1.1 Getting Started

After unpacking the scale, a small amount of assembly is required: Locate the sub-platform, four
(4) Hex screws, and enclosed Allen wrench. Place the sub-platform onto the scale's load point
with all rubber parts facing up. Install and tighten the four Hex screws. Please place the scale on
a firm and stable floor or table and plug the line cord into an AC outlet. Leave the scale on for at
least 30 minutes before using. You will find the ON/OFF switch at the bottom of the scale on the
right, towards the front. You may leave the scale on at all times, if you wish. Press the ZERO
key before operating the scale.

1.2 Important Startup Precautions:

•
DO NOT Share an AC outlet with other noise producing products (devices with electrical
motors or relays).
•
DO NOT turn the scale ON with an object already on the platform. You will not be able to
Zero the scale.
•
DO NOT operate the Scale in an area with changing ambient temperature, direct sunlight,
high humidity, wind, or vibration.

2. SPECIFICATIONS

Measurement system
Display
Capacity (resolution)
Accuracy
Overload display
Overload limit
Zero adjust
Digital Tare
Count Accumulation
Measurement modes
Power Supply
Power consumption
Weight
Dimensions

3. BASICS OF OPERATION

3.1 Keypad Overview

1 2
CE
Strain gauge load cell
7 segment, 16 digit vacuum fluorescent display
160310 = [12 lbs. (0.002lbs)] : 160330 = [30 lbs. (0.005 lbs.)]
± 0.02% full scale
Displays indicates dashes ' - - - - - ' to 103% of capacity
300% of capacity maximum static overload
Automatic zero via keypress
Known sample quantity or unit weight entered via keypad
999,999 pieces maximum. 99,999 separate count operations
COUNT, TOTAL, UNIT WEIGHT, and WEIGHT
117VAC ±10%, 50/60Hz (Fuse: 5 x 20mm, 0.5A QuickBlow)
Approx. 10 Watts
Approx. 10.2 lbs. (4.6 kg)
9x12.3x3" (240x315x85mm); Pan: 8.25x9" (210x238mm)
3 4
M+ MR
5 6
CM
WT SET SAMPLE
7 8
Zero
Check
9 0
Tare
