- Page 1 Spotting Scope inStruction Manual Model #: 71-2060 Lit. #: 95-0076 / 08-10...
- Page 2 BASIC INSTRUCTIONS Congratulations on the purchase of your Simmons ® spotting scope, a versatile high-performance spotting scope offering a wide range of terrestrial viewing. Mounting tHe Scope anD Setting up tHe tripoD Remove the spotting scope from its case. Spread out the tripod legs and place the tripod on a level surface.
- Page 3 BASIC INSTRUCTIONS uSing tHe pan arM to MoVe tHe Scope To pan the scope side to side or up and down, first loosen the side and/or vertical lock. Then unlock the pan arm by rotating it counterclockwise and use it to move the scope as desired. To lock the scope in place, rotate the pan arm clockwise and tighten the side/vertical locks.
- Page 4 PARTS GUIDE Focus Knob Sunshade Zoom Ring Quick Mount Plate Quick Mount Side Tilt Latch Lock Mounting Platform w/ bubble level Vertical Lock Pan Arm Elevation Height Lock Elevation Crank Handle Center Column Leg Lock Levers...
-
Page 5: Specifications
SPECIFICATIONS Finish Rubber armor, black Lens Coating Fully coated Prism Type BK-7 Prism System Porro Objective Diameter 60 mm Exit Pupil (20x) 3.0 mm Exit Pupil (60x) 1.0 mm Field of View (20x) 115 ft @ 1000 yds Field of View (60x) 52 ft @ 1000 yds Eye Relief (20x) 18 mm... - Page 6 LIFETIME LIMITED WARRANTY Congratulations on the purchase of your new Simmons ® product. You have chosen one of the finest values available today. This product carries Simmons’ LIFETIME LIMITED WARRANTY. This product is warranted against original defects in material and/or workmanship...
- Page 8 ©2010 B.O.P. • SimmOnS, ®, Tm denOTeS Trademark Of B.O.P...
