- Page 1 L200 LINE/SUM/MIKE AMPLIFIER OPERATING AND MAINTENANCE MANUAL © Copyright 1997-2005, Audio Technologies Incorporated - Printed in USA Audio Technologies Inc. | 154 Cooper Road #902 | West Berlin, NJ 08091 | Voice 856-719-9900 | Fax 856-719-9903 | www. audio.com...
- Page 2 CIRCUIT DESCRIPTION INPUT STAGES The balanced input stages of the L200 Line Amplifier utilize a FET input LF347 quad opamp in a clean, quiet inverting instrumentation amplifier configuration. Input levels up to +24dBm will be handled without clipping, excess levels cause only clean clipping without hang-up or phase reversal.
- Page 3 -10dBu nominal unbalanced signal. POWER SUPPLY The L200 requires 22 to 30VDC and are designed to share a common external 24VDC "Wall Wart" type power supply. A pair of loop-thru DC connectors on the rear of each module permit several units to be daisy-chained with P/N20602-1 DC power cables to a single power supply.
- Page 4 MOUNTING Single desk mounting kits consist of a pair of angled base plates that mount under the lower front and rear cover screws of a single unit, to raise and to tilt it for easy use. In addition, one or more sets of vertical stacking plates, mounting to the upper front and rear cover screws of the bottom unit, allow multiple units to be stacked.
- Page 5 OPTIONS 230VAC The WA100-2 tabletop power supply accepts 230VAC/50-60Hz via an IEC320 male 3 pin AC input connector. User supplies a matching line cord for the local power system. Battery Operation Alkaline battery packs (BBU100-1) and 24VDC converters for operation from 12V belt pack or automotive batteries (DC100-1) power modules are available.
-
Page 6: Performance Specifications
PERFORMANCE SPECIFICATIONS GAIN: 28dB maximum, 0dB at 12 o’clock pot position NOMINAL LEVELS: +4dBu in, +4dBm out to 600 ohm balanced load PEAK LEVELS: +24dBu in, +22 dBm out to 600 ohm balanced load NOISE 20kHz B.W.: -90dBm maximum output HARMONIC DIST.: .02% Max at Peak Level 20Hz to 20 kHz .005% max at Nominal Level... - Page 7 20602-1: DC power cable assembly for looping the DC power between DESK MOUNT KITS: 20617-501 Angled Desk Mount Base 20617-502 Angled Desk Mount Base and One Stacker (2 units high) 20617-503 Angled Desk Mount Base and Two Stackers (3 units high) 20617-504 Stacker (2 units high) 20604-504 Horizontal Joiner (2 units side-by-side) RACK MOUNT KITS:...
