Mixer Tab
The mixer tab is where you control the component volumes on the
sound card for both recording and playback.
Playback Mixer
The playback mixer is used to control all sound components that
are playing back through your system speaker system.
Balance
With this slider set to the middle position an equal volume of
sound will be present out the left and right channels. Moving
the slider left or right of the middle position will cause the left
or right channel o be more prominent.
Notice: Each component on the sound card also has an indi-
vidual balance slider. Moving the balance on an individual
component only affects that particular component.
Volume
Use this knob to raise or lower the overall system volume
level.
Mute
The mute button located just under the volume knob will mute
the entire sound system when lit. Click once to toggle this
control on/off. Notice: Each component on the sound card
also has an individual mute button. Clicking the mute on an
individual component only affects that particular component.
Wave
The Wave slider controls the volume of any program using
the Wave playback portion of the sound card. This usually
includes and is not limited to files with the following
extensions: .WAV, .MP3, .RM, etc). Most games will use the
Wave channel for sound effects and voice playback.
Continued on Next Page. PAGE 9
