OWNER’S GUIDE - Range Hood
PLHV42P8CC
F
PLHV42P8CC - P/N 316137229 (Pub. No. 5995392114)
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLHV42P8CC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Electrolux PLHV42P8CC

Summary of Contents for Electrolux PLHV42P8CC

  • Page 1 OWNER’S GUIDE - Range Hood PLHV42P8CC PLHV42P8CC - P/N 316137229 (Pub. No. 5995392114)

  • Page 2: Product Registration

    Contents Contents Thank you for choosing this appliance. Product Registration Register your Product PRODUCT REGISTRATION CARD Record Your Model and Serial Numbers Model Number: ________________________________________________ Serial Number: ________________________________________________ Date of Purchase: ______________________________________________ may not Note:...

  • Page 3: Important Safety Instructions

    Important Safety Instructions READ AND SAVE THESE INSTRUCTIONS Take care when using cleaning agents or detergents. Suitable for use in household cooking area CAUTION CAUTION WARNING WARNING WARNING WARNING WARNING WARNING WARNING Electrical Shock Hazard...

  • Page 4: Installation

    Installation FOR RESIDENTIAL USE ONLY NOT TO BE INSTALLED OVER GAS GRILLS PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING. INSTALLATION MUST COMPLY WITH ALL LOCAL CODES. IMPORTANT: Save these Instructions for the Local Electrical Inspector’s use. INSTALLER: Please leave these Instructions with this unit for the owner. OWNER: Please retain these instructions for future reference.
  • Page 5 Installation Pre-Installations Calculations (see Figure 2) Tools required for installation Screw driver (pozidrive n°2 , torx 10 and 20) 1. a) Select a hood preference height P (see Figure 2) that is comfortable for Allen spanner 4mm the user not less than 30”. Shifting spanner 10mm b) Calculate Hood height your installation H (see Figure 2).

  • Page 6: Appliance Installation

    Installation Appliance Installation (Note: two people may be required for proper installation). Note: Duct screws can ONLY go below this line. Figure 6 12. Install Ducting. 13. To install Chimney Structure 14. To fasten the canopy Do not tighten. Figure 7 15.
  • Page 7 Installation Wiring to Power Supply WARNING! ELECTRICAL GROUNDING INSTRUCTIONS...
  • Page 8 Installation Attention! Tabs must be fixed using the double sided adhesive tape supplied (two segments each tab should be used!): Cut the e tape into 8 segments, then remove the protection covering from both sides and apply the segments close to the screws that fix the chimney flues to the structure.

  • Page 9: Use And Care

    Use and Care Control Pad Functions Suction power 3 LED, this led Suction power is ON when 2 LED, this led suction power is ON when 3 is selected. suction power 2 is selected. Light OFF button Motor OFF button Light ON button ON button and motor suction...

  • Page 10: Hood Cleaning

    Hood Cleaning To Clean Filters • • To Remove The Metal Grease Filters To Replace The Metal Grease Filters Figure 15 To Clean Hood Surface ® ® ® Lights replacement Turn blower and lights off. Make sure the lights are cool. Light Light cover Figure 16...
