Faber Diamante 630001648 Brochure & Specs

Designer collection wall canopy rangehood

Advertisement

Quick Links

Diamante
a brilliantly cut gem
wall canopy rangehood
°
sleek styling
°
600 cfm PRO motor
°
Silent Kit noise reduction
°
2 halogen lights for 30"
°
3 halogen lights for 36" and 48"
°
3 speed push button controls
°
stainless steel baffle filters
°
modified pro depth
°
convertible to ductless*
°
Easy Cube mounting system
°
sone range: 3.5 - 6.5
°
6" round duct
°
* it is highly recommended that
professional style cooking always
be vented to the outside.
Size/Color/Model #
30 Stainless
36 Stainless
48 Stainless
a
24" High Backsplash
c
24" high, mounts to the wall beneath
the rangehood for a coordinated look
c
30 x 24 Stainless
36 x 24 Stainless
e
s
30" High Backsplash
s
30" high, mounts to the wall beneath
the rangehood for a coordinated look
o
30 x 30 Stainless
36 x 30 Stainless
r
High Ceiling Chimney Kit
i
One 40" upper chimney to replace 16 1/8"
e
upper chimney that came with hood
s
Stainless
p.o. box 435 • Wayland, MA 01778 • tel: (508) 358-5353 • fax: (508) 358-5730 • e-mail: info@faberonline.com • www.faberonline.com
A streamlined shape combined with traditional
styling makes the Diamante an updated alternative
in canopy ventilation. To add subtle sparkle, the
corners of the canopy and the chimney are angled
in a diamond-like cut.
630001087
630001088
630001648
6098835
6098815
Ductless Conversion Kit
620000095
620000096
Includes: • Lower Chimney with holes for duct-
ing • Ductless Diverter Assembly • Vent Grates
• Charcoal Filter
Stainless
Replacement Charcoal Filter
620000071
Designer Collection
pro-style baffle filters with European flair
and a built-in grease control system; bright
halogen lights encircled by a stainless trim
620000072
620000041
