COMPONENT EXPLODED VIEW
Corner Bracket (4)
364255-001
90 DEG
(Internal cabinet)
Screw (8)
882-41110-12
6 X 3/4
PAN,PH,PB,BLK
ZINC, LCS
Brackets
*Gasket
Line Array Horn
Gasket
339391-001
12"
Grille
Driver, Low Freq
Assembly
2262FF
352282-001
(363946-001X)
Cone Repl
Screw (6)
C2X2R2262
882-51110-12
6 X 3/4
Screw (8)
OV,PH,PTCL,
804-01110-16
BLK ZC,LCS
10-32 X 1
FIL,PH,BLK
ZINC,LCS
T-Nut (8)
61861
10-32 X 7/16
Step Barrel
Dust Dome
71646-04
Enclosure Assembly
VRX932LAP/240
(Not Available for Sale)
Screw (8)
818-11710-25
M10 X 25MM
Driver, HF
FLT,PH,BLK
2408J
ZINC,LCS
(361549-003X)
Diaph Repl
D16R2408
Horn
364432-001
*Gasket (2)
352378-002
Line Array Horn
Gasket,Pole
Mount
363605-001
Pole Cup, Dual
363602-001
Overlay, Dual Cup
364659-001
Pole Mount
Screw (6)
806-11010-12
1/4-20 X 3/4
FLT,PH,UNC,
BLK ZINC,L
Pole Mount
Nut (6)
804-90003-00
T-Nut, Short Barrel
Pole Mount
JBL VRX932LAP/230
Wire Harness
Amp Board
364338-004
443941-001
Screw (10)
Input Board
804-51110-12
443920-001
10-32 x 3/4
OVAL,PH,BLK
Modular PCB
ZINC, LCS
444087-001
Amplifier Trim
Interface PCB
363560-001
443807-001
T-Nut (10)
352214-001
10-32 X 1/4
ZINC PLATED
Amplifier
Air Seal Cover
(2)
353376-002
Foot (4)
Screw (20)
353445-001
882-41110-12
6 x 3/4
Screw (4)
PAN,PH,PB,
884-41110-12
BLK ZINC,
10 X 3/4
LCS
PAN,PH,PB,
BLK ZINC,LCS
Bolt,Horn (2)
854-00000-60
1/4-20 X 3 3/4
HEX,CLRZINC,LCS
Washer, Horn Bolt (2)
844-01110-07
1/4, SAE,REG,
BLK,ZINC,LCS
Washer (2)
844-03110-06
3/8 BLK
Split Lock
Drop Lever (2)
364591-003
Blk
Nylon Nut, (2)
364173-001
#8
Screw, (2)
354379-003
3/16 DIA X 1 LG
(Shldr)
Foam Pad (2)
361372-001
Rigging
Quick Release (2)
Pin
361239-003
W/Lanyard L/Shape
Handle, Front (2)
354543-001
"U" Channel (2)
361417-001
Air Cover
Gasket (2)
Screw (4)
353538-001
Rigging Channel
803-11010-12
Handle, Rear (2)
8-32 X 3/4
354544-001
FLT,PH, BLK ZC
LCS
Screw (4)
722-90008-08
Clip Pin (4)
6-19 X 1/2
363764-001
HI-LO,PAN,PH,
BLK-OX
Screw, Clip (4)
882-41110-10
6 X 5/8
PAN,PH,PB,BLK
ZINC,LCS
