L1000
DUAL LINE AMPLIFIERS
OPERATION AND MAINTENANCE MANNUAL
© Copyright 1997-2007, Audio Technologies Incorporated - Printed in USA
Audio Technologies Inc. | 154 Cooper Road #902 | West Berlin, NJ 08091 | Voice 856-719-9900 | Fax 856-719-9903 | www.
audio.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the L1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ATI Technologies L1000

Summary of Contents for ATI Technologies L1000

  • Page 1 L1000 DUAL LINE AMPLIFIERS OPERATION AND MAINTENANCE MANNUAL © Copyright 1997-2007, Audio Technologies Incorporated - Printed in USA Audio Technologies Inc. | 154 Cooper Road #902 | West Berlin, NJ 08091 | Voice 856-719-9900 | Fax 856-719-9903 | www. audio.com...
  • Page 2 DESCRIPTION The IC’s that were developed primarily for the instrumentation market had many shortcomings when used in high quality audio applications. The lack of audio related specifications, crossover distortion, high noise for low source impedances, limited output capability and limited gain bandwidth product forced many compromises when used in high gain audio systems.
  • Page 3 MICRO"P, use the proper ground for each channel. The L1000 will accept input audio to +24dBm bridging (12.5 Vrms). Inputs are protected by clamping diodes for signal swings exceeding ±41 Vp-P. Output wiring is indicated on the rear panel label. H1 outputs are in phase with each other and with the input signal.

  • Page 4: Maintenance Notes

    +/- amplifier inputs (other than due to meter loading) indicates IC failure. MODIFICATIONS - 230 VAC OPERATIONS Your L1000 is wired for 115 VAC 50/60 Hz operations unless otherwise requested at the time of ordering. It can be modified for 230 VAC use by removing the Power transformer primary jumpers W1 and W3 and inserting a jumper in the W2 holes.

  • Page 5: Input Impedance

    PERFORMANCE SPECIFICATIONS OUTPUT CLIPPING LEVEL +22dBm /600 ohms DISTORTION @ +20dBrn output and input levels to +24dBm FREQUENCY RESPONSE +/-.25dB, 50 to 20,000 Hz -1 dB at 20 Hz .2% maximum THD, 30 to 20,000 Hz INPUT IMPEDANCE Balanced differential inputs, 30,000 bridging...
