Viega Digital Thermostat Product Instructions

Product Instructions
Digital Thermostat

Applications

The Digital Thermostat is ideal for individual
room temperature control. A user friendly
three button design allows for easy change
of settings. Thermostat can sense either
room temperature, floor temperature or both.
Adjustable temperature setback function
allows for energy savings. Thermostat can
control up to four Powerheads directly or can
be connected to a zone / circulator control
box. With optional floor sensor, thermostat
provides floor high or low limit function for floor
protection or floor warming.

Features

• Compact design
• Digital LCD display
• Regulates floor or room temperature or both
• Optional Floor Sensor
• Setback function

Specifications

Control:
Accuracy:
Set temperature range:
Environment range:
Power supply:
Output:
Optional floor sensor:
Floor limiting range:
Electrical Protection:
301 N. Main, 9th Floor • Wichita, KS 67202 • Ph: 877-843-4262 • Fax: 800-976-9817 • E-Mail: service@viega.com • www.viega.com
PI-PR-18050-0309 (Digital Thermostat)
Microprocessor control
0.2 °F
41 °F - 99 °F, 0.5 °F increments
32 °F - 122 °F
24 V + / _ 10% 60Hz 15 W max
TRIAC output 24 VAC, 15 W max
NTC thermistor, (10K Ohms) 10' cable
50 °F - 104°F
Class II - IP30
Viega... The global leader in plumbing and heating systems.
1.22"
2.36"
3.15"
3.15"
