Page 1
Size/Color/Model # 36 x 27 Stainless 630006504 (600 cfm) - NEW 36 x 27 Stainless 630006505 (280 cfm) High Ceiling Chimney Kit Extends the island chimney for high ceilings Stainless 620000370 Ductless Conversion Kit Includes: • Lower Chimney with holes for ducting •...
Page 2
Dimensional Diagrams Ducted Ductless Pre-Planning Your Installation - Important: Consult the installation instructions before you begin installing this rangehood. Ducted Ductless upper 3/8” upper chimney 3/4” 3/8” chimney cover 3/8” cover ductless lower lower 1/2” 5/8” chimney 5/8” chimney cover cover 1/2"...
