- Page 1 Spotting Scope inStruction Manual Model#s : 841100 / 841101 Lit. #: 98-0080 / 11-09...
- Page 2 SETUP and OPERATION Congratulations on the purchase of your Simmons ® spotting scope, a versatile high-performance spotting scope offering a wide range of terrestrial viewing. Mounting tHe Scope anD Setting up tHe tripoD Remove the spotting scope from its case. Spread out the tripod legs and place the tripod on a level surface.
- Page 3 SETUP and OPERATION uSing tHe pan arM to MoVe tHe Scope To pan the scope side to side or up and down, first loosen the side and/or vertical lock. Then unlock the pan arm by rotating it counterclockwise and use it to move the scope as desired. To lock the scope in place, rotate the pan arm clockwise and tighten the side/vertical locks.
- Page 4 PARTS GUIDE Zoom Ring Collapsible Focus Knob Sunshade Quick Mount Plate Quick Mount Latch Side Tilt Lock Mounting Platform w/ bubble level Vertical Lock Elevation Pan Arm Crank Handle Elevation Height Lock Center Column Leg Lock Levers...
-
Page 5: Specifications
SPECIFICATIONS Spec Model# 841100 Model# 841101 Finish Rubber armor, matte Rubber armor, matte Lens Coating Fully coated Fully coated Prism Type BK-7 BK-7 Prism System Porro Porro Magnification Range 12-36x 20-60x Objective Diameter 50 mm 60 mm Exit Pupil (Lo Power) 4.1 mm... - Page 6 WARRANTY LIFETIME LIMITED WARRANTY Congratulations on the purchase of your new Simmons ® product. You have chosen one of the finest values available today. This product carries Simmons’ LIFETIME LIMITED WARRANTY. This product is warranted against original defects in material and/or workmanship...
- Page 7 NOTES...
- Page 8 ©2009 B.O.P. • SimmOnS, ®, Tm denOTeS Trademark Of B.O.P...
