QuickSpecs
Overview
HP StoreAll 8000 Storage is the latest generation of hyperscale, harnessed, instant, economic storage to tame and mine your
expanding archives. HP StoreAll increases your return on information, infrastructure, and individuals by enabling you to effectively
store, retain, protect, manage, access, AND extract value from continuously growing unstructured data.
StoreAll scales massively without complexity to 16 petabytes of billions of files and objects with data access via a broad range of file
protocols and native OpenStack Object Storage API. It brings structure to unstructured data with data retention policies, WORM, data
integrity validation, and auditing to enable adherence to governance policies. Embedded support for custom metadata tagging is also
provided so that meaning can be added to data. File system analytics and search can be performed up to 100,000X faster with StoreAll
Express Query for metadata-driven storage administration and to enhance applications integrated with it via a REST API. Costs of
storing data can be scaled down over time with policy-based tiering and a modular architecture.
StoreAll has been specifically certified with key ISV applications for enterprise sync/share repositories, content depots, general
archives, governance archives, and backup repositories. Please refer to the Single Point of Connectivity Knowledge (SPOCK) website at:
http://www.hp.com/storage/spock
What's New
HP StoreAll 8800 Storage - a converged hyperscale, economic, ultra-dense appliance that can be flexibly configured for a broad
range of archive workloads, and that can be seamlessly clustered with other StoreAll models.
HP StoreAll 8200 Gateway Storage - providing file archive and object storage services in combination with 3PAR StoreServ 7000
and 10000 Storage, and that can be seamlessly clustered with other StoreAll models.
HP StoreAll OS v6.5 that improves storage administration and data governance, and is optimized for today's and tomorrow's
demands with expanded standards-based file protocol and object storage support.

Features and Benefits

Hyperscale: Massive
scalability without
complexity
Harnessed: Structure for
unstructured data
Instant: Up to 100,000X
faster analytics and
search
for details.
Seamlessly scale out with HP StoreAll Storage to 16 petabytes of billions of files and objects.
Deploy traditional and new generation cloud archive applications with data access via a broad range of
included file protocols and native OpenStack Object Storage API.
Manage HP StoreAll Storage and your data from a single, central, web-based Management Console.
Enable data governance policy adherence with retention services and WORM file immutability.
Conduct forensics for timely administrator action with pervasive auditing of file system events.
Add meaning to your data with embedded custom metadata tagging using StoreAll Express Query.
Proactively manage long term data durability with integrated data integrity validation.
Make metadata informed storage administration decisions orders of magnitude more quickly using
StoreAll Express Query-powered reporting.
Enhance applications by integrating with the StoreAll Express Query REST API, and avoid the cost and
complexity of an external metadata database.
DA - 14792 Worldwide — Version 2 — May 9, 2014
HP StoreAll 8000 Storage
Page 1

