see if you have a power cut.
Monday to Sunday, 8am to 8pm www.hotpointservice.co.uk Republic of Ireland: 1850 502 200 Genuine Parts and Accessories UK: 08709 077 077 Monday to Friday, 8.30am to 5pm Saturday, 8.30am to 12noon www.hotpointservice.co.uk Republic of Ireland: (01) 842 6836 www.hotpoint.co.uk 01/2005 Part No. 195046000.00...
