Volkswagen CC 2014 Technical Specifications

2014 CC
Technical Specifications
CC 2.0T
ENGINE
2.0L inline four cylinder, 16V,
Type
turbocharged/intercooled, FSI
Bore 3.2 in
Stroke 3.65 in
Displacement 121 cu in
Compression Ratio 9.6:1
Horsepower (SAE) @ rpm 200 hp @ 5100
Maximum torque, lb-ft @ rpm 207 lb-ft @ 1700
Fuel Requirement Premium fuel recommended
ENGINE DESIGN
Arrangement Front mounted, transverse
Cylinder block Cast iron
Crankshaft Forged steel, five main bearings
Cylinder head Aluminum alloy, crossflow
Valvetrain Double overhead camshaft, chain driven with
automatic tensioner, four valves per cylinder,
maintenance-free hydraulic lifters, variable
intake timing
DRIVETRAIN
Driven wheels Front-wheel drive
Transmission Gear Ratios:1 1st
2nd
3rd
4th
5th
6th
Reverse 4.55
Final I
Final II
CAPACITIES
Fuel Tank 18.5 gal
STEERING
Type Rack and pinion: electric power assist
Turns (lock to lock) 3.01
Turning Circle (curb to curb) 37.4 ft
Ratio 16.4:1
INTERIOR VOLUME - SAE
EPA Class Compact
Seating Capacity Five
Passenger Volume 93.6 cu ft
Cargo Volume 13.2 cu ft
Front
Volume 50.4 cu ft
Headroom (in/mm) 37.4/949
Shoulder room (in/mm) 56.0/1422
Legroom (in/mm) 41.6/1057
BODY, CHASSIS AND SUSPENSION
Type Unitary construction
Body Material Steel stampings
Strut-type with lower control arms, coil
Front Suspension
springs, telecopic dampers, anti-roll bar
Rear Suspension Multilink with coil springs, telescopic
dampers, anti-roll bar
Brakes Power assisted, dual circuit, 12.3 x 1.0-in
vented front and 11.1 x 0.5 in solid rear discs
Anti-Lock Braking System Standard, all four wheels, three-channel with
electronic brake force distribution
Stability Control Standard Electronic Stability Control (ESC)
Parking Brake Electro-mechanical
Wheels/Tires
17-in x 8J aluminum-alloy wheels
235/45 R17 all-season tires
18-in x 8J aluminum-alloy wheels
235/40 R18 all-season tires
Drag Coefficient 0.30
82.5 mm
92.8 mm
1984 cc
(149 kW @ 5100)
(280 Nm @ 1700)
Manual DSG
3.77 3.46
2.09 2.05
1.32 1.30
0.98 0.90
0.98 0.91
0.81 0.76
3.99
3.68 4.06
2.92 3.14
70 L
11.4 m
Rear
43.2 cu ft
36.6/930
54.7/1389
37.3/947
CC V6 4MOTION
3.6L VR6 (10.6 deg V), 24V, FSI
3.5 in 89.0 mm
3.8 in 96.4 mm
219 cu in 3597 cc
11.4:1
280 hp @ 6200 (206 kW @ 6200)
265 lb-ft @ 2750 (360 Nm @ 2750)
Premium fuel recommended
Front mounted, transverse
Cast iron
Cast iron, seven main bearings
Aluminum alloy, crossflow
Double overhead camshaft, chain driven with
automatic tensioner, four valves per cylinder,
maintenance-free hydraulic lifters, variable intake
and exhaust timing
4 permanent all-wheel drive with
MOTION®
Haldex center differential
6-speed Automatic with Tiptronic®
1st 3.95
2nd 2.30
3rd 1.55
4th 1.16
5th 0.86
6th 0.69
Reverse 3.42
Final
3.45
18.5 gal 70 L
Rack and pinion: electric power assist
3.01
37.4 ft 11.4 m
16.4:1
Compact
Five
93.6 cu ft
13.2 cu ft
Front Rear
50.4 cu ft 43.2 cu ft
37.4/949 36.6/930
56.0/1422 54.7/1389
41.6/1057 37.3/947
Unitary construction
Steel stampings
Strut-type with lower control arms, coil springs,
telecopic dampers, anti-roll bar
Multilink with coil springs, telescopic dampers, anti-
roll bar
Power assisted, dual circuit, 13.4 x 1.2-in vented
front and 12.2 x 0.9-in vented rear discs
Standard, all four wheels, three-channel with
electronic brake force distribution
Standard Electronic Stability Control (ESC)
Electro-mechanical
18-in x 8J aluminum-alloy wheels
235/40 R18, all-season tires
0.30