Advertisement

   Related Manuals for HP StoreAll 8000

   Summary of Contents for HP StoreAll 8000

  • Page 1: Features And Benefits

    HP StoreAll 8000 Storage Overview HP StoreAll 8000 Storage is the latest generation of hyperscale, harnessed, instant, economic storage to tame and mine your expanding archives. HP StoreAll increases your return on information, infrastructure, and individuals by enabling you to effectively store, retain, protect, manage, access, AND extract value from continuously growing unstructured data.
  • Page 2 HP StoreAll 8000 Storage Overview Economic: Scale down HP StoreAll Storage optimizes your costs throughout the data lifecycle with policy-based tiering. costs of storing data over Modularly add capacity and performance as your archive expands with the pay-as-you-grow architecture. time Leverage the rich set of all inclusive software features for data retention, protection, optimization, and management.
  • Page 3 QuickSpecs HP StoreAll 8000 Storage Standard Features – HP StoreAll 8800 Storage HP StoreAll 8800 Couplet configured HP StoreAll 8800 Couplet configured with HP StoreAll 8800 Couplet configured with ENT SAS Capacity Blocks ENT SAS and MDL SAS Capacity Blocks...
  • Page 4 QuickSpecs HP StoreAll 8000 Storage Standard Features – HP StoreAll 8800 Storage MDL SAS Capacity Block Form Factor: 5U rack mount Interconnect: Disk Drives: 36 or 70 2 TB, 3 TB, or 4TB 7.2K LFF MDL SAS HDDs depending on model...
  • Page 5 HP StoreAll 8800 Storage. HP StoreAll 8800 Storage is based on two primary components: Nodes and Capacity Blocks. A pair of Nodes is connected with one or more Capacity Blocks to form a Couplet.
  • Page 6 Step 3: Select Capacity Block (minimum 1, maximum 2) Capacity Blocks provide the storage for user data. HP StoreAll 8800 Storage can be configured with Enterprise SAS Capacity Blocks and Midline SAS Capacity Blocks. Enterprise SAS provides higher performance and duty cycles than Midline SAS.
  • Page 7 AJ764A Rack The default rack for HP StoreAll 8800 Storage in HP configuration tools is an HP 642 Intelligent Series Rack. A KVM Console and KVM Switch will be automatically added when factory rack integration is selected. HP StoreAll 8800 Storage is also supported in existing racks containing HP StoreAll 9320 Storage and in the HP StoreAll 9730 Storage Base Rack (QZ728A).
  • Page 8 Connection of the Integrated Lights-Out port to the Network Switch Select one HP X120 1G SFP RJ45 Transceiver per Node for the corresponding Switch ports, two total per pair of Nodes. Select the same number of Ethernet Cable 7 ft CAT5 RJ45 M/M.
  • Page 9 Trunk between Switches within the Rack (required when two Switches are selected to avoid a single point of failure) Select two HP X130 10G SFP+ LC SR Transceivers and one HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable per Node to use for the trunk to ensure it is not a bottleneck.
  • Page 10 QuickSpecs HP StoreAll 8000 Storage Options - HP StoreAll 8800 Storage Select two of the appropriate type of DACs or transceivers to connect the Rack (or spanned Racks) to the facility network to allow access for management and maintenance. Refer to the QuickSpecs at: http://h18004.www1.hp.com/products/quickspecs/14260_div/14260_div.pdf...
  • Page 11 11562 16546 4600 2362 3673 Weight (lbs) 60.0 242.3 Weight (kgs) 27.3 Form Factor (rack units) Specifications for HP StoreAll 8800 Storage Couplet with ENT Minimum Maximum Each Node Each SAS Capacity Block(s) Couplet Couplet Capacity Block and Expansion Current (Amps @ 100 VAC) 42.2...
  • Page 12 One 4-port 1GbE included; reserved for a discrete management network if a discrete management network is desired Storage Controller: One Smart Array P420i for mirrored internal OS disk drives; one 2-port HP 82Q 8Gb 2-port PCIe Fibre Channel Host Bus Adapter for array attach Disk Drives:...
  • Page 13 HP StoreAll 8200 Gateway Storage. HP StoreAll 8200 Gateway Storage is only supported in pairs of Nodes attached to HP 3PAR StoreServ 7000 and 10000 Storage via Fibre Channel. Each pair of HP StoreAll 8200 Gateway Storage Nodes and storage capacity from the 3PAR StoreServ to which it is attached forms a Couplet.
  • Page 14 Connection of the Integrated Lights-Out port to the Network Switch Select one HP X120 1G SFP RJ45 Transceiver per Node for the corresponding Switch ports, two total per pair of Nodes. Select the same number of HP RJ45 to RJ45 Cat5e Black M/M 7.6m 1-pack Data Cables.
  • Page 15 Trunk between Switches within the Rack (required when two Switches are selected to avoid a single point of failure) Select two HP X130 10G SFP+ LC SR Transceivers and one HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable per Node to use for the trunk to ensure it is not a bottleneck.
  • Page 16 QuickSpecs HP StoreAll 8000 Storage Options - HP StoreAll 8200 Gateway Storage Specifications for pair of HP StoreAll 8200 Gateway Storage Nodes Current (Amps @ 100 VAC) 40.0 Current (Amps @ 200 VAC) 19.6 Max Power (Watts @ 100 VAC)
  • Page 17 Warranty HP StoreAll 8000 Storage comes with a standard 3/3/3 warranty (3 years parts exchange, 3 years labor, 3 years onsite, and next business day response). Software media is warranted to be free of physical defects for a period of 90 days from delivery.
  • Page 18 Intel is a US registered trademark of Intel Corporation. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
