Summary of Contents for Simmons 841103
- Page 1 Spotting Scope inStruction Manual 841103 / 846060t 03-16...
- Page 2 SETUP and OPERATION Congratulations on the purchase of your Simmons ® spotting scope, a versatile high-performance spotting scope offering a wide range of terrestrial viewing applications. Mounting tHe Scope anD Setting up tHe tripoD (Tripod is included with model# 841103 only) •...
- Page 3 Rotate the focus knob (located on the right side of the scope's body) until the image appears in sharp focus. uSing tHe pan arM to MoVe tHe Scope (841103 only) To pan the scope side to side or up and down, first loosen the side and/or vertical lock.
- Page 4 Side Tilt Lock Mounting Platform w/bubble level Vertical Lock Elevation Crank Handle Pan Arm Elevation Height Lock Center Column (*Tripod included with model# 841103 only) Note: tripod appearance/features are subject to change and may vary over the production cycle of this product.
- Page 5 SPECIFICATIONS Finish Rubber armor, matte Lens Coating Fully coated Prism Type BK-7 Prism System Porro Magnification Range 20-60x Objective Diameter 60 mm Exit Pupil (Lo Power) 3.0 mm Exit Pupil (Hi Power) 1.0 mm Field of View (Lo Power) 99 ft @ 1000 yds Field of View (Hi Power) 50 ft @ 1000 yds Eye Relief (Lo Power)
- Page 6 WARRANTY LIFETIME LIMITED WARRANTY Congratulations on the purchase of your new Simmons ® product. You have chosen one of the finest values available today. This product carries Simmons’ LIFETIME LIMITED WARRANTY. This product is warranted against original defects in material and/or workmanship...
- Page 7 NOTES...
- Page 8 ©2016 B.o.p. • SiMMonS, ®, tM DenoteS traDeMark oF B.o.p...
