HOTPOINT EG20, EG21 & EG22
COOKER
INSTRUCTION
AND RECIPE BOOK
The cooker must be installed in accordance with the regulations in force
and only used in a well ventilated space.
Read these instructions prior to installing or using the cooker and retain
them for future reference.
The data badge is located below the oven door on the plinth panel.
Advertisement
Table of Contents
Related Manuals for Hotpoint EG20
Summary of Contents for Hotpoint EG20
- Page 1 HOTPOINT EG20, EG21 & EG22 COOKER INSTRUCTION AND RECIPE BOOK The cooker must be installed in accordance with the regulations in force and only used in a well ventilated space. Read these instructions prior to installing or using the cooker and retain them for future reference.
-
Page 2: Table Of Contents
Oven Temperature Chart – Meat Oven Temperature Chart – Baking Recipes Care and Cleaning Cooking Results Not Satisfactory Something Wrong with your Cooker If it still won’t work Installation Hotpoint Service Cover Service 15 - 17 18 - 19 23 - 29 Back Cover... -
Page 3: Introduction
Introduction to Hotpoint EG20,EG21 & EG22 To help make the best use of your Hotpoint cooking equipment please read this booklet carefully. Your new cooker is guaranteed and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. -
Page 4: For Your Safety - Always
For Your Safety PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. Always Always make sure you remove all packing from inside the oven and grill compartments before switching on for the first time. Always make sure you understand the controls prior to using the appliance. -
Page 5: For Your Safety - Never
For Your Safety Never NOTE: The use of a gas cooking appliance results in the production of heat and moisture in the room in which it is installed. Ensure that the kitchen is well ventilated; keep natural ventilation holes open or install a mechanical ventilation device (mechanical extractor hood) Prolonged intensive use of the appliance may call for additional ventilation, for example opening of a window, or more effective... -
Page 6: Features
Features EG20 / EG21 / EG22 SIMMERING BURNER HIGH SPEED BURNER EW 21 GRILL GRILL DOOR RATING PLATE OVEN DOOR HOB VENTILATION SLOTS Oven Grill MEAT HIGH SPEED BURNER SIMMERING BURNER CONTROL PANEL Made in Great Britain GRILL/MEAT PAN WITH FIXED/... -
Page 7: Control Panel
Control Panel OVEN INDICATOR LIGHT OVEN GRILL Note: Always ensure that all controls are in the OFF position, when the appliance is not in use. Operating the In common with all cookers having controls sited above the grill control when the compartment, care must be taken when setting the controls, due grill is in use to hot air being emitted from the grill compartment. -
Page 8: Using The Hob
Using the Hob The hob has two high speed burners and two simmering burners which will accommodate pans between 100mm (4”) and 200mm (8”) diameter. All pans should be positioned centrally over the burners. The pan supports should be fitted on the hob such that the indents along one side of each pan support are inner-most. -
Page 9: Temperature Conversion Scale
Temperature Conversion Scale Comparative scale of oven settings (degrees Celsius to degrees Fahrenheit) as recommended by the Association of Manufacturers of Domestic Electrical Appliances. The temperature control knobs on this electric cooker are marked in degrees Celsius. This chart will help when the recipes show alternative scales. -
Page 10: Using The Grill
Using the Grill CAUTION: ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. GRILLING SHOULD NOT BE UNDERTAKEN WITH THE GRILL DOOR CLOSED. To Use the Open the grill chamber door fully. Grill Preheat the grill at setting 6 for approximately 5 minutes. -
Page 11: Using The Fan Oven
Using the Fan Oven The oven is fitted with ‘Stayclean’ liners, two rod shelves and a meat pan. Remove the meat pan if it is not being used. To Use the To heat the oven, turn the control knob clockwise, selecting the Oven required temperature between 80 recommended in the temperature chart. -
Page 12: Oven Cookery Notes
Oven Cookery Notes To prepare meat and poultry for roasting in your fan oven. (a) Wipe the meat or poultry, dry well and weigh it. Meat which has (b) The weight of any stuffing used should be added before cal- (c) Place meat/poultry in the meat pan supplied with your cooker. -
Page 13: Oven Temperature Chart - Meat
Oven Temperature Charts – Meat Fan Oven Cooking Meat Beef Lamb Pork Veal Chicken/Turkey up to 4kg (8 lb) Turkey up to 5.5kg (12 lb) over 5.5kg (12 lb) Casserole Stews If using aluminium foil, never: 1. Allow foil to touch sides of oven. 2. -
Page 14: Oven Temperature Chart - Baking
Oven Temperature Charts – Baking Note: If soft margarine is used for cake making, temperatures recommended by the manufacturers should be followed. Temperatures recommended in this chart refer to cakes made with block margarines or butter only. Baking Food Scones Small Cakes Victoria Sandwich Sponge Sandwich... -
Page 15: Recipes
Recipes For Fan Oven BEEF STEW AND DUMPLINGS 675g (1 lb) stewing steak, cut into 2.5cm (1 in. cubes) 2 medium sized onions, peeled and quartered 225g (8oz) carrots, peeled and sliced 225g (8oz) swede, peeled and cubed 4 sticks of celery, cut into 2.5cm (1 in.) lengths 500ml (1 pint) beef stock, boiling 30ml (2 tbsp) tomato puree... - Page 16 Recipes For Fan Oven BATTERS Basic Recipe: 100g (4oz) plain flour Pinch of salt 1 large egg 250ml ( pint) milk and water mixed in equal quantities YORKSHIRE PUDDING 1. Place 25g (1oz) dripping into shallow ovenproof dish or 22.5cm (9in) square Yorkshire pudding tin and place in top of oven to heat for 10 minutes.
