Product
Instructions
Viega Multifunctional Heat/Cool Thermostat
®
The Viega multifunctional heat/cool thermostat is easy
to install, easy to wire and easy to program. It can be
used for three stages of heating and two stages of
cooling, making it ideal for many applications. Installation
instructions can be found below.
Thermostat applications guide
Description
Gas or Oil Heat
Electric Furnace
Heat Pump (No Aux. or Emergency Heat)
Heat Pump (with Aux. or Emergency Heat)
Multi-stage Systems
Heat Only Systems
Cool Only Systems
Mounting the subbase
W/E
W2
For vertical mount put one screw top and one screw bottom.
For horizontal mount put one screw left and one screw right.
The thermostat can be mounted directly to the wall or it can
be mounted to a wall box. Use the vertical mounting screw
location to attach to a wall box.
Viega LLC, 301 N. Main, 9th Floor • Wichita, KS 67202 • Ph: 800-976-9819 • Fax: 316-425-7618
PI-PR 566441 0114 (Multifunctional Thermostat)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
to install this product can cause electrical shock or
equipment damage.
product you are replacing contains mercury, dispose of it
properly. Your local waste management authority can give
Y2
you instructions on recycling and proper disposal.
A trained, experienced technician must install this
product. Carefully read these instructions. You could
damage this product or cause a hazardous condition if
you fail to follow these instructions.
Caution: Electrical Hazard
Failure to disconnect the power before beginning
Mercury Notice:
All of our products are mercury free. However, if the
Part Number 15118
