OWNER’S GUIDE - Range Hood
PLHV42P8CC
READ AND SAVE THESE INSTRUCTIONS
E
PLHV42P8CC - P/N 316137229 (Pub. No. 5995392114)
Get other manuals https://www.bkmanuals.com

Advertisement

loading

Related Manuals for Electrolux PLHV42P8CC

Summary of Contents for Electrolux PLHV42P8CC

  • Page 1 OWNER’S GUIDE - Range Hood PLHV42P8CC READ AND SAVE THESE INSTRUCTIONS PLHV42P8CC - P/N 316137229 (Pub. No. 5995392114) Get other manuals https://www.bkmanuals.com...

  • Page 2: Product Registration

    Contents Table des matières Indice Contents Product Registration Record Your Model and Serial Numbers Get other manuals https://www.bkmanuals.com...

  • Page 3: Important Safety Instructions

    Important Safety Instructions READ AND SAVE THESE INSTRUCTIONS Take care when using cleaning agents or detergents. Suitable for use in household cooking area CAUTION CAUTION WARNING WARNING WARNING WARNING WARNING WARNING WARNING Get other manuals https://www.bkmanuals.com...

  • Page 4: Installation

    Installation FOR RESIDENTIAL USE ONLY NOT TO BE INSTALLED OVER GAS GRILLS PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING. INSTALLATION MUST COMPLY WITH ALL LOCAL CODES. IMPORTANT: Save these Instructions for the Local Electrical Inspector’s use. INSTALLER: Please leave these Instructions with this unit for the owner. OWNER: Please retain these instructions for future reference.
  • Page 5 Installation Pre-Installations Calculations (see Figure 2) Tools required for installation Screw driver (pozidrive n°2 , torx 10 and 20) 1. a) Select a hood preference height P (see Figure 2) that is comfortable for Allen spanner 4mm the user not less than 30”. Shifting spanner 10mm b) Calculate Hood height your installation H (see Figure 2).
  • Page 6 Installation Appliance Installation (Note: two people may be required for proper installation). Figure 6 Figure 7 Figure 8 Get other manuals https://www.bkmanuals.com...
  • Page 7 Installation Wiring to Power Supply Warning: Turn off power circuit at the service panel before wiring this unit. 120 VAC, 15 or 20 Amp circuit required. Figure 10 Final assembly For final Chimney Cover installation, DO NOT USE ELECTRIC SCREW DRIVER.
  • Page 8 Installation Cut the e tape into 8 segments, then remove the protection covering from both sides and apply the segments close to the screws that fix the chimney flues to the structure. main rear Chimney cover front Chimney cover Figure 12 Figure 13 Get other manuals https://www.bkmanuals.com...
  • Page 9 Use and Care Control Pad Functions Suction power 3 LED, this led Suction power is ON when 2 LED, this led suction power is ON when 3 is selected. suction power 2 is selected. Light OFF button Motor OFF button Light ON button ON button and motor suction...

  • Page 10: Lights Replacement

    Hood Cleaning To Clean Filters To Remove The Metal Grease Filters To Replace The Metal Grease Filters Figure 15 To Clean Hood Surface ® ® ® Lights replacement Light Light cover Figure 16 Get other manuals https://www.bkmanuals.com...