- Page 17 Recipes For Fan Oven CHRISTMAS CAKE 225g (8oz) butter or block margarine 225g (8oz) brown sugar 4 eggs 225g (8oz) plain flour 5ml (1 tsp) mixed spice 2.5ml ( tsp) baking powder 200g (7oz) raisins 200g (7oz) sultanas 200g (7oz) currants 50g (2oz) chopped almonds 75g (3oz) glace cherries (cut in pieces) 60ml (4 tbsp) brandy (optional)
-
Page 18: Care And Cleaning
Care and Cleaning TURN OFF THE MAIN SWITCH BEFORE CLEANING. BEFORE SWITCHING ON AGAIN, ENSURE THAT ALL CONTROLS ARE IN THE OFF POSITION. NEVER USE BIOLOGICAL WASHING POWDER, HARSH ABRASIVES, SCOURING PADS, AEROSOL CLEANERS OR OVEN CHEMICAL CLEANERS OF ANY KIND. COOKER FINISH Vitreous Enamel Hotplate, burner caps,... - Page 19 Care and Cleaning Oven Inner Glass Door - open the door fully and unscrew the two screws EG22 only securing the glass panel, taking care not to allow the glass to fall. The glass panel may now be washed at the sink. Stubborn stains can be removed by using a fine steel wool soap pad.
-
Page 20: Cooking Results Not Satisfactory
Cooking Results Not Satisfactory? Problem Grilling Uneven cooking front to back Fat splattering Oven Baking Uneven rising of cakes Sinking of cakes Over/Under cooking Fast/Slow cooking Nothing Works Top Oven Baking Uneven cooking front to back Uneven cooking of cakes Uneven rising of cakes Food is taking too long to cook... -
Page 21: Something Wrong With Your Cooker
Something Wrong with your Cooker? Before contacting your Service Office/Installer, check the problem guide below. Problem Slight odour or small amount of smoke when using the cooker for the first time. Cooker does not work at all. Oven temperature seems too high or too low. -
Page 22: If It Still Won't Work
It must be installed and connected in accordance with current installation regulations. Particular attention should be given to the relevant requirements regarding ventilation. MODEL NUMBERS EG20, EG21, EG22. Category I 2H (G.B. IE) These models are set to burn NATURAL GAS (G20) at 20 mbar ONLY and cannot be used on any other gas. - Page 23 Installation Technical Data Height Dimension Width Depth Gas connection General Pressure test point Gas rate adjustment Aeration adjustment Electrical connection Total Electrical heat input HEAT INPUT BURNER HOTPLATE 3.0 kW Front left & rear right HOTPLATE 1.8 kW Front right & rear left GRILL OVEN 900mm...
- Page 24 Installation The cooker is of type X with regard to protection against overheating of surrounding surfaces as defined in BS EN60335-2-6: 1991 it can be close fitted below hotplate level. This requires a minimum distance of 503mm between cupboard units of hotplate height. When installing next to a tall cupboard, partition or wall, for a minimum distance of 400mm above hotplate level, allow a side clearance of at least 65mm.
- Page 25 Note: Take care in moving the cooker as it is heavy. Take care to ensure that any floor covering is not damaged. Splashplate optional, apply to Hotpoint Spares Department.
- Page 26 Installation Unpack the components from inside the grill and oven: Check that Unpacking the the following parts are present. Cooker Grill pan and grid Baking dish Oven shelves (2) Literature The cooker must be fitted with a stability device firmly secured to the Stability Chain fabric of the building.
- Page 27 Installation WARNING – THIS APPLIANCE MUST BE EARTHED. Your cooker should have been checked to ensure that the voltage corresponds with your supply voltage, this is stated on the rating plate, which is situated on the front of the plinth. The cooker must be connected by a com- petent person eg.
- Page 28 Installation Operational After installation, check for gas soundness. Checks Fit the hotplate burner bodies, burner port rings, enamelled discs and pan supports referring to the instructions for use where necessary. 1. Check that the hotplate burners ignite correctly and burn with a 2.
-
Page 29: Hotpoint Service Cover
Hotpoint gives you a unique ‘Satisfaction Guaranteed’ promise – valid for ninety days after you have purchased your Hotpoint product. If there is a technical problem with your Hotpoint appliance, just call Hotpoint Service (see back page). If necessary we will arrange for an engineer to call. -
Page 32: Service
08701 50 60 70 For further product information All Hotpoint Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.
